Denon AVR-S900W

Pin Pin Name Symbol I/O Pu/Pd STBY STOP
CEC
STBY
Function
18 P85
REMOTE
POWER(232C)
(X2100W(NA))/
NC(S900W/
X2100W(EU/CH/AP/
JP))
O L L L
232C POWER SUPPLY (REMOTE 3.3V)
control pin.(ON: H)
19 RES# RESET I - - - Reset input (reset: L)
20 XTAL XTAL I - - - Oscillator connection
21 VSS VSS - - - - GND
22 EXTAL EXTAL - - - - Oscillator connection
23 VCC VCC - - - - +3.3V
24 NMI NMI I M3VPu - - - Unused
25
P34/IRQ4-A/PO12/
TIOCA1
BDOWN I I I I Power failure detection pin(Power failure:L)
26
P33/IRQ3-A/PO11/
TIOCC0/TIOCD0/
TCLKB-A
DAC.PLD ERR I L L L PLD ERROR detection pin
27
P32/IRQ2-A/PO10/
TIOCC0/TCLKA-A
NC O/I L/I L/I L/I NC
28
P31/IRQ1-A/PO9/
TIOCA0/TIOCB0
NC O L L L NC
29
P30/IRQ0-A/PO8/
TIOCA0
RC IN I I I I Remote control signal input pin
30
P27/PO7/TIOCA5/
TIOCB5/SCK1
NC O L L L NC
31
P26/PO6/TIOCA5/
TMO1/TxD1
NC O L L L NC
32
P25/PO5/TIOCA4/
TMCI1/RxD1
NC O L L L NC
33
P24/PO4/TIOCA4/
TIOCB4/TMRI1
TU RST O
SW3VPu
L L L TUNER RESET pin
34
P23/PO3/TIOCC3/
TIOCD3
E RESET O(ODR) N3VPu L L L ETHERNET RESET control pin
35
P22/PO2/TIOCC3/
TMO0/SCK0
E SPI CLK O N3VPu L L L ETHERNET communication control pin
36
P21/PO1/TIOCA3/
TMCI0/RxD0
E SPI MIEO I N3VPu I L I ETHERNET communication control pin
37
P20/PO0/TIOCA3/
TIOCB3/TMRI0/TxD0
E SPI MOEI O N3VPu L L L ETHERNET communication control pin
38
P17/IRQ7-B/TCLKD-B/
TxD3/SCL0/ADTRG1#
TU SCLK I_O L L L TUNER control pin
39 PLLVCC PLLVCC - - - - +3.3V
40
P16/IRQ6-B/TCLKC-B/
RxD3/SDA0
TU SDIO I_O L L L TUNER control pin
41 PLLVSS PLLVSS - - - - GND
42
P15/IRQ5-B/TCLKB-B/
SCK3/SCL1
EEPROM SCL O M3VPu I I I EEPROM control pin
43
P14/IRQ4-B/TCLKA-B/
SDA1
EEPROM SDA I_O M3VPu I I I EEPROM control pin
44
P13/IRQ3-B/TxD2/
ADTRG0#
ADV8003 SPI MO O L L L OSD control pin
45 P12/IRQ2-B/RxD2 ADV8003 SPI MI I L L L OSD control pin
46 P11/IRQ1-B/SCK2 ADV8003 SPI CLK O L L L OSD control pin
47 P10/IRQ0-B ADV8003 SPI CS O L L L OSD control pin
48
P37/PO15/TIOCA2/
TIOCB2/TCLKD-A
NC O L L L NC
49 P36/PO14/TIOCA2 NC O L L L NC
50
P35/PO13/TIOCA1/
TIOCB1/TCLKC-A
NC O L/H L/L L/H NC
51 P84 NC O L L L NC
52 P57/WAIT#/TRDATA3 NC O L L L NC
53 P56/TRDATA2 E POWER1 O L L L
ETHERNET POWER SUPPLY (NET3.3V)
control pin
54 P55/TRDATA1 E POWER2 O L L L
ETHERNET POWER SUPPLY (NET2.5V)
control pin
55 P54/TRDATA0 E POWER3 O L L L
ETHERNET POWER SUPPLY (NET1.8V)
control pin
56 P83 E POWER4 O L L L
ETHERNET POWER SUPPLY (NET1.2V)
control pin
57 VSS VSS - - - - GND
147
