Denon AVR-S900W Service Manual

HDMI
REF No. Part No. Part Name Remarks Q't
y
New
V
er
C1598,1599 nsp X7R)0.01UF-K/25V-1005REEL D011103174101S 2
C1600 nsp X7R)0.1UF-K/16V-1005REEL D011104177101S 1
C1607 nsp X7R 0.15uF-K/10V-1608REEL D011154172160S 1
C1608 nsp X7R)0.012UF-K/50V-1608REEL D011123177161S 1
C1609 nsp X7R 0.15uF-K/10V-1608REEL D011154172160S 1
C1610 nsp X7R)0.012UF-K/50V-1608REEL D011123177161S 1
C1611,1612 nsp COG7PF-D/50V-1608REEL D010070117160S 2
C1613 nsp X7R)1000PF-K/50V-1005REEL D011102177101S 1
C1614 nsp X7R)0.1UF-K/16V-1005REEL D011104177101S 1
C1615 nsp X7R)1000PF-K/50V-1005REEL D011102177101S 1
C1616 nsp COG)33PF-J/50V-1005REEL D011330167101S 1
C1618 nsp X7R)0.1UF-K/16V-1005REEL D011104177101S 1
C1620 nsp X5R)10UF-K/16V-2012REEL GRM21BR61C106KE15L D011106573200S 1
C1629-1644 nsp X7R)0.1UF-K/16V-1005REEL D011104177101S 16
C1645 nsp X5R)10UF-K/16V-2012REEL GRM21BR61C106KE15L D011106573200S 1
C1654-1671 nsp X7R)0.1UF-K/16V-1005REEL D011104177101S 18
C1672 nsp X7R)1UF-K/10V-1608REEL D011105772161S 1
C1675 00D9630325402 470UF-MVG/6.3V,8.3*9.0*10 REEL (Z8158) SY D050471081200S 1
C1677,1678 nsp X7R)0.1UF-K/16V-1005REEL D011104177101S 2
C1680 963134501220S 470UF-M/6.3V,8*10 RVO-6V471MG10P2U-R2 ELNA D050471081330S 1
C1681 nsp X7R)0.1UF-K/16V-1005REEL D011104177101S 1
C1684,1685 nsp X7R)0.1UF-K/16V-1005REEL D011104177101S 2
C1686 nsp X5R)22UF-M/6.3V-2012REEL JMK212BJ226MG-T D011226581203S 1
C1687 nsp X7R)1UF-K/10V-1608REEL D011105772161S 1
C1688 nsp COG)5PF-C/50V-1005REEL D011050107101S 1
C1689 nsp X5R)22UF-M/6.3V-2012REEL JMK212BJ226MG-T D011226581203S 1
C1690 nsp X5R)10UF-K/16V-2012REEL GRM21BR61C106KE15L D011106573200S 1
C1691 00D9630338606 10UF-MVG/16V,3.3*3.7*5.2 REEL (Z8154) SY D050100083470S 1
C1693 nsp X7R)1UF-K/10V-1608REEL D011105772161S 1
C1694,1695 nsp X7R)0.1UF-K/16V-1005REEL D011104177101S 2
C1696 nsp X5R)22UF-M/6.3V-2012REEL JMK212BJ226MG-T D011226581203S 1
C1697 nsp COG)5PF-C/50V-1005REEL D011050107101S 1
C1698 nsp X5R)2.2UF-K/16V-1608REEL GRM188R61C225KE15D D011225573160S 1
C1699,1700 nsp X7R)0.1UF-K/16V-1005REEL D011104177101S 2
C1701 nsp X5R)22UF-M/6.3V-2012REEL JMK212BJ226MG-T D011226581203S 1
C1702 nsp X7R)1UF-K/10V-1608REEL D011105772161S 1
C1703 nsp X5R)10UF-K/16V-2012REEL GRM21BR61C106KE15L D011106573200S 1
C1704 00D9630338606 10UF-MVG/16V,3.3*3.7*5.2 REEL (Z8154) SY D050100083470S 1
C1705 nsp X7R)1UF-K/10V-1608REEL D011105772161S 1
C1707 nsp X7R)0.1UF-K/16V-1005REEL D011104177101S 1
C1708 nsp X7R0.015UF-K/50V-1608REEL D011153777160S 1
C1709,1710 nsp X7R)0.1UF-K/16V-1005REEL D011104177101S 2
C1713 nsp X7R)1000PF-K/50V-1005REEL D011102177101S 1
C1714 nsp X5R)22UF-M/6.3V-2012REEL JMK212BJ226MG-T D011226581203S 1
C1715 nsp COG)5PF-C/50V-1005REEL D011050107101S 1
C1717 nsp X7R)0.1UF-K/16V-1005REEL D011104177101S 1
C1718 nsp X5R)22UF-M/6.3V-2012REEL JMK212BJ226MG-T D011226581203S 1
C1719 nsp X7R)1UF-K/10V-1608REEL D011105772161S 1
C1720 nsp X5R)10UF-K/16V-2012REEL GRM21BR61C106KE15L D011106573200S 1
C1722 nsp X7R)0.1UF-K/16V-1005REEL D011104177101S 1
C1723 nsp X5R)22UF-M/6.3V-2012REEL JMK212BJ226MG-T D011226581203S 1
C1724 nsp COG)5PF-C/50V-1005REEL D011050107101S 1
C1726 nsp X7R)1UF-K/10V-1608REEL D011105772161S 1
C1727 nsp X7R)0.1UF-K/16V-1005REEL D011104177101S 1
C1728 nsp X5R)2.2UF-K/16V-1608REEL GRM188R61C225KE15D D011225573160S 1
C1729 nsp X7R)0.1UF-K/16V-1005REEL D011104177101S 1
C1730 nsp X5R)22UF-M/6.3V-2012REEL JMK212BJ226MG-T D011226581203S 1
C1731 nsp X7R)1UF-K/10V-1608REEL D011105772161S 1
C1732 nsp X5R)10UF-K/16V-2012REEL GRM21BR61C106KE15L D011106573200S 1
C1734 nsp X7R)0.1UF-K/16V-1005REEL D011104177101S 1
C1735 nsp X5R)22UF-M/6.3V-2012REEL JMK212BJ226MG-T D011226581203S 1
C1736 nsp COG)5PF-C/50V-1005REEL D011050107101S 1
C1737,1738 nsp X7R)0.1UF-K/16V-1005REEL D011104177101S 2
C1739 nsp X5R)22UF-M/6.3V-2012REEL JMK212BJ226MG-T D011226581203S 1
C1740 nsp X7R)1UF-K/10V-1608REEL D011105772161S 1
C1741 nsp X5R)10UF-K/16V-2012REEL GRM21BR61C106KE15L D011106573200S 1
C1744 nsp X5R)22UF-M/6.3V-2012REEL JMK212BJ226MG-T D011226581203S 1
C1745 nsp COG)5PF-C/50V-1005REEL D011050107101S 1
C1746,1747 nsp X7R)0.1UF-K/16V-1005REEL D011104177101S 2
C1749 nsp X7R)0.1UF-K/16V-1005REEL D011104177101S 1
C1750 nsp X5R)22UF-M/6.3V-2012REEL JMK212BJ226MG-T D011226581203S 1
C1751,1752 nsp X7R)0.1UF-K/16V-1005REEL D011104177101S 2
C1753 nsp X7R)1UF-K/10V-1608REEL D011105772161S 1
C1754 nsp X5R)22UF-M/6.3V-2012REEL JMK212BJ226MG-T D011226581203S 1
C1755 nsp COG)5PF-C/50V-1005REEL D011050107101S 1
C1756,1757 nsp X5R)10UF-K/16V-2012REEL GRM21BR61C106KE15L D011106573200S 2
C1758 nsp X7R)0.1UF-K/16V-1005REEL D011104177101S 1
C1759,1760 nsp X5R)22UF-M/6.3V-2012REEL JMK212BJ226MG-T D011226581203S 2
C1761,1762 nsp COG)5PF-C/50V-1005REEL D011050107101S 2
C1763,1764 nsp X5R)10UF-K/16V-2012REEL GRM21BR61C106KE15L D011106573200S 2
C1766,1767 nsp X7R)0.1UF-K/16V-1005REEL D011104177101S 2
C1769 00D9630338606 10UF-MVG/16V,3.3*3.7*5.2 REEL (Z8154) SY D050100083470S 1
C1770 nsp X5R)22UF-M/6.3V-2012REEL JMK212BJ226MG-T D011226581203S 1
C1771 nsp X7R)0.1UF-K/16V-1005REEL D011104177101S 1
C1773-1775 nsp X7R)0.1UF-K/16V-1005REEL D011104177101S 3
C1777 nsp X5R)22UF-M/6.3V-2012REEL JMK212BJ226MG-T D011226581203S 1
C1779 nsp X5R)22UF-M/6.3V-2012REEL JMK212BJ226MG-T D011226581203S 1
C1782,1783 nsp X7R)1UF-K/10V-1608REEL D011105772161S 2
C1784 nsp X7R)0.1UF-K/16V-1005REEL D011104177101S 1
C1785 nsp X7R)1UF-K/10V-1608REEL D011105772161S 1
C1787 nsp X5R)22UF-M/6.3V-2012REEL JMK212BJ226MG-T D011226581203S 1
C1788 nsp X7R)1UF-K/10V-1608REEL D011105772161S 1
C1789 nsp X7R)0.1UF-K/16V-1005REEL D011104177101S 1
C1790 nsp X5R)22UF-M/6.3V-2012REEL JMK212BJ226MG-T D011226581203S 1
C1791 nsp COG)5PF-C/50V-1005REEL D011050107101S 1
C1796 nsp X7R)0.1UF-K/16V-1005REEL D011104177101S 1
C1797 nsp X5R)10UF-K/16V-2012REEL GRM21BR61C106KE15L D011106573200S 1
C1802 nsp X7R)0.1UF-K/16V-1005REEL D011104177101S 1
C1807 nsp X7R)0.01UF-K/25V-1005REEL D011103174101S 1
C1826-1828 nsp X7R)1000PF-K/50V-1005REEL D011102177101S 3
C1852 nsp X7R)0.1UF-K/16V-1005REEL D011104177101S 1
C1973,1974 nsp X7R)4.7UF-K/6.3V-1608REEL D011475571160S 2
C1979,1980 nsp X7R)4.7UF-K/6.3V-1608REEL D011475571160S 2
C1989-1992 nsp X7R)4.7UF-K/6.3V-1608REEL D011475571160S 4
C1999,2000 nsp X7R)4.7UF-K/6.3V-1608REEL D011475571160S 2
C2002-2011 nsp X7R)0.1UF-K/16V-1005REEL D011104177101S 10
22

Denon AVR-S900W Specifications

General

Channels	7.2
HDMI Inputs	8
HDMI Outputs	2
Wi-Fi	Yes
Bluetooth	Yes
4K Ultra HD Pass-through	Yes
Dolby Atmos	Yes
DTS:X	No
HDMI Pass-Through	Yes
Input Impedance	47 kOhm
Input Sensitivity	200 mV
THD at rated output	0.08%
Signal-To-Noise Ratio	98 dB
DAC Resolution	24-bit / 192kHz
HDMI Switching	Yes
AirPlay	Yes
DLNA	Yes
Dimensions	17.1 x 6.6 x 13.3 inches
Power Output	90 W
Response Bandwidth	10Hz-100kHz
Output Impedance / Channel	6 Ohm
Inputs	HDMI
Outputs	HDMI
Supported Audio Formats	MP3, WMA, AAC, FLAC, WAV
Supported Video Formats	4K
Output Power / Channel	90W (8 ohms, 20Hz-20kHz, 0.08% THD)
