1. Home Theater Playback – Playing Back Using Multi-channel System –
Setting HDMI Audio Output
When you press and set “HDMI Setup” – “Audio Setup” to “Auto” (vpage 23) on the GUI menu,
audio mode is set according to the connected device.
When you want to set the HDMI audio output separately, change according to the following table.
Refer to the owner’s manual of the connected device regarding HDMI audio input specications
compatible with the connected device.
•
•
•
Device to be connected Setting items About output signal and speaker settings
Device with the following
built-in decoder
Dolby TrueHD
Dolby Digital Plus
Dolby Digital
DTS-HD
DTS
·
·
·
·
·
Auto
DBP-4010UD outputs a bitstream signal that is decoded by
the connected device.
In this case, you cannot make a speaker setting for HDMI
audio with the DBP-4010UD.
Make the setting with the connected device.
When outputting the Dolby TrueHD or DTS-HD audio,
press and set “BD Audio Mode” to “HD Audio
Output” (vpage 32).
b
b
Device compatible with
multi-channel HDMI audio
input, but not capable of
speaker setting for each
channel
Multi LPCM
BM On
Outputs multi-channel Linear PCM audio signals with
speaker setting by the DBP-4010UD.
For speaker setting, on the GUI menu, “Audio Setup”
– “7.1ch Audio Out” – “Multi Channel” – “Speaker
Conguration” (vpage 25).
BM : Bass Management (means multi-channel speaker
setting)
b
b
Device compatible with
multi-channel HDMI audio
input, and capable of
speaker setting for each
channel
Multi LPCM
BM Off
Output of multi-channel Linear PCM audio signals from the
DBP-4010UD.
Perform the speaker setting with the connected device.
BM : Bass Management (means multi-channel speaker
setting)
b
Device compatible with 2-
channel HDMI audio input
2Ch
Downmixed 2-channel Linear PCM audio signals are output
from the DBP-4010UD.
Perform the speaker setting with the connected device.
Device not compatible with
HDMI audio signal input
Mute
Audio signal are not output from the DBP-4010UD’s HDMI
terminal.
Only video signals are output from the HDMI terminal.
Make the audio connection.b
NOTE
When the HDMI video resolution is set to “1080P24”, HDMI video signals are output from the DBP-
4010UD with a resolution of 1080P and a frame rate of 24 frames per second, regardless of the video
signals on the disc being played. Because of this, when playing discs containing video signals recorded
with a frame rate of something other than 24 frames per second, the movement of the picture may be
unnatural. If this happens, set the HDMI video resolution to something other than “1080P24”.
When the “I/P Direct” (vpage 23) setting is “On” and a disc with a frame rate of 24 frames per second
is played, no video signals are output from the video or S-Video outputs.
When the “I/P Direct” (vpage 23) setting is “Off”, “1080P24” is not displayed.
•
•
•
Audio signal from the HDMI output terminal
You can change the audio format and playback number of channels according to the specications
of the device to which the DBP-4010UD’s HDMI audio output signals are input. Make settings while
checking the specications of the audio device to be connected as well as the audio format/number
of channels stored in media and les for playback.
n
Media/Files Audio format
Setting “HDMI Setup” – “Audio Setup” (vpage 23) on
the GUI menu
Auto
Multi LPCM
BM On/Off
2Ch
BD
Dolby Digital
Dolby Digitalz1
Multi LPCM
2 ch Downmix
LPCM
Dolby Digital Plus
Dolby Digital Plusz1
Dolby TrueHD
Dolby TrueHD
z
1
DTS
DTSz1
DTS-HD
DTS-HDz1
LPCM Multi LPCM
AVCHD
Dolby Digital Dolby Digital
Multi LPCM
2 ch Downmix
LPCM
LPCM Multi LPCM
DVD-Video
Dolby Digital Dolby Digital
DTS DTS
LPCM, MPEG 2 ch LPCM
DVD-Audio LPCM, PPCM
Multi LPCM
2 ch Downmix
LPCM
Super audio CDz2
Multi area
Stereo area
2 ch LPCM
CD layer
DivX
®
Dolby Digital Dolby Digital Multi LPCM
2 ch Downmix
LPCM
MP3, MP2
2 ch LPCM
CD, MP3, WMA, AAC, LPCM
DTS-CD DTS Multi LPCM
2 ch Downmix
LPCM
z1 :
Multi LPCM signals are output when “BD Audio Mode” is set to “Mix Audio Output ” (vpage 32).
Multi LPCM signals are output when outputting HDMI video signals with resolutions of 480i/576i or
480p/576p.
z2 :
Super Audio CD audio signals are output at 44.1 kHz 16-bit.
Even if “HDMI Setup” – “Audio Setup” on the GUI menu is set to “Auto” (vpage 23), multilinear PCM
or downmixed 2-channel linear PCM signals are output if a device that does not support bitstreams is
connected.
