Denon DHT-FS5 Service Manual

47
DHT-FS5
SKA POWER AMPLIFIER P.W.B. UNIT ASS'Y
Ref. No. Part No. Part Name Remarks Q'ty New
SEMICONDUCTORS GROUP
7500 nsp IC SM TAS5186ADDV
932224277668
7501 nsp IC SM TAS5086DBT 932224276668
7601 nsp IC NJM4556AD 932207732682
7700 nsp IC SM LF120ABDT 932224262668
7701 nsp IC SM LF33CPT 932213916668
7502 nsp TRA SIG SM BC847B 319801042030
7503 nsp TRA SIG SM BC857B 319801042150
7504 nsp TRA SIG SM BC857B 319801042150
7505 nsp TRA SIG SM BC847B 319801042030
7605 nsp TRA SIG SM BC847B 319801042030
7610 nsp TRA SIG SM BC857B 319801042150
7611 nsp TRA SIG SM BC817-40 932200424685
7612 nsp TRA SIG SM BC817-40 932200424685
7613 nsp TRA SIG SM BC847B 319801042030
7705 nsp TRA POW SM BCP53 933917330115
7706 nsp TRA SIG SM BC857B 319801042150
7709 nsp TRA SIG SM BC847B 319801042030
6603 nsp DIO SIG SM BAS316 319801010630
RESISTORS GROUP
3500 nsp RST SM 0603 10K PM5
319802131030
3501 nsp RST SM 0603 1R0 PM5 319802131080
3502 nsp RST SM 0603 1R0 PM5 319802131080
3503 nsp RST SM 0603 100K PM5 319802131040
3504 nsp RST CRB 1/6W A 1K8 PM5 319801101820
3505 nsp RST SM 0603 100R PM5 319802131010
3506 nsp RST SM 0603 100R PM5 319802131010
3507 nsp RST SM 0603 100R PM5 319802131010
3508 nsp NTC SM 0603 0W125 10K PM5 232261533103
3509 nsp RST SM 0603 10K PM5 319802131030
3510 nsp RST SM 0603 100R PM5 319802131010
3511 nsp RST SM 0603 1R0 PM5 319802131080
3512 nsp RST SM 0603 1R0 PM5 319802131080
3513 nsp RST SM 0603 100R PM5 319802131010
3514 nsp RST SM 0603 100R PM5 319802131010
3515 nsp RST SM 0603 100R PM5 319802131010
3516 nsp RST SM 0603 100R PM5 319802131010
3517 nsp RST SM 0603 100K PM5 319802131040
3518 nsp RST SM 0603 100R PM5 319802131010
3519 nsp RST SM 0603 18K PM5 319802131830
3520 nsp RST CRB 1/6W A 1K8 PM5 319801101820
3526 nsp RST SM 0603 220R PM5 319802132210
3527 nsp RST SM 0603 100R PM5 319802131010
3528 nsp RST SM 0603 100R PM5 319802131010
3529 nsp RST SM 0603 10K PM5 319802131030
3530 nsp RST SM 0603 1R0 PM5 319802131080
3531 nsp RST SM 0603 1R0 PM5 319802131080
3532 nsp RST SM 0603 100R PM5 319802131010
3533 nsp RST SM 0603 100R PM5 319802131010
3534 nsp RST SM 0603 100R PM5 319802131010
3535 nsp RST SM 0603 100K PM5 319802131040

Denon DHT-FS5 Specifications

General

Type	Home theatre speakers
Frequency range	80 - 20000 Hz
Dimensions (WxDxH)	750 x 138 x 118 mm
Satellite speaker driver diameter	3.15 \
Audio output channels	5.0 channels
Impedance	6 Ω
RMS rated power	150 W
Signal-to-Noise Ratio (SNR)	100 dB
Microphone in	Yes
Product color	Black

Weight and Dimensions

Weight	5100 g
