Denon AVR-X2100W Service Manual

3.4.6. Audio system conrmation items
g. XX: See the block diagram of the g.XXth.
Paths conrmation item Display Settings Contents of conrmation Remarks
1
Analog ( pass )
A 0 1 : A N A L O G P A S S
Input Source: CBL/SAT
Input Mode: ANALOG xed
Sound mode: DIRECT
Amp assign: Surround Back
MAIN ZONE: ON
ZONE2: OFF
・Check the audio output.
・Check of Analog input ⇒ Speaker output.
Front L/R
（※ The input source can be switched to any source except CBL/SAT.）
2
DIGITAL
(MAIN)
A 0 2 : D I G I T A L
Input Source : CBL/SAT
Input Mode : DIGITAL xed
Sound mode: MULTI CH STEREO
Amp assign : Surround Back
Speaker Cong all Speaker=Small / SW=Yes(2ch)
MAIN ZONE ON
ZONE2 OFF
・Check the audio output.
・Check of Digital input ⇒ Speaker output.
Front L/R、 Center、 Surround L/R、Surround Back L/R
・Check of Digital(PCM) input ⇒ Preout output.
Front L/R、 Center、 Surround L/R、Surround Back L/R、Subwoofer
（※ The input source can be switched to any source except CBL/SAT.）
3
DIGITAL
(ZONE2)
A 0 3 : D I G I T A L - Z 2
Input Source : NETWORK
Input Mode : Auto
Sound mode: STEREO
Amp assign : ZONE2
MAIN ZONE: ON
ZONE2: ON
・Check the audio output.
・Digital(PCM) input ⇒ Speaker output
Surround Back (ZONE2) L/R
・Digital(PCM) input ⇒ Preout output
ZONE2 L/R
4
HDMI
A 0 5 : H D M I
Input Source : CBL/SAT
Input Mode : HDMI xed
Sound mode: STEREO
Amp assign : Surround Back
MAIN ZONE: ON
ZONE2: OFF
・Check the audio output.
・HDMI input ⇒ Speaker output.
Front L/R
（※ The input source can be switched to any source except CBL/SAT.）
5
Analog AD
(MAIN)
A 0 6 : A D
Input Source : CBL/SAT
Input Mode : Analog xed
Sound mode: MULTI CH STEREO
Vol -20dB
Amp assign : Surround Back
Speaker Cong all Speaker=Small / SW=Yes(2ch)
MAIN ZONE: ON
ZONE2: OFF
・Check the audio output.
・Check of Analog input ⇒ Speaker output.
Front L/R、 Center、 Surround L/R、Surround Back L/R
・Check of Analog input ⇒ Pre OUT.
Front L/R、 Center、 Surround L/R、Surround Back L/R、Subwoofer
（※ The input source can be switched to any source except CBL/SAT.）
（※ Volume -20dB is the value when Relative settings are used. The value is 60
when Absolute settings are used）
6
Analog Amp Assign
(Amp Assign: ZONE2)
A 0 7 : A S S I G N - Z 2
Input Source : CBL/SAT
Input Mode : Auto
Sound mode: STEREO
Z2 Source : Source
Vol -20dB
Amp assign : ZONE2
MAIN ZONE: ON
ZONE2: ON
・Check the audio output.
・Check of Analog input ⇒ Speaker output.
Surround Back(ZONE2) L/R
・Check of Analog input ⇒ Pre OUT.
ZONE2 L/R
（※ The input source can be switched to any source except CBL/SAT.）
（※ Volume -20dB is the value when Relative settings are used. The value is 60
when Absolute settings are used）
7
Analog Amp Assign
(Amp Assign: Bi-Amp)
AVR-X2100W Only
A 1 1 : A S S I G N - B i A M P
Input Source : CBL/SAT
Input Mode : Auto
Sound mode: MULTI CH STEREO
Amp assign : Bi-Amp
MAIN ZONE ON
ZONE2 OFF
・Check the audio output.
・Check of Analog input ⇒ Speaker output.
Surround Back L/R
（※ The input source can be switched to any source except CBL/SAT.）
（※ Volume -20dB is the value when Relative settings are used. The value is 60
when Absolute settings are used）
8
Front Height
A 1 4 : F R O N T H E I G H T
Input Source : CBL/SAT
Input Mode : Auto
Sound mode: MULTI CH STEREO
Vol -20dB
Amp assign : Front Height
MAIN ZONE ON
ZONE2 OFF
・Check the audio output.
・Check of Analog input ⇒ Speaker output.
Surround Back L/R
（※ The input source can be switched to any source except CBL/SAT.）
・Check of PREOUT output.
（※ Volume -20dB is the value when Relative settings are used. The value is 60
when Absolute settings are used）
g.07
g.08a
g.08b
g.09a
g.09b
g.10a
g.10b
g.11a
g.11b
g.12
g.13
g.14a
g.14b
29

Denon AVR-X2100W Specifications

General

Receiver type	Surround
Frequency range	10 - 100000 Hz
Audio output channels	7.1 channels
Signal-to-Noise Ratio (SNR)	100 dB
Power output per channel (1KHz@6 Ohm)	150 W
Power output per channel (20-20KHz@8 Ohm)	95 W
HDMI in	8
Composite video in	2
Component video (YPbPr/YCbCr) in	1
Speakers connectivity type	-
Ethernet LAN	Yes
AM band range	522 - 1611 kHz
FM band range	87.5 - 108 MHz
Supported radio bands	AM, FM
Optical drive included	No
Product color	Black
Audio decoders	Dolby Digital EX, Dolby Pro Logic IIx, Dolby TrueHD, DTS 96/24, DTS-ES, DTS-HD
Apple docking compatibility	iPhone, iPod
AC input voltage	230 V
AC input frequency	50 Hz
Power consumption (standby)	0.1 W
Power consumption (typical)	500 W

Weight and Dimensions

Depth	339 mm
Width	434 mm
Height	167 mm
Weight	9700 g
