Denon AVR-X2000 Service Manual

YES
YES
YES
NO
NO
NO
NO
NO
NO
YES
YES
No picture or sound is output.
Check BD/DVD player.
Check HDMI/DVI cable connection.
(1) Is the HDMI/DVI cable properly connected?
(3) Are you using a certied HDMI cable (with the HDMI stamp)?
(4) Are you using an HDMI/DVI cable less than 5 meters in length?
(5) Are the picture and sound output when another HDMI/DVI
cable is used?
(2) Are you using an HDMI/DVI selector, repeater or a device for
improving picture quality?
(6) Is the BD/DVD player's HDMI output setting correct?
(8) Are the picture and sound
output when the BD/DVD
player's resolution is changed?
(10) Are the picture and sound
output when a different
BD/DVD player is used?
(7) When you use a DENON BD/DVD player, is the uorescent
display tube's "HDMI" indicator lit? If you use a non-DENON
BD/DVD player, proceed to "YES".
(9) Is sound output from the set's speaker terminals when the TV's
power is turned off or the connection cable between the TV and
the set is disconnected?
There may be the a problem with the HDMI/
DVI cable. Check connection.
Use a certied HDMI cable (with the HDMI
stamp).
Replace the HDMI/DVI cable with one that
is less than 5 meters in length (2 meters
recommended) to check.
The HDMI/DVI cable is defective.
Disconnect everything and connect only the
HDMI/DVI cable to check
Check the HDMI output setting, referring to
the BD/DVD player operating instructions.
Set the BD/DVD player output resolution to
a resolution with which the TV is compatible.
The BD/DVD player is defective.
The BD/DVD player may not be compatible
with HDCP repeaters. Ask the BD/DVD
player's manufacturer.
NO
NO
NO
YES
NO
YES
YES
YES
YES
3. HDMI/DVI
3.1. No picture or sound is output (HDMI to HDMI)
87

Denon AVR-X2000 Specifications

General

Receiver type	-
Frequency range	10 - 100000 Hz
Output impedance	16 Ω
Input sensitivity	200 mV
Audio output channels	7.1 channels
Signal-to-Noise Ratio (SNR)	100 dB
Power output per channel (1KHz@6 Ohm)	125 W
Power output per channel (20-20KHz@8 Ohm)	95 W
HDMI in	7
AC (power) in	Yes
Audio (L/R) in	4
Composite video in	2
Component video (YPbPr/YCbCr) in	1
Connectivity technology	Wired
Speakers connectivity type	Banana connector
Audio formats supported	AAC, FLAC, MP3, WAV, WMA
Image formats supported	JPG
Wi-Fi	No
RDS features	PTY, TP
FM band range	87.5 - 108 MHz
Supported radio bands	FM
Internet radio services supported	Spotify, vTuner
Supported video modes	1080i, 1080p, 480p, 576p, 720p
Display	VFL
Color depth	24 bit
Aspect ratio	4:3, 16:9
Product color	Black
Audio decoders	Dolby Digital, Dolby Digital EX, Dolby Digital Plus, Dolby Pro Logic IIx, Dolby Pro Logic IIz, Dolby TrueHD, DTS, DTS-ES, DTS-HD, DTS-HD Master Audio
USB 2.0 ports quantity	USB 2.0 ports have a data transmission speed of 480 Mbps, and are backwards compatible with USB 1.1 ports. You can connect all kinds of peripheral devices to them.
Apple docking compatibility	Not supported
AC input voltage	230 V
AC input frequency	50 - 60 Hz
Power consumption (standby)	0.1 W
Power consumption (typical)	500 W

Weight and Dimensions

Depth	330 mm
Width	434 mm
Height	167 mm
Weight	9500 g
