Denon AVR-X2100W Service Manual

3.4. DIAGNOSTIC MODE (Service Path Check Mode)
3.4.1. Actions
This function is convenient for conrming problem paths in the product and executing a path check after repair.
The Video and Audio paths can be checked.
The backup data is not rewritten.
3.4.2. Starting up
AVR-X2100W
Hold down buttons "
ZONE2 SOURCE
", "
DIMMER
" and "
STATUS
" at the same time and press the power button to turn on the power.
AVR-S900W
Hold down buttons "
TUNER PRESET CH +
", "
TUNE -
" and "
TUNE +
" at the same time and press the power button to turn on the power.
Select the mode using the button "
TUNER PRESET CH+
", and press the button "
STATUS
" to commit the selection.
Select "
1. SERVICE CHECK
" and press the "
STATUS
" button to start the diagnostic mode.
The "
TUNED
", "
STERO
" and "
RDS
" segments are lit in this mode.
3.4.3. Canceling diagnostic mode
Press the power button to turn off the power.
3.4.4. Selecting items
Press
q
button to switch between video items and audio items.
Press button
w
or
e
to select the previous or next item.
The unit Remote control unit
Actions
q w e q w e
Audio ⇔ Video PREVIOUS NEXT Audio ⇔ Video PREVIOUS NEXT
Button DIMMER QUICK SELECT 1 QUICK SELECT 2 SLEEP CURSOR LEFT CURSOR RIGHT
3.4.5. Video system conrmation items
g. XX: See the block diagram of the g.XXth.
Paths conrmation item Display Settings Contents of conrmation Remarks
1
Video Convert
(Analog or HDMI ⇒ HDMI)
V 0 2 : V . C O N V E R T
Input Source : CBL/SAT
Video Convert(IP Scaler) : ON, All sources
IP Scaler : "Analog & HDMI", All sources
Resolution : "Auto", All sources
MAIN ZONE ON
ZONE2 OFF
・Check of CVBS input ⇒ IP Scaler ⇒ HDMI output.
・Check of Component input ⇒ IP Scaler ⇒ HDMI output.
・Check of HDMI input ⇒ IP Scaler ⇒ HDMI output.
・Check of ETHERNET input ⇒ IP Scaler ⇒ HDMI output.
（※ The input source can be switched to any source except CBL/SAT.）
2
HDMI pass
（MAIN ZONE）
V 0 3 : H D M I P A S S
Input Source : CBL/SAT
Source of Video Convert(IP Scaler) : OFF, All sources
MAIN ZONE ON
ZONE2 OFF
・Check of HDMI input（MAIN Function）⇒ HDMI output（MAIN）
（※ The input source can be switched to any source except CBL/SAT.）
3
HDMI CEC
V 0 4 : H D M I C E C
Input Source : CBL/SAT
HDMI Control : ON
MAIN ZONE ON
ZONE2 OFF
・When the power supply of a TV is put in the standby mode, make sure that the
power supply of this unit is also put in the standby mode.
・The ARC path can also be checked (check this using the TV input source).
（※ The input source can be switched to any source except CBL/SAT.）
4
HDMI Audio
(Audio: AVR)
V 0 5 : H . A U D I O - A V R
Input Source : CBL/SAT
HDMI Control : OFF
HDMI Audio：AVR ( if checking the audio output from AVR )
・Check of HDMI input(PCM , DolbyDigital , DTS) ⇒ Speaker output.
・Check of HDMI input(HD audio) ⇒ Speaker output.
（※ The input source can be switched to any source except CBL/SAT.）
5
HDMI Audio
(Audio: TV)
V 0 6 : H . A U D I O - T V
HDMI Audio：TV ( if checking the audio output from TV ) ・Check of HDMI input(PCM , DolbyDigital , DTS) ⇒ HDMI output (audio output
from connected TV)
（※ The input source can be switched to any source except CBL/SAT.）
6
GUI
V 0 7 : G U I M E N U O N
Input Source : CBL/SAT
Video Convert(IP Scaler) : ON, All sources
IP Scaler : "Analog & HDMI", All sources
Resolution : "AUTO", All sources
Setup Menu ON
MAIN ZONE ON
ZONE2 OFF
・Check of GUI display ⇒ HDMI output.
（※ The input source can be switched to any source except CBL/SAT.）
g.01
g.02
g.03
g.04a
g.04b
g.05
g.06
28

Denon AVR-X2100W Specifications

General

Receiver type	Surround
Frequency range	10 - 100000 Hz
Audio output channels	7.1 channels
Signal-to-Noise Ratio (SNR)	100 dB
Power output per channel (1KHz@6 Ohm)	150 W
Power output per channel (20-20KHz@8 Ohm)	95 W
HDMI in	8
Composite video in	2
Component video (YPbPr/YCbCr) in	1
Speakers connectivity type	-
Ethernet LAN	Yes
AM band range	522 - 1611 kHz
FM band range	87.5 - 108 MHz
Supported radio bands	AM, FM
Optical drive included	No
Product color	Black
Audio decoders	Dolby Digital EX, Dolby Pro Logic IIx, Dolby TrueHD, DTS 96/24, DTS-ES, DTS-HD
Apple docking compatibility	iPhone, iPod
AC input voltage	230 V
AC input frequency	50 Hz
Power consumption (standby)	0.1 W
Power consumption (typical)	500 W

Weight and Dimensions

Depth	339 mm
Width	434 mm
Height	167 mm
Weight	9700 g
