Denon AVR-S900W Service Manual

MAIN
MAIN PCB ASS'Y
※Parts indicated b
y
"ns
p
"on this table cannot be su
pp
lied.
※The
p
arts listed below are onl
y
for maintenance. Therefore the
y
mi
g
ht differ from the
p
arts used in the unit in a
pp
earances or dimensions.
NOTE:The symbols in the column Remarks indicate the following destinations.
E3 : U.S.A. & Canada model E2 : Europe model E1C : China model E1 : Asia model K : Japan model
BK : Black model SP : Silver gold model
REF No. Part No. Part Name Remarks Q't
y
New
V
er
SEMICONDUCTORS GROUP
D4000-4004 963201500170D LBAS16HT1G FAST SWITCHING SOD-323 K005041480230S 5
D4007 00D2760401905 1SS133-DO34-AXIAL LRC K000013300040S 1
D4008 963203500300D DIODE BRIDGE D10SB60 600V/10A STRAIGHT TYPE K047100600220S 1
D4013 963201500170D LBAS16HT1G FAST SWITCHING SOD-323 K005041480230S 1
D4014 963201500160D 1N4007 52REEL 1000V 1A K000400700220S 1
D4016 00D2760401905 1SS133-DO34-AXIAL LRC K000013300040S 1
D4017 963201500160D 1N4007 52REEL 1000V 1A K000400700220S 1
D4019 00D2760401905 1SS133-DO34-AXIAL LRC K000013300040S 1
D4020 963201500160D 1N4007 52REEL 1000V 1A K000400700220S 1
D4022 963201500160D 1N4007 52REEL 1000V 1A K000400700220S 1
D4023 963201500170D LBAS16HT1G FAST SWITCHING SOD-323 K005041480230S 1
D4025 963201500160D 1N4007 52REEL 1000V 1A K000400700220S 1
D4026 963201500170D LBAS16HT1G FAST SWITCHING SOD-323 K005041480230S 1
D4027-4030 963201500160D 1N4007 52REEL 1000V 1A K000400700220S 4
D4031,4032 00D2760401905 1SS133-DO34-AXIAL LRC K000013300040S 2
D4033-4036 963201500160D 1N4007 52REEL 1000V 1A K000400700220S 4
D4037 00D2760401905 1SS133-DO34-AXIAL LRC K000013300040S 1
D4038 963201500160D 1N4007 52REEL 1000V 1A K000400700220S 1
D4039-4044 963201500170D LBAS16HT1G FAST SWITCHING SOD-323 K005041480230S 6
IC4000 00D2631100005 KIA7805API,20W-TO220IS MOLD J126780500110S 1
IC4001 00D2631099006 KIA7905PI,20W-TO220IS MOLD J126790500070S 1
IC4002 00D2631100050 KIA7808API,20W-TO220IS J126780800050S 1
IC4003 00D2631100005 KIA7805API,20W-TO220IS MOLD J126780500110S 1
IC4004 00D2631251006 KIA7908PI,20W-TO220IS J126790800060S 1
IC4005 963232100400S UTC4580E SOP8 DUAL OP AMP J121458001010S 1
IC4701 236810090504S ILX3232D 3V3 RS232 INTERFACE TRANSCEIVER SOP16 J046323200020S 1
Q4005-4010 963214500310S RT1N237C 0.2W/SC-59 ISAHAYA J522102371210S 6 *
ZD4002 963202500330D ZJ6.8B-0.5W/5MA-52MM SEMTECH K06006R844522S 1
ZD4157,4158 963202500290D ZJ3.6B-0.5W/5MA-52MM SEMTECH K06003R644522S 2
RESISTOR GROUP
R4000,4001 963125010110S 470-J,2W-R.REEL C060047166060S 2
R4002 nsp 10-J,1/5W-52RE-AX C00001006P520S 1
R4003 963125010100S 10-J 2W, R-REEL C060010066050S 1
R4004 nsp 10-J,1/5W-52RE-AX C00001006P520S 1
R4005 963125010100S 10-J 2W, R-REEL C060010066050S 1
R4006 nsp 10-J,1/5W-52RE-AX C00001006P520S 1
R4007 963125010100S 10-J 2W, R-REEL C060010066050S 1
R4008 nsp 10-J,1/5W-52RE-AX C00001006P520S 1
R4009 963125010100S 10-J 2W, R-REEL C060010066050S 1
R4010 nsp 10-J,1/5W-52RE-AX C00001006P520S 1
R4011 963125010100S 10-J 2W, R-REEL C060010066050S 1
R4012 nsp 10-J,1/5W-52RE-AX C00001006P520S 1
R4013 963125010100S 10-J 2W, R-REEL C060010066050S 1
R4014 nsp 10-J,1/5W-52RE-AX C00001006P520S 1
R4015 963125010100S 10-J 2W, R-REEL C060010066050S 1
R4016 nsp 100-J,1/5W-52RE-AX C00001016P520S 1
R4017-4020 nsp 20-J,1/5W-52RE-AX C00002006P520S 4
R4025-4027 963125500070D 1.1K-J,1W-R.REEL C060011265050S 3
R4029 nsp 10K-J,1/4W-R.REEL C060103063050S 1
R4032 nsp JUMPER (0.6/52MM) L045084006040S 1
R4036-4038 nsp 470K-J,1/16W-1608REEL C20004746M160S 3
R4039,4040 nsp 82K-J,1/16W-1608REEL C20008236M160S 2
R4041 nsp 100-J,1/16W-1608REEL C20001016M160S 1
R4042 nsp 33-J,1/16W-1608REEL C20003306M160S 1
R4043 nsp 100-J,1/16W-1608REEL C20001016M160S 1
R4044,4045 nsp 470K-J,1/16W-1608REEL C20004746M160S 2
R4046 nsp 1K-J,1/16W-1608REEL
C20001026M160S 1
R4047 nsp 100-J,1/16W-1608REEL C20001016M160S 1
R4048 nsp 33-J,1/16W-1608REEL C20003306M160S 1
R4049 nsp 10K-J,1/16W-1608REEL C20001036M160S 1
R4052 nsp 470K-J,1/16W-1608REEL C20004746M160S 1
R4054,4055 nsp 0-J,1/10W-2012REEL C200000060200S 2
R4056 nsp 470K-J,1/16W-1608REEL C20004746M160S 1
R4057 nsp 100-J,1/16W-1608REEL C20001016M160S 1
R4058 nsp 10K-J,1/16W-1608REEL C20001036M160S 1
R4059 nsp 22K-J,1/16W-1608REEL C20002236M160S 1
R4060 nsp 330K-J,1/16W-1608REEL C20003346M160S 1
R4061 nsp 22K-J,1/16W-1608REEL C20002236M160S 1
R4062 nsp 10K-J,1/16W-1608REEL C20001036M160S 1
R4063 nsp 3.3K-J,1/16W-1608REEL C20003326M160S 1
R4064 nsp 1K-J,1/16W-1608REEL C20001026M160S 1
R4065 nsp 33K-J,1/16W-1608REEL C20003336M160S 1
R4066,4067 nsp 10K-J,1/16W-1608REEL C20001036M160S 2
R4069 963129501010S 0.01-J/5W W14*H18 9MM PITCH C144R01069000S 1 *
R4070 nsp 20-J,1/5W-52RE-AX C00002006P520S 1
R4708,4709 nsp 1K-J,1/16W-1608REEL C20001026M160S 2
R4710 nsp 0-J,1/16W-1608REEL C20000006M160S 1
R4711 nsp 1K-J,1/16W-1608REEL C20001026M160S 1
R4714 nsp 1K-J,1/16W-1608REEL C20001026M160S 1
CAPACIITORS GROUP
C4000 nsp MI-0.047UF-J/50V-5RE D020473167050S 1
C4002 963133501560S ST-0.022UF-J/100V-5RE MANUAL D02122306C050S 1
C4005 963133501560S ST-0.022UF-J/100V-5RE MANUAL D02122306C050S 1
C4006 nsp MI-0.047UF-J/50V-5RE D020473167050S 1
C4009 963133501560S ST-0.022UF-J/100V-5RE MANUAL D02122306C050S 1
C4011 nsp MI-0.047UF-J/50V-5RE D020473167050S 1
C4013 963133501560S ST-0.022UF-J/100V-5RE MANUAL D02122306C050S 1
C4015 963133501560S ST-0.022UF-J/100V-5RE MANUAL D02122306C050S 1
C4017 nsp MI-0.047UF-J/50V-5RE D020473167050S 1
C4019 963133501560S ST-0.022UF-J/100V-5RE MANUAL D02122306C050S 1
C4022 963133501560S ST-0.022UF-J/100V-5RE MANUAL D02122306C050S 1
C4023 nsp MI-0.047UF-J/50V-5RE D020473167050S 1
C4025 nsp MI-0.047UF-J/50V-5RE D020473167050S 1
C4027 nsp X7R)1000PF-K/50V-1608REEL E3/E1C/K D011102777160S 1
C4027 nsp C,CERAMIC CHIP HIK // X7R)0.1UF-K/50V-1608REEL E2/E1 D011104577160S 1
C4030 nsp MI-0.047UF-J/50V-5RE D020473167050S 1
C4032 nsp X7R)1000PF-K/50V-1608REEL E3/E1C/K D011102777160S 1
C4032 nsp C,CERAMIC CHIP HIK // X7R)0.1UF-K/50V-1608REEL E2/E1 D011104577160S 1
1

Denon AVR-S900W Specifications

General

Channels	7.2
HDMI Inputs	8
HDMI Outputs	2
Wi-Fi	Yes
Bluetooth	Yes
4K Ultra HD Pass-through	Yes
Dolby Atmos	Yes
DTS:X	No
HDMI Pass-Through	Yes
Input Impedance	47 kOhm
Input Sensitivity	200 mV
THD at rated output	0.08%
Signal-To-Noise Ratio	98 dB
DAC Resolution	24-bit / 192kHz
HDMI Switching	Yes
AirPlay	Yes
DLNA	Yes
Dimensions	17.1 x 6.6 x 13.3 inches
Power Output	90 W
Response Bandwidth	10Hz-100kHz
Output Impedance / Channel	6 Ohm
Inputs	HDMI
Outputs	HDMI
Supported Audio Formats	MP3, WMA, AAC, FLAC, WAV
Supported Video Formats	4K
Output Power / Channel	90W (8 ohms, 20Hz-20kHz, 0.08% THD)
