Denon AVR-X4100W

INPUT
INPUT PCB ASS'
Y
※Parts indicated b
y
"ns
p
"on this table cannot be su
pp
lied.
※The
p
arts listed below are onl
y
for maintenance. Therefore the
y
mi
g
ht differ from the
p
arts used in the unit in a
pp
earances or dimension
s
NOTE:The symbols in the column Remarks indicate the following destinations.
E3 : U.S.A. & Canada model E2 : Europe model E1C : China model E1 : Asia model JP : Japan model
BK : Black model SP : Premium Silver model
REF No. Part No. Part Name Remarks Q't
y
New
V
e
r
SEMICONDUCTORS GROUP
D6803 963209003510S DIODE,RELIABLEESDPROTECTION CVDCDS3C05HDMI
1
1
D6835,6836 963209003510S DIODE,RELIABLEESDPROTECTION CVDCDS3C05HDMI
1
2
D8795 943209001080S DIODE,CHIP,SWITCHING CVD1SS355T 1
D8797-8801 943209001080S DIODE,CHIP,SWITCHING CVD1SS355T 5
D8845-8847 943203003150S DIODE,RECTIFIER,RADIAL CVD1N4007SRT 3
D8848 943202500720S DIODE,ZENER(3.6V/0.5W,SOD-123) CVDMM1Z3V6H 1
IC466 943232100380S I.C,DUALOPAMP(SOP-8P) CVINJM8080G 1
IC471 235810045600S I.C,8CHVOLUME CVIR2A15220FP 1
IC481-483 943232100380S I.C,DUALOPAMP(SOP-8P) CVINJM8080G 3
IC484 943236101540D I.C,FUNCTIONSWITCH(SSOP-32) CVIBD3841FSE2 1
IC486-488 943232100380S I.C,DUALOPAMP(SOP-8P) CVINJM8080G 3
IC491 943235003810S I.C,INPUTWITH8CHVOLUME(100PQFP) CVIR2A15218FP 1
Q8713 943215500030S T.R,RT1P441C(47K-47K) CVTRT1P441C 1
Q8714 943216500050S T.R,RT1N441C(47K-47K) CVTRT1N441C 1
Q8717,8718 943214500030S T.R,MUTE CVTINC2001AC1 2
Q8719 943213500160S T.R,RT1N237C(2.2K-47K) CVTRT1N237C 1
Q8720 943215500030S T.R,RT1P441C(47K-47K) CVTRT1P441C 1
Q8733 943215500030S T.R,RT1P441C(47K-47K) CVTRT1P441C 1
Q8734 943216500050S T.R,RT1N441C(47K-47K) CVTRT1N441C 1
Q8737,8738 943214500030S T.R,MUTE CVTINC2001AC1 2
Q8740 943215500030S T.R,RT1P441C(47K-47K) CVTRT1P441C 1
Q8753 943215500030S T.R,RT1P441C(47K-47K) CVTRT1P441C 1
Q8754 943216500050S T.R,RT1N441C(47K-47K) CVTRT1N441C 1
Q8757,8758 943214500030S T.R,MUTE CVTINC2001AC1 2
Q8760 943215500030S T.R,RT1P441C(47K-47K) CVTRT1P441C 1
Q8795 943213500160S T.R,RT1N237C(2.2K-47K) CVTRT1N237C 1
Q8797-8800 943213500160S T.R,RT1N237C(2.2K-47K) CVTRT1N237C 4
Q8813 943215500030S T.R,RT1P441C(47K-47K) CVTRT1P441C 1
Q8814 943216500050S T.R,RT1N441C(47K-47K) CVTRT1N441C 1
Q8817 943214500030S T.R,MUTE CVTINC2001AC1 1
Q8820 943215500030S T.R,RT1P441C(47K-47K) CVTRT1P441C 1
Q8863 943215500030S T.R,RT1P441C(47K-47K) CVTRT1P441C 1
Q8864 943216500050S T.R,RT1N441C(47K-47K) CVTRT1N441C 1
Q8870 943215500030S T.R,RT1P441C(47K-47K) CVTRT1P441C 1
Q8923 943215500030S T.R,RT1P441C(47K-47K) CVTRT1P441C 1
Q8924 943216500050S T.R,RT1N441C(47K-47K) CVTRT1N441C 1
Q8927,8928 943214500030S T.R,MUTE CVTINC2001AC1 2
Q8930 943215500030S T.R,RT1P441C(47K-47K) CVTRT1P441C 1
Q8973 943215500030S T.R,RT1P441C(47K-47K) CVTRT1P441C 1
Q8974 943216500050S T.R,RT1N441C(47K-47K) CVTRT1N441C 1
Q8977,8978 943214500030S T.R,MUTE CVTINC2001AC1 2
Q8980 943215500030S T.R,RT1P441C(47K-47K) CVTRT1P441C 1
IC898,899 943233102030S I.C,Shift/StoreRegister(SOIC-16P) CVIMC74HC4094AD 2 *
RESISTOR GROUP
R4601,4602 nsp RES,CHIP(1608/5%/470ohm) CRJ10DJ471T 2
R4603,4604 nsp RES,CHIP(1608/5%/51Kohm) CRJ10DJ513T 2
R4605,4606 nsp RES,CHIP(1608/5%/470ohm) CRJ10DJ471T 2
R4607,4608 nsp RES,CHIP(1608/5%/51Kohm) CRJ10DJ513T 2
R4609,4610 nsp RES,CHIP(1608/5%/0ohm) CRJ10DJ0R0T 2
R4611,4612 nsp RES,CHIP(1608/5%/470ohm) CRJ10DJ471T 2
R4613,4614 nsp RES,CHIP(1608/5%/51Kohm) CRJ10DJ513T 2
R4615,4616 nsp RES,CHIP(1608/5%/470ohm) CRJ10DJ471T 2
R4617,4618 nsp RES,CHIP(1608/5%/51Kohm) CRJ10DJ513T 2
R4619,4620 nsp RES,CHIP(1608/5%/0ohm) CRJ10DJ0R0T 2
R4625,4626 nsp RES,CHIP(1608/5%/470ohm) CRJ10DJ471T 2
R4627,4628 nsp RES,CHIP(1608/5%/51Kohm) CRJ10DJ513T 2
R4629,4630 nsp RES,CHIP(1608/5%/0ohm) CRJ10DJ0R0T 2
R4661 nsp RES,CHIP(1608/5%/0ohm) E3/JP CRJ10DJ0R0T 1
R4661 nsp RES,CHIP(1608/5%/4.7Kohm) E2 CRJ10DJ472T 1
R4662 nsp RES,CHIP(1608/5%/0ohm) E3/JP CRJ10DJ0R0T 1
R4662 nsp RES,CHIP(1608/5%/4.7Kohm) E2 CRJ10DJ472T 1
R4663,4664 nsp RES,CHIP(1608/5%/390ohm) CRJ10DJ391T 2
R4665,4666 nsp RES,CHIP(1608/5%/68Kohm) CRJ10DJ683T 2
R4667,4668 nsp RES,CHIP(1608/5%/150Kohm) CRJ10DJ154T 2
R4669,4670 nsp RES,CHIP(1608/5%/47ohm) CRJ10DJ470T 2
R4671,4672 nsp RES,CHIP(1608/5%/240ohm) CRJ10DJ241T 2
R4679,4680 nsp RES,CHIP(1608/5%/130Kohm) CRJ10DJ134T 2
R4681,4682 nsp RES,CHIP(1608/5%/11Kohm) CRJ10DJ113T 2
R4683,4684 nsp RES,CHIP(1608/5%/22ohm) CRJ10DJ220T 2
R4685,4686 nsp RES,CHIP(1608/5%/47ohm) CRJ10DJ470T 2
R4687,4688 nsp RES,CHIP(1608/5%/470Kohm) CRJ10DJ474T 2
R4701-4705 nsp RES,CHIP(1608/5%/100ohm) CRJ10DJ101T 5
R4707 nsp RES,CHIP(1608/5%/100ohm) CRJ10DJ101T 1
R4709-4716 nsp RES,CHIP(1608/5%/100ohm) CRJ10DJ101T 8
R4719,4720 nsp RES,CHIP(1608/5%/100ohm) CRJ10DJ101T 2
R4721,4722 nsp RES,CHIP(1608/5%/4.7Kohm) CRJ10DJ472T 2
R4737,4738 nsp RES,CHIP(1608/5%/100ohm) CRJ10DJ101T 2
R4743-4746 nsp RES,CHIP(1608/5%/47Kohm) CRJ10DJ473T 4
R4761-4771 nsp RES,CHIP(1608/5%/10Kohm) CRJ10DJ103T 11
R4773,4774 nsp RES,CHIP(1608/5%/100Kohm) CRJ10DJ104T 2
R4781-4784 nsp RES,CHIP(1608/5%/100Kohm) CRJ10DJ104T 4
R4794-4799 nsp RES,CHIP(1608/5%/0ohm) CRJ10DJ0R0T 6
R4801,4802 nsp RES,CHIP(1608/5%/470Kohm) CRJ10DJ474T 2
R4803,4804 nsp RES,CHIP(1608/5%/150Kohm) CRJ10DJ154T 2
R4805,4806 nsp RES,CHIP(1608/5%/270Kohm) CRJ10DJ274T 2
R4807,4808 nsp RES,CHIP(1608/5%/0ohm) CRJ10DJ0R0T 2
R4811,4812 nsp RES,CHIP(1608/5%/100ohm) CRJ10DJ101T 2
R4813,4814 nsp RES,CHIP(1608/5%/100Kohm) CRJ10DJ104T 2
R4815-4818 nsp RES,CHIP(1608/5%/68Kohm) CRJ10DJ683T 4
R4819,4820 nsp RES,CHIP(1608/5%/33Kohm) CRJ10DJ333T 2
R4821-4824 nsp RES,CHIP(1608/5%/4.7Kohm) CRJ10DJ472T 4
R4825,4826 nsp RES,CHIP(1608/5%/47ohm) CRJ10DJ470T 2
R4827,4828 nsp RES,CHIP(1608/5%/100Kohm) CRJ10DJ104T 2
R4831,4832 nsp RES,CHIP(1608/5%/100ohm) CRJ10DJ101T 2
R4833-4836 nsp RES,CHIP(1608/5%/100Kohm) CRJ10DJ104T 4
R4851,4852 nsp RES,CHIP(1608/5%/470Kohm) CRJ10DJ474T 2
R4853,4854 nsp RES,CHIP(1608/5%/150Kohm) CRJ10DJ154T 2
R4855,4856 nsp RES,CHIP(1608/5%/270Kohm) CRJ10DJ274T 2
10
