Denon AVR-S900W Service Manual

1.5. Version Display in the Setup Menu
Follow the steps below to display the rmware information.
(1) Press the "
SETUP
" button on the remote control.
(2) Select "
General - Information - Firmware
".
The version information is displayed as a 12-digit number as shown in the screenshot below.
This 12-digit number comprises part of the version number of each device and module.
These version numbers correspond to the 12-digit number as shown below.
b
The rmware version numbers and this 12-digit version information are written in the Service Information.
General/Firmware
Version
XXXX - XXXX - XXXX
GUI Image
Main
Sub
0 0 3 8
Info display
1 2 0 0 - 8 3 8 2 - 6 7 7 3
DSP 8 4 0 2
A.PLD
V.PLD
2 8 0 1
3 4 0 7
GUI 6 8 1 0 0 0 1 6
6 8 1 0 0 0 2 8
E.FBL 0 9 0 3 1 1
E.SBL B 2 0 1 4 0 1 2 8 0 6 3 2
E.IMG I 2 0 1 4 0 4 1 7 0 0 3 7
The 1st digit from the right for DSP
The 1st digit from the right for A.PLD
The 1st digit from the right for IMG
The 2nd digit from the right for IMG
The 1st digit from the right for GUI
The 1st digit from the right for V.PLD
The 2nd digit from the right for Main
The 1th digit from the right for Main
The 2nd digit from the right for Sub
The 1st digit from the right for Sub
24

Denon AVR-S900W Specifications

General

Channels	7.2
HDMI Inputs	8
HDMI Outputs	2
Wi-Fi	Yes
Bluetooth	Yes
4K Ultra HD Pass-through	Yes
Dolby Atmos	Yes
DTS:X	No
HDMI Pass-Through	Yes
Input Impedance	47 kOhm
Input Sensitivity	200 mV
THD at rated output	0.08%
Signal-To-Noise Ratio	98 dB
DAC Resolution	24-bit / 192kHz
HDMI Switching	Yes
AirPlay	Yes
DLNA	Yes
Dimensions	17.1 x 6.6 x 13.3 inches
Power Output	90 W
Response Bandwidth	10Hz-100kHz
Output Impedance / Channel	6 Ohm
Inputs	HDMI
Outputs	HDMI
Supported Audio Formats	MP3, WMA, AAC, FLAC, WAV
Supported Video Formats	4K
Output Power / Channel	90W (8 ohms, 20Hz-20kHz, 0.08% THD)
