Denon AVR-X2000 Service Manual

Cr
Y
Cb
COMP1-Cr
COMP2-Cb
COMP1-Cb
COMP2-Y
COMP1-Y
TMDS IN
TMDS OUTPUT
USB
IN2
USBD+/-
COMP2-Cr
TMDS IN
TMDS IN
TMDS IN
OSD
IN2
IN1
2V
DM860
COMP2-Cb
COMP2-Y
BD7628
COMP2-Cr
FRONT HDMI
HDMI5
HDMI3
HDMI2
HDMI1
INPUT SELECT
MM74HC4051
K4T51163QJ
TMDS OUTPUT
OUT1
HDMI6
HDMI4
HDMI Rx
VIDEO DECODER
ADV7850
CVBS IN
COMPONENT IN
HDMI IN
K4T51163QJ
HDMI i/p Scaler_TX_OSD
ADV8003-3
HDMI OUT1
MX25L12836EMI-10G 128M
ADV8195
BUFFER
TMDS SW
ADV3002
fig2 : HDMI Pass (Main)
33

Denon AVR-X2000 Specifications

General

Receiver type	-
Frequency range	10 - 100000 Hz
Output impedance	16 Ω
Input sensitivity	200 mV
Audio output channels	7.1 channels
Signal-to-Noise Ratio (SNR)	100 dB
Power output per channel (1KHz@6 Ohm)	125 W
Power output per channel (20-20KHz@8 Ohm)	95 W
HDMI in	7
AC (power) in	Yes
Audio (L/R) in	4
Composite video in	2
Component video (YPbPr/YCbCr) in	1
Connectivity technology	Wired
Speakers connectivity type	Banana connector
Audio formats supported	AAC, FLAC, MP3, WAV, WMA
Image formats supported	JPG
Wi-Fi	No
RDS features	PTY, TP
FM band range	87.5 - 108 MHz
Supported radio bands	FM
Internet radio services supported	Spotify, vTuner
Supported video modes	1080i, 1080p, 480p, 576p, 720p
Display	VFL
Color depth	24 bit
Aspect ratio	4:3, 16:9
Product color	Black
Audio decoders	Dolby Digital, Dolby Digital EX, Dolby Digital Plus, Dolby Pro Logic IIx, Dolby Pro Logic IIz, Dolby TrueHD, DTS, DTS-ES, DTS-HD, DTS-HD Master Audio
USB 2.0 ports quantity	USB 2.0 ports have a data transmission speed of 480 Mbps, and are backwards compatible with USB 1.1 ports. You can connect all kinds of peripheral devices to them.
Apple docking compatibility	Not supported
AC input voltage	230 V
AC input frequency	50 - 60 Hz
Power consumption (standby)	0.1 W
Power consumption (typical)	500 W

Weight and Dimensions

Depth	330 mm
Width	434 mm
Height	167 mm
Weight	9500 g
