Denon AVR-X2000 Service Manual

YES
YES
YES
YES
Check TV
(11) Is the TV HDCP-compatible?
(13) Is the TV's input set to HDMI?
(14) Are the picture and sound output when a different TV is used?
Check set (AV RECEIVER)
Please Check Firmware.
Is "IP SCALER NG" diplayed?
(Refer to 26 page)
(12) Is the TV compatible with resolutions of 1080P?
Use an HDCP-compatible TV. PC TVs cannot
be used.
Check the TV's input setting, referring to the
TV's operating instructions.
The TV is defective.
•Please check IP SCALER (U1601, HDMI B'D) and
DDR2(U1801/1802) and around circuits.
If no problem, U1601 or U1801/U1802 will be broken.
If the TV is not compatible with resolutions of
1080P, no picture will be output, even if the
BD/DVD player resolution is set to 1080P.
NO
NO
NO
YES
NO
Please refer to the "AVRE400_HDMI Rx-Tx Failure Detection
Procedure Manual ver_1.00" of SDI.
NO
88
