Denon AVR-X1400H Service Manual

5. Network / Bluetooth / USB
5.1. Cannot connect to the network
Can the D3.3V output voltage
(3.3V) to [IC741 : DC-DC Conv.]
be conrmed?
Can the LEGO5V output voltage
(5V) to [Q7402 : FET-SW] be con-
rmed?
Can the voltage (5V) be conrmed between
[CN741 : 1pin]?
Is D5V_POWER [IC751 : 122pin
uCOM] "Hi" ?
Is NET5V_POWER [IC751 : 40pin
uCOM] "Hi" ?
The circuit of D5V_POWER be-
tween [IC751-IC741] are faulty.
The circuit of NET5V_POWER
between [IC751-Q7402] are
faulty.
The circuit around [IC741 : DC-
DC.Conv.] is faulty.
The circuit around [Q7402 :
FET-SW] is faulty.
TO "6. SMPS"
Can the NET3.3V output voltage
(3.3V) to [Q7404 : FET-SW] be
conrmed?
Is NET3V3_POWER [IC751 :
111pin uCOM] "Hi" ?
The circuit of NET3V3_POWER
between [IC751-Q7404] are
faulty.
The circuit around [Q7404 :
FET-SW] is faulty.
YES
YES
YES
YES
YES
NO NO
NO
NO
NO
NO
NO
YES
YES
YES
NO
NO
NO
NO
YES
YES
YES
Check the setting
Are the network settings of this unit correct?
Are peripheral devices such as the router and hub
connected to this unit correctly?
Are the router settings correct?
Set the IP address, etc. correctly.
When the static IP address is used, check that no
other devices have the same IP address and that
the subnet mask settings are correct.
Connect the peripheral devices correctly.
Check the instruction manual of the router and
congure the settings correctly.
Check that there are no connection restrictions by
MAC addresses, etc.
Is the LAN cable correctly inserted?
Insert the LAN cable correctly and then turn on
the power again.
Check the connection environment
Checking the unit
The circuit of Network Module is faulty.
Are the versions of the HEOS Version displayed in
Version Check Mode?
The Network Module software is faulty.
YES
NO
71
Caution in
servicing
Electrical Mechanical Repair Information Updating

Denon AVR-X1400H Specifications

General

Receiver type	Surround
Frequency range	20 - 20000 Hz
Pre-out channels	2 SW
Input sensitivity	200 mV
Pre-out connectivity	Yes
Audio output channels	7.2 channels
Signal-to-Noise Ratio (SNR)	98 dB
Total Harmonic Distortion (THD)	0.08 %
Power output per channel (1KHz@6 Ohm)	145 W
Power output per channel (20-20KHz@8 Ohm)	80 W
HDMI in	6
Digital audio coaxial in	0
Ethernet LAN (RJ-45) ports	1
Multichannel audio input type	RCA
Component video (YPbPr/YCbCr) in	2
Headphone connectivity	3.5 mm
Connectivity technology	Wired & Wireless
Speakers connectivity type	3.5mm
Audio formats supported	ALAC, DSD, FLAC, MP3, WAV
Display	VFL
HDCP version	2.2
Apple docking	No
Product color	Black
Audio decoders	DTS-HD Master Audio, DTS:X, Dolby Atmos, Dolby Surround
Volume control	Rotary
Center speaker impedance	16 Ω
AM band range	522 - 1611 kHz
FM band range	87.5 - 108 MHz
Supported radio bands	AM, FM
Internet radio services supported	Deezer, Napster, Pandora, SIRIUS Internet Radio, Spotify, Tidal, iHeartRadio
AC input voltage	230 V
AC input frequency	50 Hz
Power consumption (standby)	0.1 W
Power consumption (typical)	430 W
Supported video modes	720i, 720p, 960p, 1080i, 1080p, 2160p
Supported graphics resolutions	3840 x 2160
Certification	CE, EAC

Weight and Dimensions

Depth	339 mm
Width	434 mm
Height	151 mm
Weight	8500 g
