Before turning the power switch on
Check once again that all connections are correct and that there are
no problems with the connection cables.
Power is supplied to some of the circuitry even when the unit is
set to the standby mode. When traveling or leaving home for long
periods of time, be sure to unplug the power cord from the power
outlet.
Image persistence (image burn-in)
Do not leave the still images of the disc menu, DBP-4010UD menu,
etc., displayed on the TV screen for long periods. This can result in
image persistence (image burn-in) on the screen.
About Condensation
If the DBP-4010UD unit is moved from a cold place to a warm
place, or installed in a room subject to rapid temperature rise from
a heater, etc., condensation (dew) may form on the internal parts of
the unit (operating parts and lenses).
If used in this condition, the DBP-4010UD will not operate correctly
and damage may result. If condensation is formed on the unit, leave
the DBP-4010UD unit for1 to 2 hours with the power OFF before
use.
Cautions on using mobile phones
Using a mobile phone near this unit may result in noise. If so, move
the mobile phone away from this unit when it is in use.
Moving the unit
Be sure to remove a disc, turn off the power and unplug the power
cord from the power outlet. Next, disconnect the connection cables
to other system equipment before moving the unit.
About Care
Wipe the cabinet and control panel clean with a soft cloth.
Follow the instructions when using a chemical cleaner.
Benzene, paint thinner or other organic solvents as well as
insecticide may cause material changes and discoloration if brought
into contact with the unit, and should, therefore, not be used.
Sufciently ventilate the place of installation
If the unit is left in a room full of the smoke from cigarettes, etc.,
for long periods of time, the surface of the optical pickup could get
dirty, in which case it will not be able to read the signals properly.
Note that the illustrations in these instructions may differ from the
actual unit for explanation purposes.
•
•
•
•
•
•
•
•
•
•
•
•
Note:
For proper heat dispersal, do not install this unit in a conned
space, such as a bookcase or similar enclosure.
Cautions on Handling
Cautions on Installation
Noteb
b
Wall
b
b
About Media
Playable Media
Playable Media
Playable
formats/
modes
Playable
region codes
Symbols
Used
in this
Owner’s
Manual
BD-Video
z1,z2
–
Include region
BD
DVD-Audio
z1
–
–
DVD-A
DVD-Video
z1,z2
Include region
ALL
2
DVD-V
DVD-R,
DVD+R
Video
mode,
AVCHD
format
–
DVD
DVD-RW,
DVD+RW
Super Audio
CD
– –
SA-CD
CD
– –
CD
CD-R
CD-RW
Discs
z1 :
BD-Video/DVD-Audio/DVD-Video discs may not operate as
described in this manual due to menu structure.
z2 :
The BD player and BD-Video disc, and DVD player and DVD-
Video disc each have their region codes (code assigned for
each region). Playback is not possible if the codes do not
match.
Getting Started
Do not place the DBP-4010UD on an amp or other piece of equipment
that generates heat.
