DISASSEMBLY
• Remove each part in the order of the arrows below.
• Reassemble removed parts in the reverse order.
• Read before reassembling removed parts.
• If wire bundles are removed or moved during adjustment or part replacement, reshape the wires after completing
the work. Failure to shape the wires correctly may cause problems such as noise.
FRONT PANEL ASSY
See ""
1. FRONT PANEL ASSY
and ""
FRONT PCB
(Ref. No. of EXPLODED VIEW : C1)
HEAD PHONE PCB
(Ref. No. of EXPLODED VIEW : C2)
FRONT HDMI FFC CABLE PCB
(Ref. No. of EXPLODED VIEW : C3)
F.HDMI PCB
(Ref. No. of EXPLODED VIEW : C7)
USB PCB
(Ref. No. of EXPLODED VIEW : C9)
TOP COVER
MAIN TRANS
See ""
8. MAIN TRANS
and ""
MAIN TRANS
(Ref. No. of EXPLODED VIEW : C23)
RADIATOR ASSY
See ""
2. RADIATOR ASSY
and ""
GUIDE L(12630) PCB
(Ref. No. of EXPLODED VIEW : C11)
AMP PCB
(Ref. No. of EXPLODED VIEW : C12)
GUIDE FFC PCB
(Ref. No. of EXPLODED VIEW : C14)
DIGITAL PCB ASSY
See ""
3. DIGITAL PCB ASSY
and ""
DIGITAL PCB
(Ref. No. of EXPLODED VIEW : C29)
GUIDE PCB
(Ref. No. of EXPLODED VIEW : C28)
CX870 MIDDLE PCB
(Ref. No. of EXPLODED VIEW : C30)
CX870 MODULE
(Ref. No. of EXPLODED VIEW : C31)
VIDEO PCB ASSY
See ""
5. INPUT PCB ASSY
and ""
INPUT PCB
(Ref. No. of EXPLODED VIEW : C24)
INPUT PCB ASSY
See ""
4. VIDEO PCB ASSY
and ""
VIDEO PCB
(Ref. No. of EXPLODED VIEW : C26)
SPK PCB ASSY
See ""
6. SPK PCB ASSY
and ""
SPK PCB
(Ref. No. of EXPLODED VIEW : C38)
SPK FW PCB
(Ref. No. of EXPLODED VIEW : C27)
FUSE PCB
(Ref. No. of EXPLODED VIEW : C36)
FRT CNT PCB
(Ref. No. of EXPLODED VIEW : C35)
SIDE CNT PCB
(Ref. No. of EXPLODED VIEW : C37)
SMPS PCB
See ""
7. SMPS PCB
and ""
SMPS PCB
(Ref. No. of EXPLODED VIEW : C15)
11
