Denon AVR-S900W Service Manual

o
Ethernet 1st Boot Loader, Hardware ID :
FLD
E t h e r n e t F B L
Press the "
STATUS
" button.
FLD
* * * * * * - b d
Q0
Ethernet 2nd Boot Loader, Rhapsody Flag :
FLD
E t h e r n e t S B L
Press the "
STATUS
" button.
FLD
B * * * * * * * * * * * * - 0 A
Q1
Ethernet IMAGE :
FLD
E t h e r n e t I M G
Press the "
STATUS
" button.
FLD
I * * * * * * * * * * * *
Q2
Ethernet MAC ADDRESS information :
FLD
* N E T M A C A d d r e s s
Press the "
STATUS
" button.
FLD
* * * * * * - * * * * * *
Q3
BT MAC ADDRESS information :
FLD
* B T M A C A d d r e s s
Press the "
STATUS
" button.
FLD
* * * * * * - * * * * * *
22

Denon AVR-S900W Specifications

General

Channels	7.2
HDMI Inputs	8
HDMI Outputs	2
Wi-Fi	Yes
Bluetooth	Yes
4K Ultra HD Pass-through	Yes
Dolby Atmos	Yes
DTS:X	No
HDMI Pass-Through	Yes
Input Impedance	47 kOhm
Input Sensitivity	200 mV
THD at rated output	0.08%
Signal-To-Noise Ratio	98 dB
DAC Resolution	24-bit / 192kHz
HDMI Switching	Yes
AirPlay	Yes
DLNA	Yes
Dimensions	17.1 x 6.6 x 13.3 inches
Power Output	90 W
Response Bandwidth	10Hz-100kHz
Output Impedance / Channel	6 Ohm
Inputs	HDMI
Outputs	HDMI
Supported Audio Formats	MP3, WMA, AAC, FLAC, WAV
Supported Video Formats	4K
Output Power / Channel	90W (8 ohms, 20Hz-20kHz, 0.08% THD)
