Denon AVR-X2000 Service Manual

Input
COMPONENT
C
Check on set value of each IC.
Is they the following voltage
values?
HDMI B'D
N3404-3pin : L(0V)
N3404-6pin : H(5V)
Is the power supply voltage
correctly output?
V+5V : C5003 : + side
V-5V : C5002 : - side
Is the signal output from the
video amplier?
COMP-Y : J5033
COMP-CB : CN5000 10pin
COMP-CR : J5035
Check power supply voltage of
IC5003, and surrounding circuitry
soldering.
Check FRONT CONNECTOR
B'D aw, and connection of
FRONT CONNECTOR B'D or
HDMI B'D and VIDEO B'D.
Is the signal input to video amplier?
COMP-Y : C5017 : + side
COMP-CB : C5018 : + side
COMP-CR : C5021 : + side
Check cable between main unit and
player or check player.
Extend HDMI B'D using a jig.
HDMI B'D aw.
Check connection of FRONT
CONNECTOR BD and VIDEO BD.
NO
NO
NO
NO
YES
YES
YES
YES
b
Unless specied, VIDEO B'D part.
w
q
e
r
86

Denon AVR-X2000 Specifications

General

Receiver type	-
Frequency range	10 - 100000 Hz
Output impedance	16 Ω
Input sensitivity	200 mV
Audio output channels	7.1 channels
Signal-to-Noise Ratio (SNR)	100 dB
Power output per channel (1KHz@6 Ohm)	125 W
Power output per channel (20-20KHz@8 Ohm)	95 W
HDMI in	7
AC (power) in	Yes
Audio (L/R) in	4
Composite video in	2
Component video (YPbPr/YCbCr) in	1
Connectivity technology	Wired
Speakers connectivity type	Banana connector
Audio formats supported	AAC, FLAC, MP3, WAV, WMA
Image formats supported	JPG
Wi-Fi	No
RDS features	PTY, TP
FM band range	87.5 - 108 MHz
Supported radio bands	FM
Internet radio services supported	Spotify, vTuner
Supported video modes	1080i, 1080p, 480p, 576p, 720p
Display	VFL
Color depth	24 bit
Aspect ratio	4:3, 16:9
Product color	Black
Audio decoders	Dolby Digital, Dolby Digital EX, Dolby Digital Plus, Dolby Pro Logic IIx, Dolby Pro Logic IIz, Dolby TrueHD, DTS, DTS-ES, DTS-HD, DTS-HD Master Audio
USB 2.0 ports quantity	USB 2.0 ports have a data transmission speed of 480 Mbps, and are backwards compatible with USB 1.1 ports. You can connect all kinds of peripheral devices to them.
Apple docking compatibility	Not supported
AC input voltage	230 V
AC input frequency	50 - 60 Hz
Power consumption (standby)	0.1 W
Power consumption (typical)	500 W

Weight and Dimensions

Depth	330 mm
Width	434 mm
Height	167 mm
Weight	9500 g
