Denon AVR-X4100W

CX870CONNECTOR
CX870CONNECTOR PCB ASS'
Y
※Parts indicated b
y
"ns
p
"on this table cannot be su
pp
lied.
※The
p
arts listed below are onl
y
for maintenance. Therefore the
y
mi
g
ht differ from the
p
arts used in the unit in a
pp
earances or dimension
s
NOTE:The symbols in the column Remarks indicate the following destinations.
E3 : U.S.A. & Canada model E2 : Europe model E1C : China model E1 : Asia model JP : Japan model
BK : Black model SP : Premium Silver model
REF No. Part No. Part Name Remarks Q't
y
New
V
e
r
SEMICONDUCTORS GROUP
IC911 943239101090S I.C,Highsideswitch(TSSOP-B8) CVIBD82065FVJ-E2 1
IC921 nsp MODULE,BLUETOOTH,CLASS2,IBT-06-02 CNVIBT-06-02 1
IC922 00MHC012405KY I.C,INVERTER(SON5-P-0.50) CVITC7SGU04FE 1
IC923 943231101890S I.C,LDOREGULATOR(HTSOP-J8) CVIBD00HA3WEFJ-
E
1
RESISTOR GROUP
R9102,9103 nsp RES,CHIP(1005/5%/0ohm) CRJ06IJ0R0T 2
R9106 nsp RES,CHIP(1005/5%/10Kohm) CRJ06IJ103T 1
R9107-9112 nsp RES,CHIP(1005/5%/0ohm) CRJ06IJ0R0T 6
R9113 nsp RES,CHIP(1005/5%/10Kohm) CRJ06IJ103T 1
R9114 nsp RES,CHIP(1005/5%/10ohm) CRJ06IJ100T 1
R9116 nsp RES,CHIP(1005/5%/0ohm) CRJ06IJ0R0T 1
R9119 nsp RES,CHIP(1005/5%/10Kohm) CRJ06IJ103T 1
R9122,9123 nsp RES,CHIP(1005/5%/10Kohm) CRJ06IJ103T 2
R9124,9125 nsp RES,CHIP(1005/5%/33ohm) CRJ06IJ330T 2
R9127 nsp RES,CHIP(1005/5%/10Kohm) CRJ06IJ103T 1
R9141-9152 nsp RES,CHIP(1608/5%/0ohm) CRJ10DJ0R0T 12
R9161,9162 nsp RES,CHIP(1005/5%/2.2Kohm) CRJ06IJ222T 2
R9191 nsp RES,CHIP(1608/5%/0ohm) CRJ10DJ0R0T 1
R9202 nsp RES,CHIP(1608/5%/680Kohm) CRJ10DJ684T 1
R9203,9204 nsp RES,CHIP(1005/5%/10Kohm) CRJ06IJ103T 2
R9206 nsp RES,CHIP(1608/5%/10Mohm) CRJ10DJ106T 1
R9211 nsp RES,CHIP(1005/5%/10Kohm) CRJ06IJ103T 1
R9213 nsp RES,CHIP(1608/5%/11Kohm) CRJ10DJ113T 1
R9214 nsp RES,CHIP(1608/5%/39Kohm) CRJ10DJ393T 1
RN911 nsp RES,CHIP(1005/5%/0ohm*4) CRJ064IJ0R0T 1
RN913 nsp RES,CHIP(1005/5%/0ohm*4) CRJ064IJ0R0T 1
RN915 nsp RES,CHIP(1005/5%/0ohm*4) CRJ064IJ0R0T 1
CAPACIITORS GROUP
C9105,9106 nsp CAP,CHIP(1005,16V/0.1uF,X7R)_SAMSUNG CCUI1C104KCS 2
C9107-9110 nsp CAP,CHIP(2012,6.3V/10uF,X5R)_SAMSUNG CCUC0J106KCS 4
C9113 nsp CAP,CHIP(2012,6.3V/10uF,X5R)_SAMSUNG CCUC0J106KCS 1
C9114-9117 nsp CAP,CHIP(1608,50V/0.1uF,X7R)_SAMSUNG CCUS1H104KCS 4
C9201 nsp CAP,CHIP(1608,10V/1uF,X7R,X7S)_SAMSUNG CCUS1A105KCS 1
C9203-9205 nsp CAP,CHIP(1005,16V/0.1uF,X7R)_SAMSUNG CCUI1C104KCS 3
C9206 nsp CAP,CHIP(1608,50V/27pF,C0G)_SAMSUNG CCUS1H270JAS 1
C9207 nsp CAP,CHIP(1608,50V/22pF,C0G)_SAMSUNG CCUS1H220JAS 1
C9211 nsp CAP,CHIP(1608,10V/1uF,X7R,X7S)_SAMSUNG CCUS1A105KCS 1
C9213 nsp CAP,CHIP(1608,10V/1uF,X7R,X7S)_SAMSUNG CCUS1A105KCS 1
OTHER PARTS GROUP
BK911 nsp BRACKET,NETWORKB CMD1A902 1
BK912 nsp BRACKET,NETWORKB CMD1A902 1
BN501,502 nsp WAFER,64pin(2x32x1.27mm)FEMALESMDTYPE CJP64GA314ZP 2
CN911 nsp WAFER,120PINH=4.5mmp=0.5mm CJP120GA313ZR 1
CN914 nsp LOCK-WAFER/ANGLE/2MMPITCH/5PIN CJP05GJ288ZY 1
CN915 nsp WAFER,SMTRIGHTANGLE CJP04GB220ZY 1
CN916 nsp LOCK-WAFER/ANGLE/2MMPITCH/11PIN CJP11GJ288ZY 1 *
CN917 nsp WAFER,FFC,SMD(07P-1mm,STRAIGHT) CJP07GA193ZY 1
JW911 nsp WIREASS'Y(1P,80MM,BLK,#22) CWE5202080A 1
JW913 nsp WIREASS'Y(1P,80MM,BLK,#22) CWE5202080A 1
BN921
EXPLODED
_
C6
nsp WIREASS'YLocking(YH)(11P,2MM,380MM,#26) CWB7B011380HC0
0
1
L9101,9102 nsp FERRITECHIPBEAD(1608/60R,CB03YTYH600) CLZ9R005V 2
L9201,9202 nsp FERRITECHIPBEAD(1608/60R,CB03YTYH600) CLZ9R005V 2
X9201 943141101250S X-TAL,SMD(32.768KHz/12.5pF,FC-135,3.2x2.5) COX00032I125SP 1
32
