Denon AVR-X2000 Service Manual

4. AUDIO
4.1. AUDIO CHECK
Audio output NG.
Check ANALOG audio BLOCK.
Check Digital audio BLOCK.
Check ADC BLOCK
Check HDMI BLOCK.
Check other factors.
Check HDMI BLOCK.
Check Digital audio BLOCK
CHECK1 INPUT SURROND MODE SOURCE
Audio output OK? ANALOG 2CH DIRECT ANALOG
CHECK2 INPUT SURROND MODE SOURCE
Audio output OK? COAX or OPT Don't care
Legacy
(PCM or DolbyDigital or dts…)
CHECK4 INPUT SURROND MODE SOURCE
Audio output OK? HDMI Don't care
Legacy
(PCM2ch or DolbyDigital or dts…)
CHECK6 INPUT Connect
AVR's (connected in HDMI) audio
output OK?
HDMI This unit's HDMI OUT → Other AVR's HDMI IN
Setting SURROND MODE SOURCE
CEC STANDBY Don't care HBR audio(DolbyTrueHD or dtsHD MA)
CHECK5 INPUT SURROND MODE SOURCE
Audio output OK? HDMI Don't care
HBR audio
(DolbyTrueHD or dtsHD MA)
CHECK3 INPUT SURROND MODE SOURCE
Audio output OK? ANALOG 2CH MULTICH STEREO ANALOG
YES
YES
YES
YES
YES
NO
NO
YES (Digital audio Block is OK)
NO
NO
NO
NO
89

Denon AVR-X2000 Specifications

General

Receiver type	-
Frequency range	10 - 100000 Hz
Output impedance	16 Ω
Input sensitivity	200 mV
Audio output channels	7.1 channels
Signal-to-Noise Ratio (SNR)	100 dB
Power output per channel (1KHz@6 Ohm)	125 W
Power output per channel (20-20KHz@8 Ohm)	95 W
HDMI in	7
AC (power) in	Yes
Audio (L/R) in	4
Composite video in	2
Component video (YPbPr/YCbCr) in	1
Connectivity technology	Wired
Speakers connectivity type	Banana connector
Audio formats supported	AAC, FLAC, MP3, WAV, WMA
Image formats supported	JPG
Wi-Fi	No
RDS features	PTY, TP
FM band range	87.5 - 108 MHz
Supported radio bands	FM
Internet radio services supported	Spotify, vTuner
Supported video modes	1080i, 1080p, 480p, 576p, 720p
Display	VFL
Color depth	24 bit
Aspect ratio	4:3, 16:9
Product color	Black
Audio decoders	Dolby Digital, Dolby Digital EX, Dolby Digital Plus, Dolby Pro Logic IIx, Dolby Pro Logic IIz, Dolby TrueHD, DTS, DTS-ES, DTS-HD, DTS-HD Master Audio
USB 2.0 ports quantity	USB 2.0 ports have a data transmission speed of 480 Mbps, and are backwards compatible with USB 1.1 ports. You can connect all kinds of peripheral devices to them.
Apple docking compatibility	Not supported
AC input voltage	230 V
AC input frequency	50 - 60 Hz
Power consumption (standby)	0.1 W
Power consumption (typical)	500 W

Weight and Dimensions

Depth	330 mm
Width	434 mm
Height	167 mm
Weight	9500 g
