Denon AVR-X4100W

FRONT
FRONT PCB ASS'
Y
※Parts indicated b
y
"ns
p
"on this table cannot be su
pp
lied.
※The
p
arts listed below are onl
y
for maintenance. Therefore the
y
mi
g
ht differ from the
p
arts used in the unit in a
pp
earances or dimension
s
NOTE:The symbols in the column Remarks indicate the following destinations.
E3 : U.S.A. & Canada model E2 : Europe model E1C : China model E1 : Asia model JP : Japan model
BK : Black model SP : Premium Silver model
REF No. Part No. Part Name Remarks Q't
y
New
V
e
r
SEMICONDUCTORS GROUP
D6021 90M-HD302360R DIODE,ZENER,1/2W,6.8V CVDZJ6.8BT 1
D6023 00D9630328409 DIODE,RECTIFIER,AXIAL CVD1N4007ST 1
D6026 943202007690S DIODE,ZENER,1/2W,18V CVDZJ18BT 1
D6027 00D9430087209 DIODE,ZENER,1/2W,24V CVDZJ24BT 1
D6041 943209001080S DIODE,CHIP,SWITCHING CVD1SS355T 1
D6323 943209001080S DIODE,CHIP,SWITCHING CVD1SS355T 1
D6691 90M-RI000230R RES,CHIP(3216/5%/10ohm) CRJ14CJ100T 1
D6694 90M-RI000230R RES,CHIP(3216/5%/10ohm) CRJ14CJ100T 1
D6701 nsp CAP,CHIP(1608,50V/0.1uF,X7R)_SAMSUNG CCUS1H104KCS 1
D6712 943202500730S DIODE,ZENER(5.1V/0.5W,SOD-123) CVDMM1Z5V1H 1
D6729,6730 943202500730S DIODE,ZENER(5.1V/0.5W,SOD-123) CVDMM1Z5V1H 2
D6751 90M-RI000230R RES,CHIP(3216/5%/10ohm) CRJ14CJ100T 1
IC601 943232100380S I.C,DUALOPAMP(SOP-8P) CVINJM8080G 1
IC607 943232100380S I.C,DUALOPAMP(SOP-8P) CVINJM8080G 1
Q6026 943219006820S T.R CVTKTC1027YT 1
Q6027 943216500020S T.R,RT1N141C(10K-10K) CVTRT1N141C 1
Q6042 943214500020S T.R,2SC3052 CVT2SC3052 1
Q6081 943216500020S T.R,RT1N141C(10K-10K) CVTRT1N141C 1
Q6112 943215500020S T.R,RT1P141C(10K-10K) CVTRT1P141C 1
Q6311,6312 943215500020S T.R,RT1P141C(10K-10K) CVTRT1P141C 2
Q6313,6314 943216500020S T.R,RT1N141C(10K-10K) CVTRT1N141C 2
Q6703 943216500020S T.R,RT1N141C(10K-10K) CVTRT1N141C 1
RESISTOR GROUP
R6001,6002 nsp RES,CHIP(1608/5%/200ohm) CRJ10DJ201T 2
R6003,6004 nsp RES,CHIP(1608/5%/0ohm) CRJ10DJ0R0T 2
R6005 nsp RES,CHIP(1608/5%/1ohm) CRJ10DJ1R0T 1
R6006 nsp RES,CHIP(1608/5%/2.2ohm) CRJ10DJ2R2T 1
R6008 nsp RES,CHIP(1608/5%/0ohm) CRJ10DJ0R0T 1
R6009 nsp RES,CHIP(1608/5%/4.7Kohm) CRJ10DJ472T 1
R6016 nsp RES,CHIP(1608/5%/10ohm) CRJ10DJ100T 1
R6025,6026 nsp RES,CHIP(1608/5%/4.7Kohm) CRJ10DJ472T 2
R6031 nsp RES,CHIP(1608/5%/27Kohm) CRJ10DJ273T 1
R6032 nsp RES,CHIP(1608/5%/220Kohm) CRJ10DJ224T 1
R6033,6034 90M-RI000230R RES,CHIP(3216/5%/10ohm) CRJ14CJ100T 2
R6041 nsp RES,CHIP(1608/5%/100ohm) CRJ10DJ101T 1
R6042 nsp RES,CHIP(1608/5%/100Kohm) CRJ10DJ104T 1
R6043 nsp RES,CHIP(1608/5%/47Kohm) CRJ10DJ473T 1
R6044 nsp RES,CHIP(1608/5%/390Kohm) CRJ10DJ394T 1
R6071-6073 nsp RES,CHIP(1608/5%/100ohm) CRJ10DJ101T 3
R6082 nsp RES,CHIP(1608/5%/10Kohm) CRJ10DJ103T 1
R6083 nsp RES,CHIP(1608/5%/100ohm) CRJ10DJ101T 1
R6101,6102 nsp RES,CHIP(1608/5%/390ohm) CRJ10DJ391T 2
R6103 nsp RES,CHIP(1608/5%/47Kohm) CRJ10DJ473T 1
R6134 nsp RES,CHIP(1608/5%/1Kohm) CRJ10DJ102T 1
R6135 nsp RES,CHIP(1608/5%/47Kohm) CRJ10DJ473T 1
R6151 nsp RES,CHIP(1608/5%/100ohm) CRJ10DJ101T 1
R6152 nsp RES,CHIP(1608/5%/150ohm) CRJ10DJ151T 1
R6153 nsp RES,CHIP(1608/5%/180ohm) CRJ10DJ181T 1
R6154 nsp RES,CHIP(1608/5%/220ohm) CRJ10DJ221T 1
R6155 nsp RES,CHIP(1608/5%/330ohm) CRJ10DJ331T 1
R6161 nsp RES,CHIP(1608/5%/100ohm) CRJ10DJ101T 1
R6162 nsp RES,CHIP(1608/5%/150ohm) CRJ10DJ151T 1
R6163 nsp RES,CHIP(1608/5%/180ohm) CRJ10DJ181T 1
R6164 nsp RES,CHIP(1608/5%/220ohm) CRJ10DJ221T 1
R6165 nsp RES,CHIP(1608/5%/330ohm) CRJ10DJ331T 1
R6166 nsp RES,CHIP(1608/5%/560ohm) CRJ10DJ561T 1
R6171 nsp RES,CHIP(1608/5%/100ohm) CRJ10DJ101T 1
R6172 nsp RES,CHIP(1608/5%/150ohm) CRJ10DJ151T 1
R6173 nsp RES,CHIP(1608/5%/180ohm) CRJ10DJ181T 1
R6174 nsp RES,CHIP(1608/5%/220ohm) CRJ10DJ221T 1
R6175 nsp RES,CHIP(1608/5%/330ohm) CRJ10DJ331T 1
R6301 nsp RES,CHIP(1608/5%/2.2Kohm) CRJ10DJ222T 1
R6302 nsp RES,CHIP(1608/5%/1.2Kohm) E3 CRJ10DJ122T 1
R6302 nsp RES,CHIP(1608/5%/560ohm) E2/JP CRJ10DJ561T 1
R6303 nsp RES,CHIP(1608/5%/1.2Kohm) E3 CRJ10DJ122T 1
R6303 nsp RES,CHIP(1608/5%/560ohm) E2/JP CRJ10DJ561T 1
R6351,6352 nsp RES,CHIP(1608/5%/100ohm) CRJ10DJ101T 2
R6353,6354 nsp RES,CHIP(1608/5%/4.7Kohm) CRJ10DJ472T 2
R6421,6422 nsp RES,CHIP(1608/5%/100ohm) CRJ10DJ101T 2
R6423,6424 nsp RES,CHIP(1608/5%/4.7Kohm) CRJ10DJ472T 2
R6503 nsp RES,CHIP(1608/5%/100ohm) CRJ10DJ101T 1
R6601,6602 nsp RES,CHIP(1608/5%/470ohm) CRJ10DJ471T 2
R6603-6605 nsp RES,CHIP(1608/5%/100Kohm) CRJ10DJ104T 3
R6607 nsp RES,CHIP(1608/5%/100Kohm) CRJ10DJ104T 1
R6613,6614 nsp RES,CHIP(1608/5%/100ohm) CRJ10DJ101T 2
R6632 nsp RES,CHIP(1608/5%/0ohm) CRJ10DJ0R0T 1
R6704 nsp RES,CHIP(1608/5%/100Kohm) CRJ10DJ104T 1
R6711 nsp RES,CHIP(1608/5%/2.2Kohm) CRJ10DJ222T 1
R6718 nsp RES,CHIP(1608/5%/100ohm) CRJ10DJ101T 1
R6719 nsp RES,CHIP(1608/5%/820ohm) CRJ10DJ821T 1
R6720 nsp RES,CHIP(1608/5%/18Kohm) CRJ10DJ183T 1
R6721 nsp RES,CHIP(1608/5%/4.7Kohm) CRJ10DJ472T 1
R6723 nsp RES,CHIP(1608/5%/100ohm) CRJ10DJ101T 1
R6726 nsp RES,CHIP(1608/5%/1Kohm) CRJ10DJ102T 1
R6734 nsp RES,CHIP(1608/5%/100Kohm) CRJ10DJ104T 1
CAPACIITORS GROUP
C6021 nsp CAP,ELECT(50V/10uF) CCEA1HH100T 1
C6025 nsp CAP,ELECT(50V/1uF) CCEA1HH1R0T 1
C6027 nsp CAP,ELECT(50V/1uF) CCEA1HH1R0T 1
C6034 nsp CAP,CHIP(1608,50V/0.1uF,X7R)_SAMSUNG CCUS1H104KCS 1
C6071-6073 nsp CAP,CHIP(1608,50V/100pF,C0G)_SAMSUNG CCUS1H101JAS 3
C6081 nsp CAP,CHIP(2012,50V/0.1uF,X7R)_SAMSUNG CCUC1H104KCS 1
C6082 nsp CAP,ELECT(50V/10uF) CCEA1HH100T 1
C6083 nsp CAP,CHIP(1608,50V/0.047uF,X7R)_SAMSUNG CCUS1H473KCS 1
C6084 nsp CAP,CHIP(1608,50V/0.01uF,X7R)_SAMSUNG CCUS1H103KCS 1
C6113 nsp CAP,CHIP(1608,50V/0.1uF,X7R)_SAMSUNG CCUS1H104KCS 1
C6114 nsp CAP,ELECT(16V/47uF) CCEA1CH470T 1
C6118 nsp RES,CHIP(1608/5%/10ohm) CRJ10DJ100T 1
1
