Denon AVR-X4100W

DIGITAL
DIGITAL PCB ASS'
Y
※Parts indicated b
y
"ns
p
"on this table cannot be su
pp
lied.
※The
p
arts listed below are onl
y
for maintenance. Therefore the
y
mi
g
ht differ from the
p
arts used in the unit in a
pp
earances or dimension
s
NOTE:The symbols in the column Remarks indicate the following destinations.
E3 : U.S.A. & Canada model E2 : Europe model E1C : China model E1 : Asia model JP : Japan model
BK : Black model SP : Premium Silver model
REF No. Part No. Part Name Remarks Q't
y
New
V
e
r
SEMICONDUCTORS GROUP
D1101 943209001080S DIODE,CHIP,SWITCHING CVD1SS355T 1
D1102,1103 201310001503S DIODE,ULTRA-HIGHSPEED CVDKDS160RTKP 2
D1701 201310001503S DIODE,ULTRA-HIGHSPEED CVDKDS160RTKP 1
D1902 201310001503S DIODE,ULTRA-HIGHSPEED CVDKDS160RTKP 1
D1904 201310001503S DIODE,ULTRA-HIGHSPEED CVDKDS160RTKP 1
D3975 00D2760718902 DIODE,SCHOTTKY,30V CVDRB521S-30 1
D4347-4352 943204500380S DIODE,SCHOTTKYBARRIEAR(40V,0.03A,SOD-523) CVDRB751S-40 6 *
IC111-120 943239101070S I.C,DC-DCCONVERTER(3A,QFNT&R-24P) CVIEN5339QI 10
IC121 943239010400S I.C,REGULATOR(3.3V/TO-252) CVINJM2845DL133 1
IC122 943239100730S I.C,SYSTEMRESET(4.8V,SOT-25A) CVIPST8448NR_A 1
IC123 943239010400S I.C,REGULATOR(3.3V/TO-252) CVINJM2845DL133 1
IC125 943239101070S I.C,DC-DCCONVERTER(3A,QFNT&R-24P) CVIEN5339QI 1
IC151 - I.C,CPU(2M/PLQP0144KA-A) CVIR5F56108VNFP 1
┗IC151
943243102570D IC,MAINCPU
(
AVR-X4100WE3
)
E3 CVIANAM2050A
V
1*
┗IC151
943243102560D IC,MAINCPU
(
AVR-X4100WE2
)
E2 CVIANAM2051A
V
1*
┗IC151
943243102820S IC,MAINCPU
(
AVR-X4100WK
)
JP CVIANAM2052A
V
1*
IC152 nsp I.C,EEPROM(256KBIT,SOP-8P) CVIR1EX24256BSA
S
1
IC153,154 943233102030S I.C,Shift/StoreRegister(SOIC-16P) CVIMC74HC4094AD 2 *
IC171 - I.C,CPU(32BIT,1MFLASH) CVIR5F5210ABDFP 1
┗IC171
943243102830S I.C,SUBCPU
(
AVR-X4100WBKE3
)
E3 CVIANAM1926A
V
1*
┗IC171
943243102840S I.C,SUBCPU
(
AVR-X4100WE2
)
E2 CVIANAM1937A
V
1*
┗IC171
943243102850S I.C,SUBCPU
(
AVR-X4100WK
)
JP CVIANAM1942A
V
1*
IC191 00D2623448908 I.C,3STATEQUADBUFFER CVITC74VHC125FT 1
IC201 00D2623077900 I.C,HEXINVERTER HVITC74VHCU04FT 1
IC202 943236101350D I.C,DIR/DIT(WITHADC,LQFP-48P) CVIPCM9211PTR 1
IC203,204 943236101520D I.C,DIR(SSOP-16) CVILC89091JA-H 2
IC221 - IC,PLD(FBGA,256P) CVI5M570ZF256C5
N
1*
┗IC221
943236101860S I.C,APLD
(
AVR-X4100WE3/E2/K/E1C
)
CVIANAM1932A
V
1*
IC223 236810083506S I.C,CLOCKJITTER CVICS210010-CZZR 1
IC251 943245100540S I.C,DSP(LQFP-176P/400M) CVIADSP214874B7
2
1*
IC252 943246101060S I.C,SDRAM(256M,TSOP-54P) CVIA3V56S40GTP-6 1 *
IC254 - I.C,SERIALFLASH(16M) CVIMX25L1606EM2I 1
┗IC254
943248102890S I.C,DSP1
(
AVR-X4100WE3/E2/K/E1C
)
CVIANAM1928A
V
1*
IC261 943245100550S I.C,DSP(LQFP-176P/400M) CVIADSP214874B7
2
1*
IC262 943246101060S I.C,SDRAM(256M,TSOP-54P) CVIA3V56S40GTP-6 1 *
IC264 - I.C,SERIALFLASH(16M) CVIMX25L1606EM2I 1
┗IC264
943248102900S I.C,DSP2
(
AVR-X4100WE3/E2/K/E1C
)
CVIANAM1929A
V
1*
IC271 943245100560S I.C,DSP(LQFP-176P/400M) CVIADSP214874B7
2
1*
IC272 943246101060S I.C,SDRAM(256M,TSOP-54P) CVIA3V56S40GTP-6 1 *
IC273 - I.C,SERIALFLASH(16M) CVIMX25L1606EM2I 1
┗IC273
943248102910S I.C,DSP3
(
AVR-X4100WE3/E2/K/E1C
)
CVIANAM1930A
V
1*
IC281 943245100570S I.C,DSP(LQFP-176P/400M) CVIADSP214874B7
2
1*
IC282 943246101060S I.C,SDRAM(256M,TSOP-54P) CVIA3V56S40GTP-6 1 *
IC283 - I.C,SERIALFLASH(16M) CVIMX25L1606EM2I 1
┗IC283
943248102920S I.C,DSP4
(
AVR-X4100WE3/E2/K/E1C
)
CVIANAM1931A
V
1*
IC306 236810086505S I.C,ADC(96kHz24-Bit) CVIAK5358BET 1
IC321,322 943239100690S I.C,2CHDAC(32BIT,384KHZ,TSSOP-20P) CVIPCM5100PWR 2
IC323 943239010400S I.C,REGULATOR(3.3V/TO-252) CVINJM2845DL133 1
IC351 963236101220D I.C,HDMIRX CVIADV7850KBCZ-
5
1
IC381 23681015960AS I.C,HDMI2.0TX+SCALER/ES5 CVIMN8647771 1
IC391 23681015960AS I.C,HDMI2.0TX+SCALER/ES5 CVIMN8647771 1
IC392 943239101510S I.C,MUX/DEMUX(TSSOP-16P) CVISN74CBT3251P
W
1
IC401 23681016160AS I.C,VSP(ADV8003KBCZ-8B) CVIAD55/058Z-0 1
IC402,403 24681020160AS I.C,DDR2SDRAM(512Mbits,84-ballFBGA) CVIA3R12E40CBF-8 2
IC404 - I.C,SERIALFLASH(128M,SOP-16) CVIMX25L12845EMI 1
┗IC404
943248102930S I.C,OSDFLASH
(
AVR-X4100WBKE3
)
E3 CVIANAM1927A
V
1*
┗IC404
943248102940S I.C,OSDFLASH
(
AVR-X4100WE2
)
E2 CVIANAM1938A
V
1*
┗IC404
943248102950S I.C,OSDFLASH
(
AVR-X4100WK
)
JP CVIANAM1943A
V
1*
IC421 - I.C,PLD(FBGA,256P,MAXII) CVIEPM570F256C4
N
1
┗IC421
943236101870S I.C,VPLD
(
AVR-X4100WE3/E2/K/E1C
)
CVIANAM1933A
V
1*
IC431 23681015960AS I.C,HDMI2.0TX+SCALER/ES5 CVIMN8647771 1
IC502 23671011050AS I.C,IPODAUTHENTICATIONFROMD&M CVI23671011050AS
_
1
Q1001 943239101550S FET,SSM6N15AFU,N-CH,SC-88,TOSHIBA CVTSSM6N15AFU 1 *
Q1101-1103 943229500020S MOSFET,TPC6111(P-CH,U-MOSV) CVTTPC6111 3
Q1105 943229500020S MOSFET,TPC6111(P-CH,U-MOSV) CVTTPC6111 1
Q1106 943216500050S T.R,RT1N441C(47K-47K) CVTRT1N441C 1
Q1107 943229500020S MOSFET,TPC6111(P-CH,U-MOSV) CVTTPC6111 1
Q1111-1113 943216500050S T.R,RT1N441C(47K-47K) CVTRT1N441C 3
Q1115 943216500050S T.R,RT1N441C(47K-47K) CVTRT1N441C 1
Q1116 943212500220D T.R,2SA2166,PNP,TO-236,ISAHAYA CVT2SA2166 1
Q1117 943216500020S T.R,RT1N141C(10K-10K) CVTRT1N141C 1
Q1118 943229500020S MOSFET,TPC6111(P-CH,U-MOSV) CVTTPC6111 1
Q1119 943216500050S T.R,RT1N441C(47K-47K) CVTRT1N441C 1
Q1121 943212500220D T.R,2SA2166,PNP,TO-236,ISAHAYA CVT2SA2166 1
Q1122 943216500020S T.R,RT1N141C(10K-10K) CVTRT1N141C 1
Q1123 00D2710326904 T.R,2SA1954 CVT2SA1954 1
Q1124 943216500020S T.R,RT1N141C(10K-10K) CVTRT1N141C 1
Q1125 943212500220D T.R,2SA2166,PNP,TO-236,ISAHAYA CVT2SA2166 1
Q1126 943216500020S T.R,RT1N141C(10K-10K) CVTRT1N141C 1
Q1127 943212500220D T.R,2SA2166,PNP,TO-236,ISAHAYA CVT2SA2166 1
Q1128 943216500020S T.R,RT1N141C(10K-10K) CVTRT1N141C 1
Q1131 943214500020S T.R,2SC3052 CVT2SC3052 1
Q1701,1702 943214500020S T.R,2SC3052 CVT2SC3052 2
Q1703 943214500030S T.R,MUTE CVTINC2001AC1 1
Q1704 943216500020S T.R,RT1N141C(10K-10K) CVTRT1N141C 1
Q1706 943216500020S T.R,RT1N141C(10K-10K) CVTRT1N141C 1
Q1901 943216500020S T.R,RT1N141C(10K-10K) CVTRT1N141C 1
Q1902,1903 943214500020S T.R,2SC3052 CVT2SC3052 2
Q1909 963212500030S T.R,ISA1530AC1 CVTISA1530AC1 1
Q1910,1911 943214500020S T.R,2SC3052 CVT2SC3052 2
Q1912 963212500030S T.R,ISA1530AC1 CVTISA1530AC1 1
Q1913-1917 943214500020S T.R,2SC3052 CVT2SC3052 5
Q2001 213850009503S T.R,2SC4617EBTLR(NPN,SOT-416,SMALLSIGNAL,ROHM CVT2SC4617EBTLR 1
Q2002,2003 963216500060S T.R,RT1N144C(10K-47K) CVTRT1N144C 2
Q3841,3842 943216500020S T.R,RT1N141C(10K-10K) CVTRT1N141C 2
Q3851,3852 943216500020S T.R,RT1N141C(10K-10K) CVTRT1N141C 2
Q3861,3862 943216500020S T.R,RT1N141C(10K-10K) CVTRT1N141C 2
Q3871,3872 943216500020S T.R,RT1N141C(10K-10K) CVTRT1N141C 2
