Denon AVR-X6400H Service Manual

Paths to be conrmed Display Settings What to conrm
3
DIGITAL
(ZONE2)
g.03a
g.03b
g.03c
A03:DIGITAL-Z2
Input Source : HEOS Music
Input Mode : Auto
Sound mode : STEREO
Amp assign : 9.1ch + ZONE2
Speaker for ZONE2 : S.Back
Floor Layout : 5ch
Height Sp : 2ch
Dolby Sp : None
Height Layout : Front Height/Rear Height
MAIN ZONE : On
ZONE2 : On
ZONE3 : Off
・ Digital(PCM) input ⇒ Speaker output (S.Back (ZONE2) L/R)
・ Digital(PCM) input ⇒ Pre OUT output (ZONE2 L/R)
(
b
The input source can be switched to any source except HEOS Music.)
4
DIGITAL
(ZONE3)
g.04a
g.04b
A04:DIGITAL-Z3
Input Source : HEOS Music
Input Mode : Auto
Sound mode : STEREO
Amp assign : 9.1ch + ZONE3
Speaker for ZONE3 : Height2
Floor Layout : 5ch
Height Sp : 2ch
Dolby Sp : None
Height Layout : Front Height/Rear Height
MAIN ZONE : On
ZONE2 : Off
ZONE3 : On
・ Digital(PCM) input ⇒ Amp Assign Speaker output (Height2 (ZONE3) L/R)
・ Digital(PCM) input ⇒ Pre OUT output (ZONE3 L/R)
(
b
The input source can be switched to any source except HEOS Music.)
5 HDMI
g.05a
g.05b
g.05c
A05:HDMI
Input Source : CBL/SAT
Input Mode : HDMI (xed)
Sound mode : STEREO
Amp assign : 11.1ch
Floor Layout : 5ch&SB
Height Sp : 4ch
Dolby Sp : None
Height Layout : Front Height/Rear Height
MAIN ZONE : On
ZONE2 : Off
ZONE3 : Off
・ HDMI input ⇒ Speaker output (Front L/R)
・ HDMI input ⇒ Pre OUT output (Front L/R)
(
b
The input source can be switched to any source except CBL/SAT.)
6
Analog AD
(MAIN ZONE)
g.06a
g.06b
A06:AD
Input Source : CBL/SAT
Input Mode : Analog (xed)
Sound mode : MULTI CH STEREO
Amp assign : 11.1ch
Floor Layout : 5ch&SB
Height Sp : 4ch
Dolby Sp : None
Height Layout : Front Height/Rear Height
Speaker Select : Floor
Speaker Cong ALL Speaker = Small/SW = Yes(2ch)
MAIN ZONE : On
ZONE2 : Off
ZONE3 : Off
・ Analog input ⇒ Speaker output (Front L/R, Center, Surround L/R, S.Back L/R, Height1 L/R)
・ Analog input ⇒ Pre OUT output, SW(20Hz) (Front L/R, Center, Surround L/R, S.Back L/R, Sub-
Woofer)
(
b
The input source can be switched to any source except CBL/SAT.)
(
b
Volume 60 is the value when Absolute settings are used. The value is -20 when Relative set-
tings are used)
7
Analog Amp Assign
(Amp Assign :
ZONE2)
g.07
A07:ASSIGN-Z2
Input Source : CBL/SAT
Input Mode : Auto
Sound mode : STEREO
Z2 Source : Source
Amp assign : 9.1ch + ZONE2
Speaker for ZONE2 : S.Back
Floor Layout : 5ch
Height Sp : 4ch
Dolby Sp : None
Height Layout : Front Height/Rear Height
MAIN ZONE : On
ZONE2 : On
ZONE3 : Off
・ Analog input ⇒ Speaker output (S.Back (ZONE2) L/R)
・ Analog input ⇒ Pre OUT output (ZONE2 L/R)
(
b
The input source can be switched to any source except CBL/SAT.)
(
b
Volume 60 is the value when Absolute settings are used. The value is -20 when Relative set-
tings are used)
158
Caution in
servicing
Electrical Mechanical Repair Information Updating

Denon AVR-X6400H Specifications

General

Receiver type	Surround
Frequency range	10 - 100000 Hz
Pre-out channels	11.2
Input sensitivity	200 mV
Pre-out connectivity	Yes
Audio output channels	11.2 channels
Signal-to-Noise Ratio (SNR)	100 dB
Power output per channel (1KHz@6 Ohm)	205 W
Power output per channel (20-20KHz@8 Ohm)	140 W
Display	-
HDCP version	2.2
Apple docking	No
Product color	Silver
Audio decoders	DTS:X, Dolby Atmos
Audio formats supported	ALAC, DSD, FLAC, WAV
RS-232 ports	1
Connectivity technology	Wireless
AM band range	522 - 1611 kHz
FM band range	87.5 - 108 MHz
Supported radio bands	AM, FM
Internet radio services supported	Deezer, Napster, Spotify, Tidal, TuneIn
HDMI in	8
Composite video in	4
Component video (YPbPr/YCbCr) in	2
AC input voltage	230 V
AC input frequency	50 Hz
Power consumption (standby)	0.5 W
Power consumption (typical)	750 W
Number of HDMI outputs	3

Weight and Dimensions

Depth	393 mm
Width	434 mm
Height	167 mm
Weight	14500 g
