Denon AVR-X4100W

BK903
CMD1A629
OPTION
OPTION
OPTION
OPTION
AC220~240V : 100uF/400V AC100~120V : 220uF/200V
HEATSINK
(16*16*30)
or CHASSIS
HEATSINK
(16*16*25)
AC100 ~ 120V
AC220 ~ 240V
OPTION
OPEN
CCQF2E104KZE-T
R9004 330K(0.2W)
C9006
0.047uF(1608)
C9007
0.01uF(1608)
C9008
0.1uF(1608)
C9010
0.1uF(1608)
R9006
1M(1608)
D9006 1N4007
D9005 1N4007
D9001 1N4007
D9002 1N4007
D9003 1N4007
D9004 1N4007
CX902
0.1uF/275V
R9015
8.2K(1608)
R9016
1K(1608)
R9014
270K(1608)
R9010
1M(0.2W)
R9008
2.2M(0.2W)
ZD908
120V/5W
R9009
2.2M(0.2W)
ZD911
150V/5W
C9012
1000P/1KV
R9017
6.8(0.2W)
C9017
47/25V(NXA)
D9013
1N4007S
ZD920
39V
C9016
0.1uF(1608)
D9008
1N4007
ZD918
22V
C9009 50V/10UF(NXA)
D9009
1N4007
C9018 0.1uF(1608)
C9019 4.7uF(1608)
C9020 5600uF/6.3V
C9021 5600uF/6.3V
C9022 5600uF/6.3V
C9028
2200P 250V
C9029
0.1uF(1608)
1
3
2
D9012
CVDSRL3060P
C9002 0.01uF
250V
C9003
0.01uF 250V
R9030
OPEN(1608)
C9030 OPEN(1608)
C9004
400V/100uF
R9035
1M(2125)
R9036
1M(2125)
R9037
1M(2125)
43
2 1
IC902
PC123Y22
ZD921
7.5V
J9002
JUMPER
J9003
JUMPER
D
G
S
Q9001
INK0010AC1
1
2
3
4
5
6
7
8
10
11
T9001
ZD922
39V
D
7
F S C X V
5 4 3 2 1
IC901
TOP256YN
C9031
OPEN
GND91
OPEN
After primary side rectification
(Caution: High voltage, electric shock)
Primary drain
(Caution: High voltage, electric shock)
After secondary rectifications
A B
C
Operation waveform for each part
A B C
A B C
SMPS unit
(Unloaded)
Set
116
