Denon AVR-X2000 Service Manual

23
J X3
J X3
K X3
AVR X2000BKE3/BKE2
J X2
(INLET)
(SCREW : 1500-04008-3B1-0S)
L
K
1
2
4
6
7
8
9
5
10
P1
P2
P3
P4
P5
P6
11
6
AVR X2000BKE3
AVR X2000BKE2/K
AVR X2000SPE1C
12
13
15 X4
16 X4
14
17
18
19
20
21 X3
P7
B x4
A x6
A X2
A x2
G x4
A
H X21
A
A X5
D x6
A
A X2
A
I
24
A
P17
P18
A
25
26
27
27
2
28
HDMI JACK/TUNER PACK/M3 BRACKET
30
30
31
32
A X29
(FRONT PCB&FUNCTION PCB
H/P PCB&USB PCB&FRONT HDMI PCB&SUB PANEL+FRONT PANEL)
22
P8
A
A
P13
P12
P9
A X2
P10
P14
P11
P15
A X6
33
25X2
34
34
34
28
28
AVR X2000BKE3
AVR X2000E2/K/SPE1C
28
AVR X2000BKE3
Cautions when replacing the FRONT PANEL (Only AVR X2000E3)f
Depending on when the model was manufactured, there may be washers in the
FRONT PANEL screw positions. Washers are not used in the replacement FRONT
PANEL.If you are replacing a FRONT PANEL that has washers, discard the washers.
This caution does not apply to
models that are not originally
fitted with washers.
EXPLODED VIEW
WARNING:
Parts marked with this symbol
z
have critical characteristics.
Use ONLY replacement parts recommended by the manufacturer.
143

Denon AVR-X2000 Specifications

General

Receiver type	-
Frequency range	10 - 100000 Hz
Output impedance	16 Ω
Input sensitivity	200 mV
Audio output channels	7.1 channels
Signal-to-Noise Ratio (SNR)	100 dB
Power output per channel (1KHz@6 Ohm)	125 W
Power output per channel (20-20KHz@8 Ohm)	95 W
HDMI in	7
AC (power) in	Yes
Audio (L/R) in	4
Composite video in	2
Component video (YPbPr/YCbCr) in	1
Connectivity technology	Wired
Speakers connectivity type	Banana connector
Audio formats supported	AAC, FLAC, MP3, WAV, WMA
Image formats supported	JPG
Wi-Fi	No
RDS features	PTY, TP
FM band range	87.5 - 108 MHz
Supported radio bands	FM
Internet radio services supported	Spotify, vTuner
Supported video modes	1080i, 1080p, 480p, 576p, 720p
Display	VFL
Color depth	24 bit
Aspect ratio	4:3, 16:9
Product color	Black
Audio decoders	Dolby Digital, Dolby Digital EX, Dolby Digital Plus, Dolby Pro Logic IIx, Dolby Pro Logic IIz, Dolby TrueHD, DTS, DTS-ES, DTS-HD, DTS-HD Master Audio
USB 2.0 ports quantity	USB 2.0 ports have a data transmission speed of 480 Mbps, and are backwards compatible with USB 1.1 ports. You can connect all kinds of peripheral devices to them.
Apple docking compatibility	Not supported
AC input voltage	230 V
AC input frequency	50 - 60 Hz
Power consumption (standby)	0.1 W
Power consumption (typical)	500 W

Weight and Dimensions

Depth	330 mm
Width	434 mm
Height	167 mm
Weight	9500 g
