Denon AVR-X6400H Service Manual

1.4. Error display
See the table below for descriptions of the displayed errors and countermeasures for these.
If multiple errors occur, only one item is displayed.
The priority order is
w
,
e
,
r
,
t
,
y
,
q
.
Condition States Display TROUBLE SHOOTING
q
Firm Check
NG
(
#
: 1/2/3/4)
The model name, brand name and region information
written in the rmware are compared to the region
settings in the PCB. This error is displayed if the infor-
mation does not match.
" ▲ " is displayed as the rst character if the rmware
is not correct (see the illustrations on the right).
FIRM ERROR
–
M:*************
–
Main FBL :**.**
–
DSP# :**.**
–
Audio PLD:**.**
–
Video PLD:**.**
–
GUI :********
• Check the resistor for setting the
region [R6217, R6218, R6219, DIGITAL
PCB].
• Write the rmware for the correct
region.
w
IP SCALER NG
An error occurs in Loop back Test of the DDR memory
which is performed during the initial setting of i/p
Scaler(ADV8003).
IP SCALER ERR 01
• Check the circuits around the IP
SCALER [U2800, DIGITAL PCB] and
DDR2 [U3000/U3001].
If there appear to be no problems,
[U2800] or [U3000/U3001] is faulty.
During the initial setting of i/p Scaler ( ADV8003 ) ,
there is not the reply of the Loop back Test result of
the DDR memory .
IP SCALER ERR 02
e
GUI Serial
Flash NG
If the Main CPU version is not supported by the GUI
Serial Flash (ADV8003),
" ▼ " is displayed as the rst character of the GUI
rmware version.
GUI VER. ERROR
•
GUI :********
• Check the rmware version.
r
DIR NG
This error is displayed if there is no response from the
DIR.
DIR ERROR 01
• Check the DIR [U7004, DIGITAL PCB]
and surrounding circuits.
t
DSP
#
NG
(
#
: 1/2/3/4)
The DSP FLAG0 port does not enter "
Hi
" status while
booting a DSP code even after resetting DSP.
DSP# ERROR 01
• Check the DSP [U101, U201, U301,
U401, DIGITAL PCB] and surrounding
circuits.
The DSP FLAG0 port does not enter "
Hi
" status before
issuing a DSP command.
DSP# ERROR 02
Setting WRITE to "
Lo
" does not set ACK to "
Hi
" during
DSP data reading.
DSP# ERROR 03
Setting REQ to "
Lo
" does not set ACK to "
Lo
" during
DSP data reading.
DSP# ERROR 04
Setting WRITE to "
Hi
" does not set ACK to "
Hi
" during
DSP data writing.
DSP# ERROR 05
Setting REQ to "
Lo
" does not set ACK to "
Lo
" during
DSP data writing.
DSP# ERROR 06
y
EEPROM NG
An error occurred in a checksum of the EEPROM(*** is
a block address number).
BACKUP ERROR
145
Caution in
servicing
Electrical Mechanical Repair Information Updating

Denon AVR-X6400H Specifications

General

Receiver type	Surround
Frequency range	10 - 100000 Hz
Pre-out channels	11.2
Input sensitivity	200 mV
Pre-out connectivity	Yes
Audio output channels	11.2 channels
Signal-to-Noise Ratio (SNR)	100 dB
Power output per channel (1KHz@6 Ohm)	205 W
Power output per channel (20-20KHz@8 Ohm)	140 W
Display	-
HDCP version	2.2
Apple docking	No
Product color	Silver
Audio decoders	DTS:X, Dolby Atmos
Audio formats supported	ALAC, DSD, FLAC, WAV
RS-232 ports	1
Connectivity technology	Wireless
AM band range	522 - 1611 kHz
FM band range	87.5 - 108 MHz
Supported radio bands	AM, FM
Internet radio services supported	Deezer, Napster, Spotify, Tidal, TuneIn
HDMI in	8
Composite video in	4
Component video (YPbPr/YCbCr) in	2
AC input voltage	230 V
AC input frequency	50 Hz
Power consumption (standby)	0.5 W
Power consumption (typical)	750 W
Number of HDMI outputs	3

Weight and Dimensions

Depth	393 mm
Width	434 mm
Height	167 mm
Weight	14500 g
