Denon AVR-X2000 Service Manual

3. Service Related Selection mode
3.1. Behaviorspecications
In this mode, you can switch between the Diagnostic mode (SERVICE CHECK), the Displaying the protection mode
(PROTECTION) and the 232C clear mode (RS232C RESET).
3.2. Starting up
Press the "Power operation (
X
)" button to turn on power while pressing the "ZONE2 SOURCE", "DIMMER" and
"STATUS" buttons.
Press the "TUNER PRESET CH +" button ("SOURCE SELECT" button for AVR-E400) to select the mode and press the
"STATUS" button to restart the set and make the setting take effect.
q
FLD
1 . S E R V I C E C H E C K
This mode is used for conrming the Video and Audio (signal) paths.
(Diagnostic mode)The signal paths of the set can be easily conrmed
after repair.
w
FLD
2 . P R O T E C T I O N
The protection history can be checked.
e
AVR-X2000E3 Only
FLD
3 . R S 2 3 2 C R E S E T
The 232C standby mode is changed to the Normal standby mode.
r
FLD
4 . 0 P I N F O
The operation information about the set can be checked.
3.3. Canceling diagnostic mode
Turn off the power by pressing the "Power operation (
X
)" button.
29

Denon AVR-X2000 Specifications

General

Receiver type	-
Frequency range	10 - 100000 Hz
Output impedance	16 Ω
Input sensitivity	200 mV
Audio output channels	7.1 channels
Signal-to-Noise Ratio (SNR)	100 dB
Power output per channel (1KHz@6 Ohm)	125 W
Power output per channel (20-20KHz@8 Ohm)	95 W
HDMI in	7
AC (power) in	Yes
Audio (L/R) in	4
Composite video in	2
Component video (YPbPr/YCbCr) in	1
Connectivity technology	Wired
Speakers connectivity type	Banana connector
Audio formats supported	AAC, FLAC, MP3, WAV, WMA
Image formats supported	JPG
Wi-Fi	No
RDS features	PTY, TP
FM band range	87.5 - 108 MHz
Supported radio bands	FM
Internet radio services supported	Spotify, vTuner
Supported video modes	1080i, 1080p, 480p, 576p, 720p
Display	VFL
Color depth	24 bit
Aspect ratio	4:3, 16:9
Product color	Black
Audio decoders	Dolby Digital, Dolby Digital EX, Dolby Digital Plus, Dolby Pro Logic IIx, Dolby Pro Logic IIz, Dolby TrueHD, DTS, DTS-ES, DTS-HD, DTS-HD Master Audio
USB 2.0 ports quantity	USB 2.0 ports have a data transmission speed of 480 Mbps, and are backwards compatible with USB 1.1 ports. You can connect all kinds of peripheral devices to them.
Apple docking compatibility	Not supported
AC input voltage	230 V
AC input frequency	50 - 60 Hz
Power consumption (standby)	0.1 W
Power consumption (typical)	500 W

Weight and Dimensions

Depth	330 mm
Width	434 mm
Height	167 mm
Weight	9500 g
