Denon DHT-FS5 Service Manual

49
DHT-FS5
3628 nsp RST SM 0603 22K PM5 319802132230
3629 nsp RST SM 0603 22K PM5 319802132230
3634 nsp RST SM 0603 10K PM5 319802131030
3635 nsp RST SM 0603 22K PM5 319802132230
3636 nsp RST SM 0603 220K PM5 319802132240
3637 nsp RST SM 0603 470R PM5 319802134710
3638 nsp RST SM 0603 330R PM5 319802133310
3639 nsp RST SM 0603 100R PM5 319802131010
3640 nsp RST SM 0603 4K7 PM5 319802134720
3641 nsp RST SM 0603 4K7 PM5 319802134720
3642 nsp RST SM 0603 4K7 PM5 319802134720
3701 nsp RST SM 0603 10R PM5 319802131090
3702 nsp RST SM 0603 10R PM5 319802131090
3710 nsp RST SM FUSE 1206 4R7 PM5 232275064708
3711 nsp RST SM 0603 47K PM5 319802134730
3712 nsp RST SM 0603 10K PM5 319802131030
3713 nsp RST SM 0603 22K PM5 319802132230
3714 nsp RST SM 0603 4K7 PM5 319802134720
3715 nsp RST SM 0603 1K2 PM5 319802131220
4600 nsp RST SM 0603 JUMP. 0R05 COL 319802190030
4701 nsp RST SM 0603 JUMP. 0R05 COL 319802190030
4702 nsp RST SM 0603 JUMP. 0R05 COL 319802190030
4703 nsp RST SM 0603 JUMP. 0R05 COL 319802190030
4704 nsp RST SM 0603 JUMP. 0R05 COL 319802190030
CAPACITORS GROUP
2500 nsp CAP MPOL 63V S 470N PM5
202030800003
2501 nsp CAP SM PPS 50V 100N PM5 202031900002
2502 nsp CAP SM PPS 50V 100N PM5 202031900002
2503 nsp CAP SM PPS 50V 100N PM5 202031900002
2504 nsp CAP SM PPS 50V 100N PM5 202031900002
2505 nsp CAP SM PPS 50V 100N PM5 202031900002
2506 nsp CAP SM PPS 50V 100N PM5 202031900002
2508 nsp ELCAP VZ 50V S 330U PM20 310413051171
2509 nsp CER2 0603 X7R 50V 10N 319801731030
2510 nsp CER2 0603 X7R 50V 10N 319801731030
2511 nsp CER2 0603 X7R 50V 10N 319801731030
2512 nsp CER2 0603 X7R 50V 10N 319801731030
2513 nsp ELCAP VZ 50V S 330U PM20 310413051171
2514 nsp CER2 0603 X7R 16V 470N PM10 202055200189
2515 nsp CER2 0603 X7R 16V 470N PM10 202055200189
2516 nsp CAP MPOL 63V S 470N PM5 202030800003
2517 nsp ELCAP VZ 50V S 330U PM20 310413051171
2518 nsp CER2 0603 X7R 16V 100N 319801731040
2519 nsp CER2 0603 X7R 50V 10N 319801731030
2520 nsp CER2 0603 X7R 50V 10N 319801731030
2521 nsp CER2 0603 X7R 50V 10N 319801731030
2522 nsp CER2 0603 X7R 50V 10N 319801731030
2523 nsp ELCAP VZ 50V S 330U PM20 310413051171
2524 nsp CER1 0603 NP0 50V 100P 319801631010
2525 nsp CER1 0603 NP0 50V 100P 319801631010
2526 nsp CER1 0603 NP0 50V 100P 319801631010
2527 nsp CER1 0603 NP0 50V 100P 319801631010
2528 nsp CER1 0603 NP0 50V 100P 319801631010
Ref. No. Part No. Part Name Remarks Q'ty New

Denon DHT-FS5 Specifications

General

Type	Home theatre speakers
Frequency range	80 - 20000 Hz
Dimensions (WxDxH)	750 x 138 x 118 mm
Satellite speaker driver diameter	3.15 \
Audio output channels	5.0 channels
Impedance	6 Ω
RMS rated power	150 W
Signal-to-Noise Ratio (SNR)	100 dB
Microphone in	Yes
Product color	Black

Weight and Dimensions

Weight	5100 g
