Denon AVR-X2000 Service Manual

DISASSEMBLY
• Disassemble in order of the arrow in the following gure.
• In the case of the re-assembling, assemble it in order of the reverse of the following ow.
• In the case of the re-assembling, observe "attention of assembling".
• If wire bundles are untied or moved to perform adjustment or replace parts etc., be sure to rearrange them neatly as
they were originally bundled or placed afterward.
Otherwise, incorrect arrangement can be a cause of noise generation.
FRONT PANEL ASSY
Refer to "DISASSEMBLY
1. FRONT PANEL ASSY"
and "EXPLODED VIEW"
PCB FRONT HDMI ASSY
(Ref. No. of EXPLODED VIEW : P1)
PCB USB ASSY
(Ref. No. of EXPLODED VIEW : P2)
PCB FRONT ASSY
(Ref. No. of EXPLODED VIEW : P3)
PCB FUNCTION ASSY
(Ref. No. of EXPLODED VIEW : P4)
PCB CNT ASSY
(Ref. No. of EXPLODED VIEW : P5)
PCB F/H_GUIDE ASSY
(Ref. No. of EXPLODED VIEW : P6)
RADIATOR ASSY
Refer to "DISASSEMBLY
7. RADIATOR ASSY"
and "EXPLODED VIEW"
PCB AMP ASSY
(Ref. No. of EXPLODED VIEW : P7)
PCB GUIDE R
(Ref. No. of EXPLODED VIEW : P17)
PCB TOP_GUIDE
(Ref. No. of EXPLODED VIEW : P18)
POWER TRANS MAIN
Refer to "DISASSEMBLY
4. POWER TRANS MAIN"
and "EXPLODED VIEW"
POWER TRANS
(Ref. No. of EXPLODED VIEW : 13)
TOP COVER
PCB HDMI
Refer to "DISASSEMBLY
3. PCB HDMI"
and "EXPLODED VIEW"
PCB HDMI ASSY
(Ref. No. of EXPLODED VIEW : P13)
PCB MX PORT/PCB RS232C
(AVR-X2000E3 only)
Refer to "DISASSEMBLY
2. PCB MX PORT/PCB RS232C"
and "EXPLODED VIEW"
PCB RS232C ASSY
(Ref. No. of EXPLODED VIEW : P14)
PCB MX PORT ASSY
(Ref. No. of EXPLODED VIEW : P15)
PCB VIDEO ASSY
Refer to "DISASSEMBLY
5. PCB VIDEO ASSY"
and "EXPLODED VIEW"
PCB MAIN ASSY
(Ref. No. of EXPLODED VIEW : P9)
PCB INPUT ASSY
(Ref. No. of EXPLODED VIEW : P10)
PCB FRONT CNT ASSY
(Ref. No. of EXPLODED VIEW : P11)
PCB VIDEO ASSY
(Ref. No. of EXPLODED VIEW : P12)
BACK CHASSIS
PCB SMPS
Refer to "DISASSEMBLY
6. PCB SMPS"
and "EXPLODED VIEW"
PCB SMPS ASSY
(Ref. No. of EXPLODED VIEW : P8)
12

Denon AVR-X2000 Specifications

General

Receiver type	-
Frequency range	10 - 100000 Hz
Output impedance	16 Ω
Input sensitivity	200 mV
Audio output channels	7.1 channels
Signal-to-Noise Ratio (SNR)	100 dB
Power output per channel (1KHz@6 Ohm)	125 W
Power output per channel (20-20KHz@8 Ohm)	95 W
HDMI in	7
AC (power) in	Yes
Audio (L/R) in	4
Composite video in	2
Component video (YPbPr/YCbCr) in	1
Connectivity technology	Wired
Speakers connectivity type	Banana connector
Audio formats supported	AAC, FLAC, MP3, WAV, WMA
Image formats supported	JPG
Wi-Fi	No
RDS features	PTY, TP
FM band range	87.5 - 108 MHz
Supported radio bands	FM
Internet radio services supported	Spotify, vTuner
Supported video modes	1080i, 1080p, 480p, 576p, 720p
Display	VFL
Color depth	24 bit
Aspect ratio	4:3, 16:9
Product color	Black
Audio decoders	Dolby Digital, Dolby Digital EX, Dolby Digital Plus, Dolby Pro Logic IIx, Dolby Pro Logic IIz, Dolby TrueHD, DTS, DTS-ES, DTS-HD, DTS-HD Master Audio
USB 2.0 ports quantity	USB 2.0 ports have a data transmission speed of 480 Mbps, and are backwards compatible with USB 1.1 ports. You can connect all kinds of peripheral devices to them.
Apple docking compatibility	Not supported
AC input voltage	230 V
AC input frequency	50 - 60 Hz
Power consumption (standby)	0.1 W
Power consumption (typical)	500 W

Weight and Dimensions

Depth	330 mm
Width	434 mm
Height	167 mm
Weight	9500 g
