Denon AVR-X2000 Service Manual

3.4.DIAGNOSTICMODE(Video/Audio(signal)pathconrmationmode
3.4.1.Specication
This mode is used for conrming the Video and Audio (signal) paths. (Troubleshooting)
Conrming the operation of unit can be easily done after repair.
Backup data will not be lost.
3.4.2. Starting diagnostic mode
Press the "Power operation (
X
)" button to turn on power while pressing the "ZONE2 SOURCE" and "DIMMER" and "
STATUS
" buttons.
Select "1. SERVICE CHECK" and press "
STATUS
" to start the set in the Diagnostic mode.
In this mode, TUNED, STEREO and RDS are lit in FL display.
3.4.3. Canceling diagnostic mode
Turn off the power by pressing the "Power operation (
X
)" button.
3.4.4 Selecting items
Press
q
button to switch between video items and audio items.
Press
w
or
e
button to select previous or next items.
This unit remote controller
q w e q w e
audio
⇔
video previous next audio
⇔
video previous next
DIMMER QUICK SELECT 1 QUICK SELECT 2 SLEEP CURSOR LEFT CURSOR RIGHT
3.4.5Videosystemconrmationitems
g. XX: Refer to the block diagram of the g.XXth.
Conrmation item FL display settings Contents of conrmationRemarks
1
video convert
(analog or HDMI
⇒
HDMI)
V 0 2 : V . C O N V E R T
Input Source : CBL/SAT
Video Convert(IP Scaler) : ON, All sources
IP Scaler : "Analog&HDMI", All sources
Resolution : "Auto", All sources
MAIN ZONE ON
ZONE2 OFF
·CVBS input
⇒
IP Scaler
⇒
HDMI output
·Component input
⇒
IP Scaler
⇒
HDMI output
·HDMI input
⇒
IP Scaler
⇒
HDMI output
·ETHERNET input
⇒
IP Scaler
⇒
HDMI output
(* Input source can be switched.)
2
HDMI pass
(Main)
V 0 3 : H D M I P A S S
Input Source : CBL/SAT
Source of Video Convert(IP Scaler) : OFF, All sources
MAIN ZONE ON
ZONE2 OFF
·HDMI input
⇒
HDMI output
·Front HDMI input
⇒
HDMI output
(* Input source can be switched.)
3
HDMI CEC
V 0 4 : H D M I C E C
Input Source : CBL/SAT
HDMI Control : ON
MAIN ZONE ON
ZONE2 OFF
·When the power supply of a TV is put in the standby mode, make sure that the
power supply of this unit is also put in the standby mode.
·To check ARC path, switch the input source to "TV AUDIO".
(* Input source can be switched.)
4
HDMI audio
(audio: AVR)
V 0 5 : H . A U D I O - A V R
Input Source : CBL/SAT
HDMI Control : OFF
HDMI Audio : AVR
·HDMI input(PCM , DolbyDigital , DTS)
⇒
Speaker output
·HDMI input(HD audio)
⇒
Speaker output
(* Input source can be switched.)
5
HDMI audio
(audio: TV)
V 0 6 : H . A U D I O - T V
HDMI Audio : TV ·HDMI input(PCM , DolbyDigital , DTS)
⇒
HDMI output (audio output from
connected TV)
(* Input source can be switched.)
6
GUI menu
V 0 7 : G U I M E N U O N
Input Source : CBL/SAT
Video Convert(IP Scaler) : ON, All sources
IP Scaler : "Analog&HDMI", All sources
Resolution : "AUTO", All sources
Setup Menu ON
MAIN ZONE ON
ZONE2 OFF
·GUI display
⇒
HDMI output
(* Input source can be switched.)
g.1
g.2
g.3
g.4
g.5
g.6
30

Denon AVR-X2000 Specifications

General

Receiver type	-
Frequency range	10 - 100000 Hz
Output impedance	16 Ω
Input sensitivity	200 mV
Audio output channels	7.1 channels
Signal-to-Noise Ratio (SNR)	100 dB
Power output per channel (1KHz@6 Ohm)	125 W
Power output per channel (20-20KHz@8 Ohm)	95 W
HDMI in	7
AC (power) in	Yes
Audio (L/R) in	4
Composite video in	2
Component video (YPbPr/YCbCr) in	1
Connectivity technology	Wired
Speakers connectivity type	Banana connector
Audio formats supported	AAC, FLAC, MP3, WAV, WMA
Image formats supported	JPG
Wi-Fi	No
RDS features	PTY, TP
FM band range	87.5 - 108 MHz
Supported radio bands	FM
Internet radio services supported	Spotify, vTuner
Supported video modes	1080i, 1080p, 480p, 576p, 720p
Display	VFL
Color depth	24 bit
Aspect ratio	4:3, 16:9
Product color	Black
Audio decoders	Dolby Digital, Dolby Digital EX, Dolby Digital Plus, Dolby Pro Logic IIx, Dolby Pro Logic IIz, Dolby TrueHD, DTS, DTS-ES, DTS-HD, DTS-HD Master Audio
USB 2.0 ports quantity	USB 2.0 ports have a data transmission speed of 480 Mbps, and are backwards compatible with USB 1.1 ports. You can connect all kinds of peripheral devices to them.
Apple docking compatibility	Not supported
AC input voltage	230 V
AC input frequency	50 - 60 Hz
Power consumption (standby)	0.1 W
Power consumption (typical)	500 W

Weight and Dimensions

Depth	330 mm
Width	434 mm
Height	167 mm
Weight	9500 g
