Denon AVR-X4100W

7CHAMP
REF No. Part No. Part Name Remarks Q't
y
New
V
e
r
R7745 nsp RES,CARBON(1/5W,22Kohm,J) CRD20TJ223T 1
CAPACIITORS GROUP
C7001 nsp CAP,CHIP(1608,50V/0.01uF,X7R)_SAMSUNG CCUS1H103KCS 1
C7011,7012 nsp CAP,ELECT(10V/330uF) CCEA1AH331T 2
C7013 nsp CAP,ELECT(10V/47uF) CCEA1AH470T 1
C7101 00D2544583971 CAP,ELEC(ELNAROBSERIES,47uF/50V) CCEA1HROB470T 1
C7102 nsp CAP,PE-FILM(100V/470pF/J) CCME2A471JR11T 1
C7104 nsp CAP,PE-FILM(100V/220pF/J) CCME2A221JR11T 1
C7106 00MOA47702520 CAP,ELECT(25V/470uF) CCEA1EH471T 1
C7107 nsp CAP,MYLAR(50V/2200pF/J) HCQI1H222JZT 1
C7112 nsp CAP,PE-FILM(100V/220pF/J) CCME2A221JR11T 1
C7120,7121 nsp CAP,PE-FILM(100V/470pF/J) CCME2A471JR11T 2
C7125 00MOA47702520 CAP,ELECT(25V/470uF) CCEA1EH471T 1
C7131,7132 943134500070S CAP,ELECT(100V/10uF) CCEA2AH100T 2
C7138 nsp CAP,CHIP(1608,50V/0.1uF,X7R)_SAMSUNG CCUS1H104KCS 1
C7201 00D2544583971 CAP,ELEC(ELNAROBSERIES,47uF/50V) CCEA1HROB470T 1
C7202 nsp CAP,PE-FILM(100V/470pF/J) CCME2A471JR11T 1
C7204 nsp CAP,PE-FILM(100V/220pF/J) CCME2A221JR11T 1
C7206 00MOA47702520 CAP,ELECT(25V/470uF) CCEA1EH471T 1
C7207 nsp CAP,MYLAR(50V/2200pF/J) HCQI1H222JZT 1
C7212 nsp CAP,PE-FILM(100V/220pF/J) CCME2A221JR11T 1
C7220,7221 nsp CAP,PE-FILM(100V/470pF/J) CCME2A471JR11T 2
C7225 00MOA47702520 CAP,ELECT(25V/470uF) CCEA1EH471T 1
C7231,7232 943134500070S CAP,ELECT(100V/10uF) CCEA2AH100T 2
C7238 nsp CAP,CHIP(1608,50V/0.1uF,X7R)_SAMSUNG CCUS1H104KCS 1
C7301 00D2544583971 CAP,ELEC(ELNAROBSERIES,47uF/50V) CCEA1HROB470T 1
C7302 nsp CAP,PE-FILM(100V/470pF/J) CCME2A471JR11T 1
C7304 nsp CAP,PE-FILM(100V/220pF/J) CCME2A221JR11T 1
C7306 00MOA47702520 CAP,ELECT(25V/470uF) CCEA1EH471T 1
C7307 nsp CAP,MYLAR(50V/2200pF/J) HCQI1H222JZT 1
C7312 nsp CAP,PE-FILM(100V/220pF/J) CCME2A221JR11T 1
C7320,7321 nsp CAP,PE-FILM(100V/470pF/J) CCME2A471JR11T 2
C7325 00MOA47702520 CAP,ELECT(25V/470uF) CCEA1EH471T 1
C7331,7332 943134500070S CAP,ELECT(100V/10uF) CCEA2AH100T 2
C7338 nsp CAP,CHIP(1608,50V/0.1uF,X7R)_SAMSUNG CCUS1H104KCS 1
C7401 00D2544583971 CAP,ELEC(ELNAROBSERIES,47uF/50V) CCEA1HROB470T 1
C7402 nsp CAP,PE-FILM(100V/470pF/J) CCME2A471JR11T 1
C7404 nsp CAP,PE-FILM(100V/220pF/J) CCME2A221JR11T 1
C7406 00MOA47702520 CAP,ELECT(25V/470uF) CCEA1EH471T 1
C7407 nsp CAP,MYLAR(50V/2200pF/J) HCQI1H222JZT 1
C7412 nsp CAP,PE-FILM(100V/220pF/J) CCME2A221JR11T 1
C7420,7421 nsp CAP,PE-FILM(100V/470pF/J) CCME2A471JR11T 2
C7425 00MOA47702520 CAP,ELECT(25V/470uF) CCEA1EH471T 1
C7431,7432 943134500070S CAP,ELECT(100V/10uF) CCEA2AH100T 2
C7438 nsp CAP,CHIP(1608,50V/0.1uF,X7R)_SAMSUNG CCUS1H104KCS 1
C7501 00D2544583971 CAP,ELEC(ELNAROBSERIES,47uF/50V) CCEA1HROB470T 1
C7502 nsp CAP,PE-FILM(100V/470pF/J) CCME2A471JR11T 1
C7504 nsp CAP,PE-FILM(100V/220pF/J) CCME2A221JR11T 1
C7506 00MOA47702520 CAP,ELECT(25V/470uF) CCEA1EH471T 1
C7507 nsp CAP,MYLAR(50V/2200pF/J) HCQI1H222JZT 1
C7512 nsp CAP,PE-FILM(100V/220pF/J) CCME2A221JR11T 1
C7520,7521 nsp CAP,PE-FILM(100V/470pF/J) CCME2A471JR11T 2
C7525 00MOA47702520 CAP,ELECT(25V/470uF) CCEA1EH471T 1
C7531,7532 943134500070S CAP,ELECT(100V/10uF) CCEA2AH100T 2
C7538 nsp CAP,CHIP(1608,50V/0.1uF,X7R)_SAMSUNG CCUS1H104KCS 1
C7601 00D2544583971 CAP,ELEC(ELNAROBSERIES,47uF/50V) CCEA1HROB470T 1
C7602 nsp CAP,PE-FILM(100V/470pF/J) CCME2A471JR11T 1
C7604 nsp CAP,PE-FILM(100V/220pF/J) CCME2A221JR11T 1
C7606 00MOA47702520 CAP,ELECT(25V/470uF) CCEA1EH471T 1
C7607 nsp CAP,MYLAR(50V/2200pF/J) HCQI1H222JZT 1
C7612 nsp CAP,PE-FILM(100V/220pF/J) CCME2A221JR11T 1
C7620,7621 nsp CAP,PE-FILM(100V/470pF/J) CCME2A471JR11T 2
C7625 00MOA47702520 CAP,ELECT(25V/470uF) CCEA1EH471T 1
C7631,7632 943134500070S CAP,ELECT(100V/10uF) CCEA2AH100T 2
C7638 nsp CAP,CHIP(1608,50V/0.1uF,X7R)_SAMSUNG CCUS1H104KCS 1
C7701 00D2544583971 CAP,ELEC(ELNAROBSERIES,47uF/50V) CCEA1HROB470T 1
C7702 nsp CAP,PE-FILM(100V/470pF/J) CCME2A471JR11T 1
C7704 nsp CAP,PE-FILM(100V/220pF/J) CCME2A221JR11T 1
C7706 00MOA47702520 CAP,ELECT(25V/470uF) CCEA1EH471T 1
C7707 nsp CAP,MYLAR(50V/2200pF/J) HCQI1H222JZT 1
C7712 nsp CAP,PE-FILM(100V/220pF/J) CCME2A221JR11T 1
C7720,7721 nsp CAP,PE-FILM(100V/470pF/J) CCME2A471JR11T 2
C7725 00MOA47702520 CAP,ELECT(25V/470uF) CCEA1EH471T 1
C7731,7732 943134500070S CAP,ELECT(100V/10uF) CCEA2AH100T 2
C7738 nsp CAP,CHIP(1608,50V/0.1uF,X7R)_SAMSUNG CCUS1H104KCS 1
OTHER PARTS GROUP
BK701 nsp BRACKET,PCB CMD1A569-V1 1
BN710
EXPLODED
_
C13
nsp WIREASS'Y(7P,2.0MM,180MM,UL1007#26) CWB1B007180LC 1
CN461 nsp LOCK-WAFER/STRAIGHT/2MMPITCH/13PIN CJP13GI288ZY 1
CN701 nsp LOCK-WAFER/STRAIGHT/2.5MMPITCH/4PIN CJP04GI289ZY 1
CN702 nsp LOCK-WAFER/STRAIGHT/2.5MMPITCH/5PIN CJP05GI289ZY 1
CN703 nsp LOCK-WAFER/STRAIGHT/2.5MMPITCH/7PIN CJP07GI289ZY 1
CN704 nsp LOCK-WAFER/STRAIGHT/2.5MMPITCH/6PIN CJP06GI289ZY 1
CN715 nsp WAFER(3PIN,AN,2MM,JWT) CJP03GB48ZW 1
CN725 nsp WAFER(3PIN,AN,2MM,JWT) CJP03GB48ZW 1
CN735 nsp WAFER(3PIN,AN,2MM,JWT) CJP03GB48ZW 1
CN745 nsp WAFER(3PIN,AN,2MM,JWT) CJP03GB48ZW 1
CN755 nsp WAFER(3PIN,AN,2MM,JWT) CJP03GB48ZW 1
CN765 nsp WAFER(3PIN,AN,2MM,JWT) CJP03GB48ZW 1
CN775 nsp WAFER(3PIN,AN,2MM,JWT) CJP03GB48ZW 1
GND71 nsp PLATE,EARTH(TRONICELECTRONICS) CJT1A026 1
VR714 963161012400S RES,SEMIFIXED(1K/B-CURVE)ANGLE CVN1RE102B01T 1
VR724 963161012400S RES,SEMIFIXED(1K/B-CURVE)ANGLE CVN1RE102B01T 1
VR734 963161012400S RES,SEMIFIXED(1K/B-CURVE)ANGLE CVN1RE102B01T 1
VR744 963161012400S RES,SEMIFIXED(1K/B-CURVE)ANGLE CVN1RE102B01T 1
VR754 963161012400S RES,SEMIFIXED(1K/B-CURVE)ANGLE CVN1RE102B01T 1
VR764 963161012400S RES,SEMIFIXED(1K/B-CURVE)ANGLE CVN1RE102B01T 1
VR774 963161012400S RES,SEMIFIXED(1K/B-CURVE)ANGLE CVN1RE102B01T 1
★ nsp HEATSINKASS'Y CMY2A376ZA 1
