Denon DHT-FS5 Service Manual

50
DHT-FS5
2529 nsp CER2 0805 X7R 50V 10N 319801701030
2531 nsp CER2 0805 X7R 50V 10N 319801701030
2533 nsp CER2 0603 X7R 16V 100N 319801731040
2534 nsp CER2 0603 X7R 16V 100N 319801731040
2535 nsp CER2 0603 X7R 16V 100N 319801731040
2536 nsp CER2 0603 X7R 16V 100N 319801731040
2537 nsp CER2 0603 X7R 16V 100N 319801731040
2538 nsp CER2 0603 X7R 16V 100N 319801731040
2539 nsp ELCAP 5MM 35V 10U PM20 319802841090
2540 nsp CER2 0805 X7R 50V 10N 319801701030
2541 nsp CER2 0603 X7R 50V 10N 319801731030
2547 nsp CER2 0805 X7R 50V 10N 319801701030
2548 nsp CER2 0805 X7R 50V 10N 319801701030
2549 nsp CAP MPOL 63V S 470N PM5 202030800003
2550 nsp ELCAP M 50V S 2200U PM20 202002490447
2551 nsp CER2 0805 X7R 50V 10N 319801701030
2552 nsp CER2 0603 X7R 50V 10N 319801731030
2553 nsp CER2 0603 X7R 50V 10N 319801731030
2554 nsp CER2 0603 X7R 50V 10N 319801731030
2555 nsp CER2 0603 X7R 50V 10N 319801731030
2556 nsp CER2 0805 X7R 50V 10N 319801701030
2557 nsp ELCAP M 50V S 2200U PM20 202002490447
2558 nsp CAP MPOL 63V S 470N PM5 202030800003
2559 nsp ELCAP VZ 50V S 330U PM20 310413051171
2560 nsp CER2 0603 X7R 50V 10N 319801731030
2561 nsp CER2 0603 X7R 16V 100N 319801731040
2562 nsp CER2 0603 X7R 50V 10N 319801731030
2563 nsp CER2 0603 X7R 50V 10N 319801731030
2564 nsp CER2 0603 X7R 50V 10N 319801731030
2565 nsp CER2 0603 X7R 50V 10N 319801731030
2566 nsp ELCAP VZ 50V S 330U PM20 310413051171
2567 nsp ELCAP BP NW7 16V S 10U PM20 202000990074
2568 nsp CAP MPOL 63V S 470N PM5 202030800003
2569 nsp ELCAP VZ 50V S 330U PM20 310413051171
2570 nsp CER2 0603 X7R 50V 10N 319801731030
2571 nsp CER2 0603 X7R 50V 10N 319801731030
2572 nsp CER2 0603 X7R 50V 10N 319801731030
2573 nsp CER2 0603 X7R 50V 10N 319801731030
2574 nsp ELCAP VZ 50V S 330U PM20 310413051171
2575 nsp CAP MPOL 63V S 470N PM5 202030800003
2576 nsp CER1 0603 NP0 50V 220P 319801632210
2577 nsp CER1 0603 NP0 50V 220P 319801632210
2578 nsp CER1 0603 NP0 50V 220P 319801632210
2579 nsp CER1 0603 NP0 50V 220P 319801632210
2580 nsp CER1 0603 NP0 50V 220P 319801632210
2581 nsp CER1 0603 NP0 50V 220P 319801632210
2584 nsp CER2 0603 X7R 16V 470N PM10 202055200189
2585 nsp CER2 0603 X7R 16V 470N PM10 202055200189
2586 nsp CER1 0603 NP0 50V 220P 319801632210
2600 nsp CER2 0603 X7R 16V 100N 319801731040
2601 nsp ELCAP 5MM 35V 47U PM20 319802844790
2603 nsp CER1 0603 NP0 50V 220P 319801632210
2604 nsp CER2 0603 X7R 16V 100N 319801731040
2605 nsp ELCAP 5MM 35V 47U PM20 319802844790
2606 nsp CER2 0603 X7R 16V 470N PM10 202055200189
2608 nsp CER1 0603 NP0 50V 470P 319801634710
Ref. No. Part No. Part Name Remarks Q'ty New

Denon DHT-FS5 Specifications

General

Type	Home theatre speakers
Frequency range	80 - 20000 Hz
Dimensions (WxDxH)	750 x 138 x 118 mm
Satellite speaker driver diameter	3.15 \
Audio output channels	5.0 channels
Impedance	6 Ω
RMS rated power	150 W
Signal-to-Noise Ratio (SNR)	100 dB
Microphone in	Yes
Product color	Black

Weight and Dimensions

Weight	5100 g
