Denon AVR-S900W Service Manual

7CH_AMP
REF No. Part No. Part Name Remarks Q't
y
New
V
er
R467,468 00D9630345903 RSD-R1-2WJ-0.47 3.5*8.6 P=5MM SMALL R.REEL N113136647820S 2
R469 nsp 5.6K-J,1/16W-1608REEL C20005626M160S 1
R471 nsp 1.2K-J,1/5W-52RE-AX C00001226P520S 1
R473 nsp 33K-J,1/5W-52RE-AX C00003336P520S 1
R474,475 00D9630345903 RSD-R1-2WJ-0.47 3.5*8.6 P=5MM SMALL R.REEL N113136647820S 2
R476 nsp 2.7K-J,1/5W-52RE-AX C00002726P520S 1
R478 nsp 3.3K-J,1W-R.REEL C060033265050S 1
R479 nsp 560-J,1/5W-52RE-AX C00005616P520S 1
R480 nsp 470K-J,1/5W-52RE-AX C00004746P520S 1
R481 nsp 33K-J,1/5W-52RE-AX C00003336P520S 1
R482 nsp 220-J,1/5W-52RE-AX C00002216P520S 1
R483 963125012630S 22-J,1W-5REEL C060022065050S 1
R484 nsp 150-J,1/5W-52RE-AX C00001516P520S 1
R485,486 nsp 1.2K-J,1W-5REEL C060012265050S 2
R487 nsp 47-J,1W-R.REEL C060047065060S 1
R488 nsp 1.2K-J,1/5W-52RE-AX C00001226P520S 1
R489 nsp RSD-R0-1WJ-4.7K 3*9 P=5MM SMALL R.REEL N113135647230S 1
R490 nsp 100K-J,1/5W-52RE-AX C00001046P520S 1
R493 00D9630337908 33-J,1W-R.REEL C060033065050S 1
R494 963252100140D DHPTHF1608 471P 105T SMD PTC THERMISTOR F320471001050S 1
R495 nsp RSD-R0-1WJ-4.7K 3*9 P=5MM SMALL R.REEL N113135647230S 1
R496 nsp 150K-J,1/5W-52RE-AX C00001546P520S 1
R498 nsp 200K-J,1/5W-52RE-AX C00002046P520S 1
R499 963121006330M 47K-J,1/5W-52RE-AX C00004736P520S 1
R500,501 nsp 10K-J,1/16W-1608REEL C20001036M160S 2
R502 963125012630S 22-J,1W-5REEL C060022065050S 1
R503 nsp 22K-J,1/5W-52RE-AX C00002236P520S 1
R504 nsp 270K-J,1/16W-1608REEL C20002746M160S 1
R506 nsp 22K-J,1/5W-52RE-AX C00002236P520S 1
R507 nsp 220K-J,1/5W-52RE-AX C00002246P520S 1
R509 nsp 470-J,1/5W-52RE-AX C00004716P520S 1
R510 nsp 10K-J,1/16W-1608REEL C20001036M160S 1
R511,512 00D9630345903 RSD-R1-2WJ-0.47 3.5*8.6 P=5MM SMALL R.REEL N113136647820S 2
R513 nsp 5.6K-J,1/16W-1608REEL C20005626M160S 1
R514 nsp 1.2K-J,1/5W-52RE-AX C00001226P520S 1
R516 nsp 33K-J,1/5W-52RE-AX C00003336P520S 1
R517,518 00D9630345903 RSD-R1-2WJ-0.47 3.5*8.6 P=5MM SMALL R.REEL N113136647820S 2
R519 nsp 2.7K-J,1/5W-52RE-AX C00002726P520S 1
R520 nsp 220K-J,1/5W-52RE-AX C00002246P520S 1
R521 nsp 3.3K-J,1W-R.REEL C060033265050S 1
R522 nsp 560-J,1/5W-52RE-AX C00005616P520S 1
R523 nsp 470K-J,1/5W-52RE-AX C00004746P520S 1
R524 nsp 33K-J,1/5W-52RE-AX C00003336P520S 1
R525 nsp 220-J,1/5W-52RE-AX C00002216P520S 1
R526 963125012630S 22-J,1W-5REEL C060022065050S 1
R527 nsp 150-J,1/5W-52RE-AX C00001516P520S 1
R528,529 nsp 1.2K-J,1W-5REEL C060012265050S 2
R530 nsp 47-J,1W-R.REEL C060047065060S 1
R531 nsp 1.2K-J,1/5W-52RE-AX C00001226P520S 1
R532 nsp 100K-J,1/5W-52RE-AX C00001046P520S 1
R534 nsp RSD-R0-1WJ-4.7K 3*9 P=5MM SMALL R.REEL N113135647230S 1
R536 nsp 1.2K-J,1/5W-52RE-AX
C00001226P520S 1
R537 963252100140D DHPTHF1608 471P 105T SMD PTC THERMISTOR F320471001050S 1
R538 nsp RSD-R0-1WJ-4.7K 3*9 P=5MM SMALL R.REEL N113135647230S 1
R539 nsp 150K-J,1/5W-52RE-AX C00001546P520S 1
R541 nsp 200K-J,1/5W-52RE-AX C00002046P520S 1
R542 963121006330M 47K-J,1/5W-52RE-AX C00004736P520S 1
R543,544 nsp 10K-J,1/5W-52RE-AX C00001036P520S 2
R545 963125012630S 22-J,1W-5REEL C060022065050S 1
R546 nsp 22K-J,1/5W-52RE-AX C00002236P520S 1
R547 nsp 270K-J,1/16W-1608REEL C20002746M160S 1
R549 nsp 22K-J,1/5W-52RE-AX C00002236P520S 1
R551 00D9639005639 100-J,1W-R.REEL C060010165060S 1
R552 nsp 470-J,1/5W-52RE-AX C00004716P520S 1
R553 nsp 10K-J,1/16W-1608REEL C20001036M160S 1
R554,555 00D9630345903 RSD-R1-2WJ-0.47 3.5*8.6 P=5MM SMALL R.REEL N113136647820S 2
R556 nsp 5.6K-J,1/16W-1608REEL C20005626M160S 1
R557 nsp 1.2K-J,1/5W-52RE-AX C00001226P520S 1
R559 nsp 33K-J,1/5W-52RE-AX C00003336P520S 1
R560 nsp 2.7K-J,1/5W-52RE-AX C00002726P520S 1
R561,562 00D9630345903 RSD-R1-2WJ-0.47 3.5*8.6 P=5MM SMALL R.REEL N113136647820S 2
R564 nsp 3.3K-J,1W-R.REEL C060033265050S 1
R565 nsp 560-J,1/5W-52RE-AX C00005616P520S 1
R566 nsp 470K-J,1/5W-52RE-AX C00004746P520S 1
R567 nsp 33K-J,1/5W-52RE-AX C00003336P520S 1
R568 nsp 220-J,1/5W-52RE-AX C00002216P520S 1
R569 963125012630S 22-J,1W-5REEL C060022065050S 1
R570 nsp 150-J,1/5W-52RE-AX C00001516P520S 1
R571,572 nsp 1.2K-J,1W-5REEL C060012265050S 2
R573 nsp 47-J,1W-R.REEL C060047065060S 1
R574 nsp 1.2K-J,1/5W-52RE-AX C00001226P520S 1
R575 nsp 100K-J,1/5W-52RE-AX C00001046P520S 1
R577 nsp RSD-R0-1WJ-4.7K 3*9 P=5MM SMALL R.REEL N113135647230S 1
R580 963252100140D DHPTHF1608 471P 105T SMD PTC THERMISTOR F320471001050S 1
R581 nsp RSD-R0-1WJ-4.7K 3*9 P=5MM SMALL R.REEL N113135647230S 1
R582 nsp 150K-J,1/5W-52RE-AX C00001546P520S 1
R584 nsp 200K-J,1/5W-52RE-AX C00002046P520S 1
R585 963121006330M 47K-J,1/5W-52RE-AX C00004736P520S 1
R586,587 nsp 10K-J,1/16W-1608REEL C20001036M160S 2
R588 963125012630S 22-J,1W-5REEL C060022065050S 1
R589 nsp 22K-J,1/5W-52RE-AX C00002236P520S 1
R590 nsp 270K-J,1/16W-1608REEL C20002746M160S 1
R592 nsp 22K-J,1/5W-52RE-AX C00002236P520S 1
R595 nsp 470-J,1/5W-52RE-AX C00004716P520S 1
R596 nsp 10K-J,1/16W-1608REEL C20001036M160S 1
R597,598 00D9630345903 RSD-R1-2WJ-0.47 3.5*8.6 P=5MM SMALL R.REEL N113136647820S 2
R599 nsp 5.6K-J,1/16W-1608REEL C20005626M160S 1
R600 nsp 1.2K-J,1/5W-52RE-AX C00001226P520S 1
R602 nsp 33K-J,1/5W-52RE-AX C00003336P520S 1
R603,604 00D9630345903 RSD-R1-2WJ-0.47 3.5*8.6 P=5MM SMALL R.REEL N113136647820S 2
R605 nsp 2.7K-J,1/5W-52RE-AX C00002726P520S 1
R607 nsp 3.3K-J,1W-R.REEL C060033265050S 1
R608 nsp 560-J,1/5W-52RE-AX C00005616P520S 1
R609 nsp 470K-J,1/5W-52RE-AX C00004746P520S 1
R610 nsp 33K-J,1/5W-52RE-AX C00003336P520S 1
R611 nsp 220-J,1/5W-52RE-AX C00002216P520S 1
11

Denon AVR-S900W Specifications

General

Channels	7.2
HDMI Inputs	8
HDMI Outputs	2
Wi-Fi	Yes
Bluetooth	Yes
4K Ultra HD Pass-through	Yes
Dolby Atmos	Yes
DTS:X	No
HDMI Pass-Through	Yes
Input Impedance	47 kOhm
Input Sensitivity	200 mV
THD at rated output	0.08%
Signal-To-Noise Ratio	98 dB
DAC Resolution	24-bit / 192kHz
HDMI Switching	Yes
AirPlay	Yes
DLNA	Yes
Dimensions	17.1 x 6.6 x 13.3 inches
Power Output	90 W
Response Bandwidth	10Hz-100kHz
Output Impedance / Channel	6 Ohm
Inputs	HDMI
Outputs	HDMI
Supported Audio Formats	MP3, WMA, AAC, FLAC, WAV
Supported Video Formats	4K
Output Power / Channel	90W (8 ohms, 20Hz-20kHz, 0.08% THD)
