Denon AVR-X2000 Service Manual

+20dB
+10dB
0dB
-20dB
-30dB
-40dB
-10dB
+20dB
+10dB
0dB
-20dB
-30dB
-40dB
-10dB
LINE IN
-10dBFS
0dBFS=1.06Vrms
-20dBFS
-30dBFS
-40dBFS
A/D IN
50mVrms
(-26.5dBFS)
0dBFS
1.41Vrms
PCM9211
H/POUT
79.6mVrms
AVR-E400/X2000
LEVEL DIAGRAM
FRONT ch
-12dB
-
2.0dB
-
35dB
0dBFS
-10dBFS
-20dBFS
-30dBFS
-40dBFS
200mV
+30dB
SP OUT
4.48Vrms/8Ω
+
29dB
-
2+6.5=+4.5dB
M
AX SIGNAL LEVEL
DOLBY LIMIT LEVEL (ALLch-3dBFS)
MASTER VOL 00dB時のGAIN設定
･SW:YES時(DIGITAL) -2dB =-2.0dB
･SW:YES時(ANALOG) -2dB+ 6.5dB=+4.5dB
･SW:NONE時(DIGITAL) -2dB+12dB =10.0dB
･SW:NONE時(ANALOG) -2dB+12dB+6.5dB=16.5dB
① ② ③
①:VOL=0dB(表示値)時の基本OFFSET
②:SW NON時のOFFSET
③:AD入力時のOFFSET
-2+12=10.0dB
-2+12+6.5=16.5dB
+3dB
SW NO
-32dBFS(DIG.IN)
-38.5dBFS(A/D IN)
-20dBFS(DIG.IN)
-26.5dBFS(A/D IN)
＋
＋
LINE IN
H/POUT
＋
SPEAKER
DSP
ANALOG
R2A15218FP
GAIN
ZONE2
(AVRX2000 ONLY)
PCM1690
D/A
－
－
＋
PLD
PCM9211
A/D
PCM1690
+3dB
LEVEL DIAGRAM
99

Denon AVR-X2000 Specifications

General

Receiver type	-
Frequency range	10 - 100000 Hz
Output impedance	16 Ω
Input sensitivity	200 mV
Audio output channels	7.1 channels
Signal-to-Noise Ratio (SNR)	100 dB
Power output per channel (1KHz@6 Ohm)	125 W
Power output per channel (20-20KHz@8 Ohm)	95 W
HDMI in	7
AC (power) in	Yes
Audio (L/R) in	4
Composite video in	2
Component video (YPbPr/YCbCr) in	1
Connectivity technology	Wired
Speakers connectivity type	Banana connector
Audio formats supported	AAC, FLAC, MP3, WAV, WMA
Image formats supported	JPG
Wi-Fi	No
RDS features	PTY, TP
FM band range	87.5 - 108 MHz
Supported radio bands	FM
Internet radio services supported	Spotify, vTuner
Supported video modes	1080i, 1080p, 480p, 576p, 720p
Display	VFL
Color depth	24 bit
Aspect ratio	4:3, 16:9
Product color	Black
Audio decoders	Dolby Digital, Dolby Digital EX, Dolby Digital Plus, Dolby Pro Logic IIx, Dolby Pro Logic IIz, Dolby TrueHD, DTS, DTS-ES, DTS-HD, DTS-HD Master Audio
USB 2.0 ports quantity	USB 2.0 ports have a data transmission speed of 480 Mbps, and are backwards compatible with USB 1.1 ports. You can connect all kinds of peripheral devices to them.
Apple docking compatibility	Not supported
AC input voltage	230 V
AC input frequency	50 - 60 Hz
Power consumption (standby)	0.1 W
Power consumption (typical)	500 W

Weight and Dimensions

Depth	330 mm
Width	434 mm
Height	167 mm
Weight	9500 g
