3.4.6. Audio system conrmation items
g. XX: See the block diagram of the g.XXth.
Paths conrmation item Display Settings Contents of conrmation Remarks
1
Analog ( pass )
A 0 1 : A N A L O G P A S S
Input Source: CBL/SAT
Input Mode: ANALOG xed
Sound mode: DIRECT
Amp assign: Surround Back
MAIN ZONE: ON
ZONE2: OFF
・Check the audio output.
・Check of Analog input ⇒ Speaker output.
Front L/R
(※ The input source can be switched to any source except CBL/SAT.)
2
DIGITAL
(MAIN)
A 0 2 : D I G I T A L
Input Source : CBL/SAT
Input Mode : DIGITAL xed
Sound mode: MULTI CH STEREO
Amp assign : Surround Back
Speaker Cong all Speaker=Small / SW=Yes(2ch)
MAIN ZONE ON
ZONE2 OFF
・Check the audio output.
・Check of Digital input ⇒ Speaker output.
Front L/R、 Center、 Surround L/R、Surround Back L/R
・Check of Digital(PCM) input ⇒ Preout output.
Front L/R、 Center、 Surround L/R、Surround Back L/R、Subwoofer
(※ The input source can be switched to any source except CBL/SAT.)
3
DIGITAL
(ZONE2)
A 0 3 : D I G I T A L - Z 2
Input Source : NETWORK
Input Mode : Auto
Sound mode: STEREO
Amp assign : ZONE2
MAIN ZONE: ON
ZONE2: ON
・Check the audio output.
・Digital(PCM) input ⇒ Speaker output
Surround Back (ZONE2) L/R
・Digital(PCM) input ⇒ Preout output
ZONE2 L/R
4
HDMI
A 0 5 : H D M I
Input Source : CBL/SAT
Input Mode : HDMI xed
Sound mode: STEREO
Amp assign : Surround Back
MAIN ZONE: ON
ZONE2: OFF
・Check the audio output.
・HDMI input ⇒ Speaker output.
Front L/R
(※ The input source can be switched to any source except CBL/SAT.)
5
Analog AD
(MAIN)
A 0 6 : A D
Input Source : CBL/SAT
Input Mode : Analog xed
Sound mode: MULTI CH STEREO
Vol -20dB
Amp assign : Surround Back
Speaker Cong all Speaker=Small / SW=Yes(2ch)
MAIN ZONE: ON
ZONE2: OFF
・Check the audio output.
・Check of Analog input ⇒ Speaker output.
Front L/R、 Center、 Surround L/R、Surround Back L/R
・Check of Analog input ⇒ Pre OUT.
Front L/R、 Center、 Surround L/R、Surround Back L/R、Subwoofer
(※ The input source can be switched to any source except CBL/SAT.)
(※ Volume -20dB is the value when Relative settings are used. The value is 60
when Absolute settings are used)
6
Analog Amp Assign
(Amp Assign: ZONE2)
A 0 7 : A S S I G N - Z 2
Input Source : CBL/SAT
Input Mode : Auto
Sound mode: STEREO
Z2 Source : Source
Vol -20dB
Amp assign : ZONE2
MAIN ZONE: ON
ZONE2: ON
・Check the audio output.
・Check of Analog input ⇒ Speaker output.
Surround Back(ZONE2) L/R
・Check of Analog input ⇒ Pre OUT.
ZONE2 L/R
(※ The input source can be switched to any source except CBL/SAT.)
(※ Volume -20dB is the value when Relative settings are used. The value is 60
when Absolute settings are used)
7
Analog Amp Assign
(Amp Assign: Bi-Amp)
AVR-X2100W Only
A 1 1 : A S S I G N - B i A M P
Input Source : CBL/SAT
Input Mode : Auto
Sound mode: MULTI CH STEREO
Amp assign : Bi-Amp
MAIN ZONE ON
ZONE2 OFF
・Check the audio output.
・Check of Analog input ⇒ Speaker output.
Surround Back L/R
(※ The input source can be switched to any source except CBL/SAT.)
(※ Volume -20dB is the value when Relative settings are used. The value is 60
when Absolute settings are used)
8
Front Height
A 1 4 : F R O N T H E I G H T
Input Source : CBL/SAT
Input Mode : Auto
Sound mode: MULTI CH STEREO
Vol -20dB
Amp assign : Front Height
MAIN ZONE ON
ZONE2 OFF
・Check the audio output.
・Check of Analog input ⇒ Speaker output.
Surround Back L/R
(※ The input source can be switched to any source except CBL/SAT.)
・Check of PREOUT output.
(※ Volume -20dB is the value when Relative settings are used. The value is 60
when Absolute settings are used)
g.07
g.08a
g.08b
g.09a
g.09b
g.10a
g.10b
g.11a
g.11b
g.12
g.13
g.14a
g.14b
29
