Denon AVR-X2000 Service Manual

Checking the USB device
YES
Is the USB device compatible with the set?
Are you using a USB hub?
Only mass storage devices in FAT16 or
FAT32 format or MTPcompatible devices
and iPod (Remove some models) are
supported.
Don't use the USB hub.
NO
YES
NO
Checking the set (AVR-E400/X2000)
YES
YES
Is a voltage (5V) supplied between the pins 1 and 4 of CP4406 on the
USB board (USB connector)?
The circuitry from U2602 on the HDMI board to CP4406 on the USB
board is defective.
Is the wire properly connected between N2801 on the HDMI board
and CN4402 on the USB board.
The U2806 and surrounding circuitry on the
HDMI board are defective.
Connect the wire properly.
NO
NO
5.2. USBdeviceisnotrecognized
U2602 and surrounding circuitry are
defective.
Checking the set (AVR-E400/X2000):(If no picture is output)
Check the HDMI/DVI circuit.
Are digital video signals(BCLK, VD0 - VD7) output from U2602 to
U1601?
NO
Checking the set (AVR-E400/X2000):(If no sound is output)
YES
YES
YES
Are audio signals output to IC4200 pin 62 and 63?
Check the Analog audio circuit.
Are I2S signals output to U2401 pin 12, 13, 14, 15?
U2602 and surrounding circuitry are
defective.
U2401 and surrounding circuitry are
defective.
NO
NO
5.3. No picture or no sound is output
93

Denon AVR-X2000 Specifications

General

Receiver type	-
Frequency range	10 - 100000 Hz
Output impedance	16 Ω
Input sensitivity	200 mV
Audio output channels	7.1 channels
Signal-to-Noise Ratio (SNR)	100 dB
Power output per channel (1KHz@6 Ohm)	125 W
Power output per channel (20-20KHz@8 Ohm)	95 W
HDMI in	7
AC (power) in	Yes
Audio (L/R) in	4
Composite video in	2
Component video (YPbPr/YCbCr) in	1
Connectivity technology	Wired
Speakers connectivity type	Banana connector
Audio formats supported	AAC, FLAC, MP3, WAV, WMA
Image formats supported	JPG
Wi-Fi	No
RDS features	PTY, TP
FM band range	87.5 - 108 MHz
Supported radio bands	FM
Internet radio services supported	Spotify, vTuner
Supported video modes	1080i, 1080p, 480p, 576p, 720p
Display	VFL
Color depth	24 bit
Aspect ratio	4:3, 16:9
Product color	Black
Audio decoders	Dolby Digital, Dolby Digital EX, Dolby Digital Plus, Dolby Pro Logic IIx, Dolby Pro Logic IIz, Dolby TrueHD, DTS, DTS-ES, DTS-HD, DTS-HD Master Audio
USB 2.0 ports quantity	USB 2.0 ports have a data transmission speed of 480 Mbps, and are backwards compatible with USB 1.1 ports. You can connect all kinds of peripheral devices to them.
Apple docking compatibility	Not supported
AC input voltage	230 V
AC input frequency	50 - 60 Hz
Power consumption (standby)	0.1 W
Power consumption (typical)	500 W

Weight and Dimensions

Depth	330 mm
Width	434 mm
Height	167 mm
Weight	9500 g
