Denon AVR-X2000 Service Manual

5. Network/USB
5.1. Cannot connect to network
Checking the settings
YES
YES
YES
YES
Are the AVR-E400/X2000's network settings correct?
Are the router, hub and other peripherals properly connected?
Are the router's settings correct?
Set the IP address and other parameters
properly. For a xed IP setting, check
whether the IP address is redundant with
that of other devices and the subnet mask
setting is correct.
Connect them properly to peripherals.
Check the router's operating instructions
and set it properly.
Check whether there are connection
restrictions due to the MAC address, etc.
NO
NO
NO
YES
Is the LAN cable properly connected?
Turn off the power and check the LAN cable
properly, and then turn the power back on.
NO
Checking the environment
The U2802 and surrounding circuitry are defective.
Checking the set (AVR-E400/X2000)
YES
YES
YES
YES
Is output voltage (3.3V) supplied from U3601?
Is output voltage (1.2V) supplied from U3604?
Is the version of IMG or Ethernet SBL displayed in Version check
mode?
Is a voltage (5V) supplied between the pins 2 and 5 of N3601?
The U3601 and surrounding circuitry or
circuitry of 3.3V device are defective.
The U3604 or U2602 and surrounding
circuitry are defective.
The rmware of ethernet is defective.
The circuit from AC inlet to N3601 is defective.
NO
NO
NO
NO
92

Denon AVR-X2000 Specifications

General

Receiver type	-
Frequency range	10 - 100000 Hz
Output impedance	16 Ω
Input sensitivity	200 mV
Audio output channels	7.1 channels
Signal-to-Noise Ratio (SNR)	100 dB
Power output per channel (1KHz@6 Ohm)	125 W
Power output per channel (20-20KHz@8 Ohm)	95 W
HDMI in	7
AC (power) in	Yes
Audio (L/R) in	4
Composite video in	2
Component video (YPbPr/YCbCr) in	1
Connectivity technology	Wired
Speakers connectivity type	Banana connector
Audio formats supported	AAC, FLAC, MP3, WAV, WMA
Image formats supported	JPG
Wi-Fi	No
RDS features	PTY, TP
FM band range	87.5 - 108 MHz
Supported radio bands	FM
Internet radio services supported	Spotify, vTuner
Supported video modes	1080i, 1080p, 480p, 576p, 720p
Display	VFL
Color depth	24 bit
Aspect ratio	4:3, 16:9
Product color	Black
Audio decoders	Dolby Digital, Dolby Digital EX, Dolby Digital Plus, Dolby Pro Logic IIx, Dolby Pro Logic IIz, Dolby TrueHD, DTS, DTS-ES, DTS-HD, DTS-HD Master Audio
USB 2.0 ports quantity	USB 2.0 ports have a data transmission speed of 480 Mbps, and are backwards compatible with USB 1.1 ports. You can connect all kinds of peripheral devices to them.
Apple docking compatibility	Not supported
AC input voltage	230 V
AC input frequency	50 - 60 Hz
Power consumption (standby)	0.1 W
Power consumption (typical)	500 W

Weight and Dimensions

Depth	330 mm
Width	434 mm
Height	167 mm
Weight	9500 g
