1.3. File structure on USB Memory
Copy the update les to the USB memory with the following structure:
USB memory root
Model Name Model Area Product ID
AVR-X2100WE3 NorthAmerica(E3) 000100680100
AVR-X2100WE2/E1 Europe(E2)/Asia(E1) 000100680200
AVR-X2100WE1C China(E1C) 000100680500
AVR-X2100WK Japan(JP) 000100680400
AVR-S900WE3 NorthAmerica(E3) 000100680700
+ rmwares
+ 000100XXXXXX
+ APLD.bin
+ DSP.bin
+ enc_update.xml
+ GUI.bin
+ IMG.bcd
+ MAIN.bin
+ SBL.bcd
+ SUB.bin
+ VPLD.bin
1.4. Insert the USB memory in the USB port.
NOTE
：
Remove the LAN cable from this unit when performing updates.
MASTER VOLUME
ONLINE
MEDIA
PLAYER
Blu-rayCB L /S A T
321 4
ZONE2
SOURC
E
DIMMER S T AT U S
SETUP MICAUX 1 - HDMI
QUICK SELECT
Download firmware in
USB flash drive.
61

Denon AVR-S900W Specifications

General

Channels	7.2
HDMI Inputs	8
HDMI Outputs	2
Wi-Fi	Yes
Bluetooth	Yes
4K Ultra HD Pass-through	Yes
Dolby Atmos	Yes
DTS:X	No
HDMI Pass-Through	Yes
Input Impedance	47 kOhm
Input Sensitivity	200 mV
THD at rated output	0.08%
Signal-To-Noise Ratio	98 dB
DAC Resolution	24-bit / 192kHz
HDMI Switching	Yes
AirPlay	Yes
DLNA	Yes
Dimensions	17.1 x 6.6 x 13.3 inches
Power Output	90 W
Response Bandwidth	10Hz-100kHz
Output Impedance / Channel	6 Ohm
Inputs	HDMI
Outputs	HDMI
Supported Audio Formats	MP3, WMA, AAC, FLAC, WAV
Supported Video Formats	4K
Output Power / Channel	90W (8 ohms, 20Hz-20kHz, 0.08% THD)
