Pin Pin Name Symbol I/O

Pull up/

down

LvCnv STBY STOP

CEC

STBY

Function

PB1/A9/PO25/

TIOCA9/TIOCB9

D5V POWER O - - L L H

DIGITAL POWER SUPPLY (D5V)

control pin (ON:H)

86 P74/ADTRG3# DIR CE O - - L L L DIR control pin (PCM9211)

87 P73 DIR DIN O - - L L L DIR control pin (PCM9211)

88 P72 DIR DOUT I DA3VPu - I I I DIR control pin (PCM9211)

P71/CS4#-C/

CS5#-C/CS6#-C/

CS7#-C

DIR CLK O - - L L L DIR control pin (PCM9211)

P70/CS3#-B/

ADTRG2#

DIR RST O - - L L L DIR RESET pin (PCM9211)

91 VCC VCC - - - - - - +3.3V

PB0/A8/PO24/

TIOCA9

COMP SW2 O - 3->5 L L L

A-VIDEO (COMPONENT) switcher

control pin (NJM2586)

93 VSS VSS - - - - - - GND

PA7/A7/PO23/

TIOCA8/TIOCB8/

TCLKH

NC O/O - - L L L Unused

PA6/A6/PO22/

TIOCA8

VSEL A I - - I I I

Master Volume rotation detection

pin(Rotary encoder)

PA5/A5/PO21/

TIOCA7/TIOCB7/

TCLKG

VSEL B I - - I I I

Master Volume rotation detection

pin(Rotary encoder)

PA4/A4/PO20/

TIOCA7

NC O - - L L L Unused

PA3/A3/PO19/

TIOCC6/TIOCD6/

TCLKF

DAC(ETHER)

MUTE

O - - L L L

DAC (ETHER) MUTE control pin

(PCM5100 for DM860)

PA2/A2/PO18/

TIOCC6/TCLKE

PRE Z2 MUTE O - - L L L

Z2 PRE OUT MUTE control pin

(AVRX2000 Only)

100

PA1/A1/PO17/

TIOCA6/TIOCB6

CLK MUTE O - - L L L A.PLD MUTE control pin

101

PA0/A0/BC0#/PO16/

TIOCA6

PRE MUTE O - - L L L

Sub Woofer PRE OUT MUTE control

102 PE7/IRQ7-A/D15 ADV8003 INT2 I - - I I I HDMI TX INT2 input pin (ADV8003)

103 PE6/IRQ6-A/D14 ADV7850 INT1 I - - I I I HDMI RX INT1 input pin (ADV7850)

104 PE5/IRQ5-A/D13 ADV7850 INT2 I - - L L L HDMI RX INT2 input pin (ADV7850)

105 PE4/D12

ISEL

A(AVRX2000)/

NC(AVRE400)

I/O - - I/L I/L I/L

Input Selector rotation detection

pin(Rotary encoder) / Unused

(AVRE400)

106 PE3/D11

ISEL

B(AVRX2000)/

NC(AVRE400)

I/O - - I/L I/L I/L

Input Selector rotation detection

pin(Rotary encoder) / Unused

(AVRE400)

107 PE2/D10 VOL CLK O - - L L L

FUNCTION / VOLUME control pin

(R2A15218)

108 PE1/D9 VOL DATA O - - L L L

FUNCTION / VOLUME control pin

(R2A15218)

109 PE0/D8 PLD WRITE O - - L L L A.PLD /JTAG switching control pin

110 PD7/D7 JTAG TDO I - - L L L A.PLD rewriting control pin (JTAG)

111 PD6/D6

JTAG TMS/APLD

O/O - - L L L A.PLD rewriting & control pin

112 PD5/D5

JTAG TDI/APLD

DATA/DAC DATA

O/O - - L L L

A.PLD rewriting & control /DAC control

113 PD4/D4

JTAG TCK/APLD

CLK/DAC CLK

O/O - - L L L

A.PLD rewriting & control /DAC control

114 P64/CS4#-B ZVOL LATCH O - - L L L

ZONE VOLUME control pin

(AVR-X2000 Only)

115 P63/CS3#-A/CS7#-A NC O - - L L L Unused

116 P62/CS2#-A/CS6#-A E SPI CS O N3VPu - L L L

ETHERNET communication control

pin(DM860)

117

P61/CS1#/CS2#-B/

CS5#-A/CS6#-B/

CS7#-B

DAC MS O - - L L L D/A converter control pin(PCM1690)

118

P60/CS0#/CS4#-A/

CS5#-B

DAC RST O - - L L L D/A converter control pin(PCM1690)

119 PD3/D3 NC O

- - L L L Unused

120 PD2/D2 NC O - - L L L Unused

121 PD1/D1 FL CLK O - - L L L VFD control pin

122 PD0/D0 FL DATA O - - L L L VFD control pin

151
