Denon AVR-X4100W Service Manual

YES
YES
YES
YES
Check the TV.
(12) Does the TV support HDCP?
(14) Is HDMI input set on the TV?
(15) Are a picture and sound output when a different TV is used?
Check the unit.
Check the rmware.
Is "
IP SCALER ERR
" displayed?
(See 21 page)
(13) Does the TV support 1080P/4K?
Use a TV that supports HDCP. Computer monitors can-
not be used.
Check the instruction manual of the TV and check the
input setting.
The TV is faulty.
•Check the circuits around the IP SCALER (IC401) and
DDR2 (IC402/403).
If there appear to be no problems, IC401 or IC402/403 is
faulty.
If the TV does not support 1080P/4K, a picture cannot be
output even if the Blu-ray/DVD player is set to 1080P/4K.
NO
NO
NO
YES
NO
See "AVR-X4100W_HDMI Rx-Tx Failure Detection Procedure Manual
ver_1.00" of SDI.
NO
NO
(11) Are a picture and sound output when a different Blu-ray/DVD
player is used?
The Blu-ray/DVD player is faulty.
YES
