Denon AVR-X4100W

DIGITAL
REF No. Part No. Part Name Remarks Q't
y
New
V
e
r
C4307 nsp CAP,CHIP(1005,16V/0.1uF,X7R)_SAMSUNG CCUI1C104KCS 1
C4308 nsp CAP,CHIP(1608,10V/1uF,X7R,X7S)_SAMSUNG CCUS1A105KCS 1
C4309 nsp CAP,CHIP(1005,16V/0.1uF,X7R)_SAMSUNG CCUI1C104KCS 1
C4310 nsp CAP,CHIP(1608,10V/1uF,X7R,X7S)_SAMSUNG CCUS1A105KCS 1
C4311-4335 nsp CAP,CHIP(1005,16V/0.1uF,X7R)_SAMSUNG CCUI1C104KCS 25
C4336 nsp CAP,CHIP(1608,50V/10pF,C0G)_SAMSUNG CCUS1H100JAS 1
C4337 nsp CAP,CHIP(1608,50V/9pF,C0G)_SAMSUNG CCUS1H090DAS 1
C4338 nsp CAP,CHIP(1005,50V/1000pF,X7R)_SAMSUNG CCUI1H102KCS 1
C4339-4346 nsp CAP,CHIP(1005,16V/0.1uF,X7R)_SAMSUNG CCUI1C104KCS 8
C4353-4361 nsp CAP,CHIP(1005,50V/1000pF,X7R)_SAMSUNG CCUI1H102KCS 9
C4371-4373 nsp CAP,CHIP(1608,10V/1uF,X7R,X7S)_SAMSUNG CCUS1A105KCS 3
C4381-4384 nsp CAP,CHIP(1608,6.3V/4.7uF,X5R)_SAMSUNG CCUS0J475KCS 4
C4396,4397 nsp CAP,CHIP(1608,6.3V/4.7uF,X5R)_SAMSUNG CCUS0J475KCS 2
C4404,4405 nsp CAP,CHIP(1608,6.3V/4.7uF,X5R)_SAMSUNG CCUS0J475KCS 2
C4411,4412 nsp CAP,CHIP(1608,6.3V/4.7uF,X5R)_SAMSUNG CCUS0J475KCS 2
C4417,4418 nsp CAP,CHIP(1608,6.3V/4.7uF,X5R)_SAMSUNG CCUS0J475KCS 2
C4420,4421 nsp CAP,CHIP(1608,6.3V/4.7uF,X5R)_SAMSUNG CCUS0J475KCS 2
C4423,4424 nsp CAP,CHIP(1608,6.3V/4.7uF,X5R)_SAMSUNG CCUS0J475KCS 2
C4425 943134503070S CAP,SMDELECT(16V/47uF) CCEC1CMVG470T 1 *
C4428,4429 nsp CAP,CHIP(1608,6.3V/4.7uF,X5R)_SAMSUNG CCUS0J475KCS 2
C5001 nsp CAP,CHIP(1005,16V/0.1uF,X7R)_SAMSUNG CCUI1C104KCS 1
C5002 nsp CAP,CHIP(1005,50V/1000pF,X7R)_SAMSUNG CCUI1H102KCS 1
C5011,5012 nsp CAP,CHIP(1608,6.3V/4.7uF,X5R)_SAMSUNG CCUS0J475KCS 2
C5013,5014 nsp CAP,CHIP(1005,16V/0.1uF,X7R)_SAMSUNG CCUI1C104KCS 2
C5021,5022 nsp CAP,CHIP(1608,6.3V/4.7uF,X5R)_SAMSUNG CCUS0J475KCS 2
C5023,5024 nsp CAP,CHIP(1005,16V/0.1uF,X7R)_SAMSUNG CCUI1C104KCS 2
C5031,5032 nsp CAP,CHIP(1608,6.3V/4.7uF,X5R)_SAMSUNG CCUS0J475KCS 2
C5033,5034 nsp CAP,CHIP(1005,16V/0.1uF,X7R)_SAMSUNG CCUI1C104KCS 2
C5041,5042 nsp CAP,CHIP(1608,6.3V/4.7uF,X5R)_SAMSUNG CCUS0J475KCS 2
C5043,5044 nsp CAP,CHIP(1005,16V/0.1uF,X7R)_SAMSUNG CCUI1C104KCS 2
C5101 nsp CAP,CHIP(1005,16V/0.1uF,X7R)_SAMSUNG CCUI1C104KCS 1
C5111 nsp CAP,CHIP(1005,25V/0.022uF,X7R)_SAMSUNG CCUI1E223KCS 1
OTHER PARTS GROUP
BK101-103 nsp BRACKET,PCB CMD1A569-V1 3
BK104,105 nsp BRACKET,NETWORKA CMD1A900 2
BN21A nsp PINSOCKET(19P,1.25mm,ANGLE,B-TO-B) CJP19HJ282Z 1
BN23A,24 nsp PINSOCKET(27P,1.25mm,ANGLE,B-TO-B) CJP27HJ282Z 2
BN25A nsp PINSOCKET(23P,1.25mm,ANGLE,B-TO-B) CJP23HJ282Z 1
BN26A nsp PINSOCKET(09P,1.25mm,ANGLE,B-TO-B) CJP09HJ282Z 1
BN27A nsp PINSOCKET(15P,1.25mm,ANGLE,B-TO-B) CJP15HJ282Z 1
CN431 nsp WAFER,FFC,SMD(23P-1mm,STRAIGHT) CJP23GA193ZY 1
CN501,502 nsp WAFER,64pin(2x32x1.27mm)SMDTYPE CJP64GA312ZP 2
CN69B nsp WAFER,FFC,SMD(40P-1mm,STRAIGHT) CJP40GA193ZY 1
CN704 nsp WAFER,2mm,SMD,Vertical,07p CJP07GA208ZY 1 *
CN903 nsp LOCK-WAFER/STRAIGHT/2.5MMPITCH/5PIN CJP05GI289ZY 1
CN904 nsp WAFER,SMD(2MMPITCH)-4P CJP04GA208ZY 1
JK201 943643101110S JACK,2P(ORG),SILVER CJJ4N068Y 1
JK202,203 943262100150S MODULE,OPTICAL(RX16MHz) CJSJSR1124 2
JK204 943643101920S JACK,RCA(1P,BK,GOLDPLATE) CJJ4M073ZY 1
JK381-384 943643102920S JACK,HDMI(TYPE-A,SMT-19P,WITHFLANGE) CJJ9H021Z 4
JK391-394 943643102920S JACK,HDMI(TYPE-A,SMT-19P,WITHFLANGE) CJJ9H021Z 4
JK431,432 943643102920S JACK,HDMI(TYPE-A,SMT-19P,WITHFLANGE) CJJ9H021Z 2
JK501 943643102430S JACK,RJ-45W/TRANSFORMER CJJ9L029Z 1
L1001-1006 nsp RES,CHIP(1608/5%/0ohm) CRJ10DJ0R0T 6
L1008 nsp FERRITECHIPBEAD(1608/60R,CB03YTYH600) CLZ9R005V 1
L1009 nsp RES,CHIP(1608/5%/0ohm) CRJ10DJ0R0T 1
L1010 nsp FERRITECHIPBEAD(1608/60R,CB03YTYH600) CLZ9R005V 1
L1011-1013 nsp RES,CHIP(1608/5%/0ohm) CRJ10DJ0R0T 3
L1014,1015 nsp FERRITECHIPBEAD(1608/60R,CB03YTYH600) CLZ9R005V 2
L1016-1020 nsp RES,CHIP(1608/5%/0ohm) CRJ10DJ0R0T 5
L1022-1025 nsp RES,CHIP(1608/5%/0ohm) CRJ10DJ0R0T 4
L1029-1034 nsp RES,CHIP(1608/5%/0ohm) CRJ10DJ0R0T 6
L1111 nsp FERRITECHIPBEAD(1608/60R,CB03YTYH600) CLZ9R005V 1
L1113,1114 nsp FERRITECHIPBEAD(1608/60R,CB03YTYH600) CLZ9R005V 2
L1121 nsp FERRITECHIPBEAD(1608/60R,CB03YTYH600) CLZ9R005V 1
L1124 nsp FERRITECHIPBEAD(1608/60R,CB03YTYH600) CLZ9R005V 1
L1131 nsp FERRITECHIPBEAD(1608/60R,CB03YTYH600) CLZ9R005V 1
L1134 nsp FERRITECHIPBEAD(1608/60R,CB03YTYH600) CLZ9R005V 1
L1141 nsp FERRITECHIPBEAD(1608/60R,CB03YTYH600) CLZ9R005V 1
L1144 nsp FERRITECHIPBEAD(1608/60R,CB03YTYH600) CLZ9R005V 1
L1151 nsp FERRITECHIPBEAD(1608/60R,CB03YTYH600) CLZ9R005V 1
L1154 nsp FERRITECHIPBEAD(1608/60R,CB03YTYH600) CLZ9R005V 1
L1161 nsp FERRITECHIPBEAD(1608/60R,CB03YTYH600) CLZ9R005V 1
L1164 nsp FERRITECHIPBEAD(1608/60R,CB03YTYH600) CLZ9R005V 1
L1171 nsp FERRITECHIPBEAD(1608/60R,CB03YTYH600) CLZ9R005V 1
L1174 nsp FERRITECHIPBEAD(1608/60R,CB03YTYH600) CLZ9R005V 1
L1181 nsp FERRITECHIPBEAD(1608/60R,CB03YTYH600) CLZ9R005V 1
L1184 nsp FERRITECHIPBEAD(1608/60R,CB03YTYH600) CLZ9R005V 1
L1191 nsp FERRITECHIPBEAD(1608/60R,CB03YTYH600) CLZ9R005V 1
L1194 nsp FERRITECHIPBEAD(1608/60R,CB03YTYH600) CLZ9R005V 1
L1201 nsp FERRITECHIPBEAD(1608/60R,CB03YTYH600) CLZ9R005V 1
L1204 nsp FERRITECHIPBEAD(1608/60R,CB03YTYH600) CLZ9R005V 1
L1211-1213 nsp FERRITECHIPBEAD(2012/220R) CLZBLM21PG221S
N
3
L1214 nsp FERRITECHIPBEAD(2012/120R) CLZBLM21AG121S
N
1
L1215 nsp FERRITECHIPBEAD(1608/60R,CB03YTYH600) CLZ9R005V 1
L1218 nsp FERRITECHIPBEAD(1608/60R,CB03YTYH600) CLZ9R005V 1
L2201 nsp FERRITECHIPBEAD(2012/220R,CB05YTYH221) CLZ9R018V 1
L3501-3513 nsp FERRITECHIPBEAD(2012/220R) CLZBLM21PG221S
N
13
L3801-3808 nsp FERRITECHIPBEAD(2012/220R) CLZBLM21PG221S
N
8
L3901-3908 nsp FERRITECHIPBEAD(2012/220R) CLZBLM21PG221S
N
8
L3909 943113100000S COMMONMODEFILTER(1210,90ohm) CLZ9Z188Z 1
L4001-4008 nsp FERRITECHIPBEAD(1608/60R,CB03YTYH600) CLZ9R005V 8
L4010 nsp FERRITECHIPBEAD(1608/60R,CB03YTYH600) CLZ9R005V 1
L4012-4016 nsp FERRITECHIPBEAD(1608/60R,CB03YTYH600) CLZ9R005V 5
L4301-4308 nsp FERRITECHIPBEAD(2012/220R) CLZBLM21PG221S
N
8
L4311-4313 nsp RES,CHIP(1005/5%/0ohm*2) CRJ062IJ0R0T 3
L4314 943113100000S COMMONMODEFILTER(1210,90ohm) CLZ9Z188Z 1
L4321-4323 nsp RES,CHIP(1005/5%/0ohm*2) CRJ062IJ0R0T 3
L4324 943113100000S COMMONMODEFILTER(1210,90ohm) CLZ9Z188Z 1
L5111,5112 nsp COMMONMODEFILTER(2012,90ohm) CLZ9Z174Z 2
ST01-03 nsp WIREASS'Y(1P,80MM,BLK,#22) CWE5202080A 3
X1501 943141101260S X-TAL,SMD(12MHz/8pF,FA-238V,3.2X2.5) COX12000I080SP 1
X1701 943141101260S X-TAL,SMD(12MHz/8pF,FA-238V,3.2X2.5) COX12000I080SP 1
X2001 943141101310S X-TAL,SMD(24.576MHz/10pF,FA-238,3.2X2.5) COX24576I100SP 1 *
X2501 943141101280S X-TAL,SMD(25MHz/12pF,FA-238,3.2X2.5) COX25000I120SP 1
X2601 943141101280S X-TAL,SMD(25MHz/12pF,FA-238,3.2X2.5) COX25000I120SP 1
30
