Denon AVR-S900W Service Manual

Pin Symbol Pin Name I/O Pu/Pd
LvCnv
STBY
CEC
STBY
Function
85 PD1/IRQ1 DSP1CS O C
DA
3VPu
Z L DSP control pin (ADSP21487KSWZ-3B)
86 PD0/IRQ0 DSP1FLAG0 I -
Pd
Z - DSP control pin (ADSP21487KSWZ-3B)
87 P47/AN007 NC O C
-
Z - NC
88 P46/AN006 VIN A O C
-
Z - COMPOSITE VIDEO SELECT IC(NJM2595)
89 P45/AN005 VIN B O C
-
Z - COMPOSITE VIDEO SELECT IC(NJM2595)
90 P44/AN004 VIN C O C
-
Z - COMPOSITE VIDEO SELECT IC(NJM2595)
91 P43/AN003 COMP SW1 O C O/L L COMPONENT VIDEO SELECT IC(NJM2586)
92 P42/AN002 COMP SW2 O C O/L L COMPONENT VIDEO SELECT IC(NJM2586)
93 P41/AN001 NC O C
-
Z - NC
94 VREFL0 VREFL0 - -
-
- - GND
95 P40/AN000 NC O C
-
Z - NC
96 VREFH0 VREFH0 - -
-
- - +3.3V
97 AVCC0 AVCC - -
-
- - +3.3V
98 P07 NC O C
-
Z - NC
99 AVSS0 AVSS0 - -
-
- - GND
100 P05 TXEN O C
-
Z - Front HDMI INPUT (AD8195) control pin
152

Denon AVR-S900W Specifications

General

Channels	7.2
HDMI Inputs	8
HDMI Outputs	2
Wi-Fi	Yes
Bluetooth	Yes
4K Ultra HD Pass-through	Yes
Dolby Atmos	Yes
DTS:X	No
HDMI Pass-Through	Yes
Input Impedance	47 kOhm
Input Sensitivity	200 mV
THD at rated output	0.08%
Signal-To-Noise Ratio	98 dB
DAC Resolution	24-bit / 192kHz
HDMI Switching	Yes
AirPlay	Yes
DLNA	Yes
Dimensions	17.1 x 6.6 x 13.3 inches
Power Output	90 W
Response Bandwidth	10Hz-100kHz
Output Impedance / Channel	6 Ohm
Inputs	HDMI
Outputs	HDMI
Supported Audio Formats	MP3, WMA, AAC, FLAC, WAV
Supported Video Formats	4K
Output Power / Channel	90W (8 ohms, 20Hz-20kHz, 0.08% THD)
