Denon AVR-X4100W

o
Detailed settings when “Assign Mode” is set to
“9.1ch”
When “Assign Mode” is set to “9.1ch”, set the following items.
n
Height Speakers
Select the number of the height speakers used in MAIN ZONE.
None: Uses no height speakers.
2 Height Speakers
(Default):
Uses a set of (two) height speakers.
4 Height Speakers : Uses two sets of (four) height speakers.
Using Dolby Speakers :
Select when the Dolby Atmos Enabled
speakers are connected.
n
Height Layout
Select the type of the height speakers used.
GWhen “Height Speakers” is set to “2 Height Speakers”H
Select the height channel used.
AUDIO OUT connectors
Select items
HEIGHT1
Front Height
(Default)
Front Height
Top Front Top Front
Top Middle Top Middle
Top Rear Top Rear
Rear Height Rear Height
