Denon AVR-X2100W Service Manual

1.11.Devicedisplayduringrmwareupdate
Displayoftargetdeviceduringrmwareupdate.
Target device Display Error code when an error occurs
MainCPU
M a i n : * * % * * * m i n
08 - 0B
10 - 15
20 - 27
36 - 3B
3F
Sub
S u b : * * % * * * m i n
50-52
54-58
5A-64
AudioPLD
A P L D : * * % * * * m i n
50 - 52
54 - 58
5A - 64
VIDEOPLD
V P L D : * * % * * * m i n
50-52
54-58
5A-64
DSP
D S P : * * % * * * m i n
50 - 52
54 - 58
5A - 64
GUISerialFlash
G U I : * * % * * * m i n
50 - 52
54 - 58
5A
62 - 64
80 - 86
CX870BootLoader
E S B L : * * % * * * m i n
A0 - A4
A6 - A7
AE - B5
CX870Image
E I M G : * * % * * * m i n
A0 - A4
A6 - A7
AE - B5
CX870Image(Emergency
Mode)
U p d a t e r e t r y
–
Checking the Firmware Version After an Update
After updating the rmware, check the version. See "
1. Version Display Mode
" (21 page ).
68

Denon AVR-X2100W Specifications

General

Receiver type	Surround
Frequency range	10 - 100000 Hz
Audio output channels	7.1 channels
Signal-to-Noise Ratio (SNR)	100 dB
Power output per channel (1KHz@6 Ohm)	150 W
Power output per channel (20-20KHz@8 Ohm)	95 W
HDMI in	8
Composite video in	2
Component video (YPbPr/YCbCr) in	1
Speakers connectivity type	-
Ethernet LAN	Yes
AM band range	522 - 1611 kHz
FM band range	87.5 - 108 MHz
Supported radio bands	AM, FM
Optical drive included	No
Product color	Black
Audio decoders	Dolby Digital EX, Dolby Pro Logic IIx, Dolby TrueHD, DTS 96/24, DTS-ES, DTS-HD
Apple docking compatibility	iPhone, iPod
AC input voltage	230 V
AC input frequency	50 Hz
Power consumption (standby)	0.1 W
Power consumption (typical)	500 W

Weight and Dimensions

Depth	339 mm
Width	434 mm
Height	167 mm
Weight	9700 g
