Denon AVR-X5200W

Upgrade (Auro-3D)
o
Detailed setting when “Assign Mode” is set to
“Auro-3D”
When “Assign Mode” is set to “Auro-3D”, set the following items.
n
Layout
Select the speaker layout for Auro-3D playback
Auro 9.1ch
(Default):
This is a layout that adds the front height and
surround height speakers to the basic 5.1 channel
layout.
Connect the front height speakers to the HEIGHT1
speaker terminals and the surround height speakers
to the FRONT WIDE/HEIGHT2 speaker terminals.
Auro 10.1ch:
This is a layout that adds the front height, surround
height and top surround speakers to the basic 5.1
channel layout.
Connect the front height speakers to the HEIGHT1
speaker terminals and the surround height speakers
to the FRONT WIDE/HEIGHT2 speaker terminals.
And connect the top surround speaker to
SUBWOOFER 2 PRE OUT connector through an
external power amplifier.
In this setting, you can’t use the second subwoofer.
o
View Terminal Config.
This shows how to connect the speaker terminals and PRE OUT
connectors for your “Amp Assign” setting on the menu screen.
