Detailed settings when “Assign Mode” is set to
“Dolby Atmos”
When “Assign Mode” is set to “Dolby Atmos”, set the following items.
n
Layout
Select the speaker layout for Dolby Atmos playback.
7.1ch + 4 Height:
This is a layout that adds the top front and
top rear speakers to the 7.1 channel layout
which includes the surround back channel.
Connect the top front speakers to the
HEIGHT1 speaker terminals and connect the
top rear speakers to the HEIGHT2 PRE OUT
connectors through an external power
amplifier.
7.1ch + 2 Height
(Default):
This is a layout that adds the top middle
speakers to the 7.1 channel layout including
the surround back channel. Connect the top
middle speakers to the HEIGHT1 speaker
terminals.
5.1ch + 4 Height:
This is a layout that adds the top front and
top rear speakers to the basic 5.1 channel
layout. Connect the top front speakers to the
HEIGHT1 speaker terminals and the top rear
speakers to the FRONT WIDE/HEIGHT2
speaker terminals.
5.1ch + 2 Height:
This is a layout that adds the top middle
speakers to the basic 5.1 channel layout.
Connect the top middle speakers to the
HEIGHT1 speaker terminals.
If you use “Dolby Atmos Enabled speakers”, the “Assign Mode” is set to “11.1ch”
(v p. 227) or “9.1ch” (v p. 231).
