Denon AVR-X2000 Service Manual

3.4.6Audiosystemconrmationitems
g. XX: Refer to the block diagram of the g.XXth.
Conrmation item FL display settings Contents of conrmationRemarks
1
analog pass
A 0 1 : A N A L O G P A S S
Input Source: CBL/SAT
Input Mode: ANALOG(xed)
Sound mode: DIRECT
Amp assign: Surround Back
MAIN ZONE: ON
ZONE2: OFF
·Analog input
⇒
Speaker output
(* Input source can be switched.)
2
digital
A 0 2 : D I G I T A L
Input Source : CBL/SAT
Input Mode : DIGITAL(xed)
Sound mode: MULTI CH STEREO
Amp assign : Surround Back
Speaker Cong:
all Speakers =Small
SW=Yes
·Digital input
⇒
Speaker output
(* Input source can be switched.)
3
digital
(ZONE2)
A 0 3 : D I G I T A L - Z 2
Input Source : NETWORK(xed)
Input Mode : Auto
Sound mode: STEREO
Amp assign : ZONE2
MAIN ZONE: ON
ZONE2: ON
·Digital(PCM) input
⇒
Speaker output
(ZONE2 L, R )
·Digital(PCM) input
⇒
Preout output
(ZONE2 L, R)
4
HDMI
A 0 5 : H D M I
Input Source : CBL/SAT
Input Mode : HDMI(xed)
Sound mode: STEREO
Amp assign : Surround Back
MAIN ZONE: ON
ZONE2: OFF
·HDMI input
⇒
Speaker output
(* Input source can be switched.)
5
analog A/D
(MAIN)
A 0 6 : A D
Input Source : CBL/SAT
Input Mode : Analog(xed)
Sound mode: MULTI CH STEREO
Amp assign : Surround Back
Speaker Cong:
all Speaker=Small/ SW=Yes
MAIN ZONE: ON
·Analog input
⇒
Speaker output
·Analog input
⇒
Pre OUT (SW)
(* Input source can be switched.)
6
analog amp assign
(Amp assign: ZONE2)
A 0 7 : A S S I G N - Z 2
Input Source : CBL/SAT
Input Mode : Auto
Sound mode: STEREO
Z2 Source : Source
Amp assign : ZONE2
MAIN ZONE: ON
ZONE2: ON
·Analog input
⇒
Speaker output
·Analog input
⇒
Pre OUT (ZONE2) AVR-X2000 only
(* Input source can be switched.)
7
analog amp assign
(amp assign: bi-amp)
(AVR-X2000 only)
A 1 1 : A S S I G N - B i A M P
Input Source : CBL/SAT
Input Mode : Auto
Sound mode: MULTI CH STEREO
Amp assign : Bi-Amp
MAIN ZONE ON
ZONE2 OFF
·Analog input
⇒
Speaker output
(* Input source can be switched.)
8
front height
A 1 4 : F R O N T H E I G H T
Input Source : CBL/SAT
Input Mode : Auto
Sound mode: MULTI CH STEREO
Amp assign : Front Height
MAIN ZONE ON
ZONE2 OFF
·Analog input
⇒
Speaker output
(* Input source can be switched.)
g.7
g.8
g.9
g.10
g.11
g.12
g.13
g.14
31

Denon AVR-X2000 Specifications

General

Receiver type	-
Frequency range	10 - 100000 Hz
Output impedance	16 Ω
Input sensitivity	200 mV
Audio output channels	7.1 channels
Signal-to-Noise Ratio (SNR)	100 dB
Power output per channel (1KHz@6 Ohm)	125 W
Power output per channel (20-20KHz@8 Ohm)	95 W
HDMI in	7
AC (power) in	Yes
Audio (L/R) in	4
Composite video in	2
Component video (YPbPr/YCbCr) in	1
Connectivity technology	Wired
Speakers connectivity type	Banana connector
Audio formats supported	AAC, FLAC, MP3, WAV, WMA
Image formats supported	JPG
Wi-Fi	No
RDS features	PTY, TP
FM band range	87.5 - 108 MHz
Supported radio bands	FM
Internet radio services supported	Spotify, vTuner
Supported video modes	1080i, 1080p, 480p, 576p, 720p
Display	VFL
Color depth	24 bit
Aspect ratio	4:3, 16:9
Product color	Black
Audio decoders	Dolby Digital, Dolby Digital EX, Dolby Digital Plus, Dolby Pro Logic IIx, Dolby Pro Logic IIz, Dolby TrueHD, DTS, DTS-ES, DTS-HD, DTS-HD Master Audio
USB 2.0 ports quantity	USB 2.0 ports have a data transmission speed of 480 Mbps, and are backwards compatible with USB 1.1 ports. You can connect all kinds of peripheral devices to them.
Apple docking compatibility	Not supported
AC input voltage	230 V
AC input frequency	50 - 60 Hz
Power consumption (standby)	0.1 W
Power consumption (typical)	500 W

Weight and Dimensions

Depth	330 mm
Width	434 mm
Height	167 mm
Weight	9500 g
