Denon DHT-FS5 Service Manual

46
DHT-FS5
OTHERS PARTS GROUP
1200 nsp CON V 18P F SM FFC, 18FMN-BMT-A-TF
242202517194
1202 nsp RES XTL SM 12M288 20P SMD-49 242254301602
1301 nsp RES XTL SM 9M8304 20P SMD-49 242254301603
1302 nsp CON V 9P M, B9B-PH-SM4-TBT 242202518744
1303 nsp CON V 16P F SM FFC, 16FMN-BMT-A-TF 242202517202
1305 nsp CON V 5P M, B5B-PH-SM4-TBT 242202518739
1400 nsp CON V 15P F SM FFC, 15FMN-BMT-A-TF 242202517018
5200 nsp IND FXD 0603 EMI 100MHZ 220R 242254900393
5201 nsp IND FXD 0603 EMI 100MHZ 220R 242254900393
5300 nsp IND FXD 0603 EMI 100MHZ 30R 242254943769
5301 nsp IND FXD 0603 EMI 100MHZ 30R 242254943769
5302 nsp IND FXD 0603 EMI 100MHZ 220R 242254900393
5303 nsp IND FXD 0603 EMI 100MHZ 220R 242254900393
5305 nsp IND FXD 0603 EMI 100MHZ 220R 242254900393
5306 nsp IND FXD 0603 EMI 100MHZ 220R 242254900393
5307 nsp IND FXD 0805 EMI 100MHZ 220R 242254944197
5400 nsp IND FXD 0805 EMI 100MHZ 220R 242254944197
5401 nsp IND FXD 0805 EMI 100MHZ 220R 242254944197
5402 nsp IND FXD 0805 EMI 100MHZ 220R 242254944197
5403 nsp IND FXD 0805 EMI 100MHZ 220R 242254944197
Ref. No. Part No. Part Name Remarks Q'ty New

Denon DHT-FS5 Specifications

General

Type	Home theatre speakers
Frequency range	80 - 20000 Hz
Dimensions (WxDxH)	750 x 138 x 118 mm
Satellite speaker driver diameter	3.15 \
Audio output channels	5.0 channels
Impedance	6 Ω
RMS rated power	150 W
Signal-to-Noise Ratio (SNR)	100 dB
Microphone in	Yes
Product color	Black

Weight and Dimensions

Weight	5100 g
