Denon AVR-X4100W

Device display during rmware update
Display of target device during rmware update.
Target device DPMS Update Display Error code when an error occurs
Main CPU
L1
M a i n * * * m i n
L2
U p d a t i n g * * %
10 - 16
36 - 3F
Sub
L1
S u b * * * m i n
L2
U p d a t i n g * * %
50 - 52
54 - 58
5A - 62
Audio PLD
L1
A P L D * * * m i n
L2
U p d a t i n g * * %
50 - 52
54 - 58
5A - 62
VIDEO PLD
L1
V P L D * * * m i n
L2
U p d a t i n g * * %
50 - 52
54 - 58
5A - 62
DSP
L1
D S P 1 * * * m i n
L2
U p d a t i n g * * %
L1
D S P 2 * * * m i n
L1
D S P 3 * * * m i n
L1
D S P 4 * * * m i n
50 - 52
54 - 58
5A - 62
GUI Serial Flash
L1
G U I * * * m i n
L2
U p d a t i n g * * %
50 - 52
54 - 58
5A
62
80 - 86
CX870 / CY920 second
Boot Load-
er
L1
E t h e r S B L * * * m i n
L2
U p d a t i n g * * %
A0 - A4
A6 - A7
AE - B5
CX870 / CY920
L1
E t h e r I M G * * * m i n
L2
U p d a t i n g * * %
A0 - A4
A6 - A7
AE - B5
CX870 / CY920
I Image (Emer-
gency Mode)
L1
P l e a s e w a i t . . .
L2
U p d a t e r e t r y
–
Checking the Firmware Version After an Update
After updating the rmware, check the version.
See "1. Version Display Mode" (19 page ).
96
