Denon DHT-FS5 Service Manual

48
DHT-FS5
3536 nsp RST SM 2512 PRC221 100R PM5 232276260101
3537 nsp RST SM 0603 100R PM5 319802131010
3538 nsp RST SM 0603 10K PM5 319802131030
3539 nsp RST SM 0603 10K PM5 319802131030
3540 nsp RST SM 0603 10K PM5 319802131030
3541 nsp RST SM 0603 10K PM5 319802131030
3542 nsp RST SM 0603 10K PM5 319802131030
3543 nsp RST SM 0603 10K PM5 319802131030
3544 nsp RST SM 0603 10K PM5 319802131030
3545 nsp RST SM 0603 10K PM5 319802131030
3546 nsp RST SM 0603 220R PM5 319802132210
3547 nsp RST SM 0603 1R0 PM5 319802131080
3548 nsp RST SM 0603 1R0 PM5 319802131080
3549 nsp RST SM 0603 RC22H 18K2 PM1 232270481823
3550 nsp RST CRB 1/6W A 10R PM5 319801101090
3551 nsp RST SM 0603 10K PM5 319802131030
3552 nsp RST SM 0603 100K PM5 319802131040
3553 nsp RST CRB 1/6W A 1K8 PM5 319801101820
3554 nsp RST SM 0603 22K PM5 319802132230
3555 nsp RST SM 0603 10K PM5 319802131030
3556 nsp RST SM 0603 10K PM5 319802131030
3557 nsp RST SM 0603 1R0 PM5 319802131080
3558 nsp RST SM 0603 1R0 PM5 319802131080
3559 nsp RST SM 0603 100K PM5 319802131040
3560 nsp RST SM 0603 10K PM5 319802131030
3561 nsp RST SM 0603 100K PM5 319802131040
3562 nsp RST SM 0603 100K PM5 319802131040
3563 nsp RST CRB 1/6W A 1K8 PM5 319801101820
3564 nsp RST SM 1206 RC01 10R PM5 232271181109
3565 nsp RST SM 1206 RC01 10R PM5 232271181109
3566 nsp RST SM 1206 RC01 10R PM5 232271181109
3567 nsp RST SM 1206 RC01 10R PM5 232271181109
3568 nsp RST SM 1206 RC01 10R PM5 232271181109
3569 nsp RST SM 1206 RC01 10R PM5 232271181109
3570 nsp RST CRB 1/6W A 10R PM5 319801101090
3571 nsp RST SM 0603 10K PM5 319802131030
3572 nsp RST SM 0603 10K PM5 319802131030
3573 nsp RST SM 0603 470R PM5 319802134710
3574 nsp RST SM 2512 PRC221 100R PM5 232276260101
3575 nsp RST SM 1206 RC01 12R PM5 232271161129
3576 nsp RST SM 1206 RC01 12R PM5 232271161129
3577 nsp RST SM 1206 RC01 12R PM5 232271161129
3578 nsp RST SM 1206 RC01 12R PM5 232271161129
3579 nsp RST SM 1206 RC01 12R PM5 232271161129
3580 nsp RST SM 1206 RC01 12R PM5 232271161129
3600 nsp RST SM 0603 10K PM5 319802131030
3601 nsp RST SM FUSE 1206 22R PM5 232275062209
3602 nsp RST SM 0603 10K PM5 319802131030
3604 nsp RST SM 0603 33K PM5 319802133330
3605 nsp RST SM 0603 10K PM5 319802131030
3606 nsp RST SM 0603 47K PM5 319802134730
3609 nsp RST SM 0603 68K PM5 319802136830
3610 nsp RST SM 0603 10K PM5 319802131030
3614 nsp RST SM 0603 22K PM5 319802132230
3615 nsp RST SM 0603 33K PM5 319802133330
3623 nsp RST SM 0603 68K PM5 319802136830
Ref. No. Part No. Part Name Remarks Q'ty New

Denon DHT-FS5 Specifications

General

Type	Home theatre speakers
Frequency range	80 - 20000 Hz
Dimensions (WxDxH)	750 x 138 x 118 mm
Satellite speaker driver diameter	3.15 \
Audio output channels	5.0 channels
Impedance	6 Ω
RMS rated power	150 W
Signal-to-Noise Ratio (SNR)	100 dB
Microphone in	Yes
Product color	Black

Weight and Dimensions

Weight	5100 g
