Denon DHT-FS5 Service Manual

51
DHT-FS5
2609 nsp CER1 0603 NP0 50V 12P 319801631290
2628 nsp CER2 0603 X7R 10V 220N 319801732240
2629 nsp ELCAP 5MM 50V 22U PM20 319802852290
2630 nsp CER2 0603 X5R 10V 2U2 PM10 202055200132
2631 nsp CER2 0603 X5R 10V 2U2 PM10 202055200132
2700 nsp ELCAP 5MM 35V 10U PM20 319802841090
2701 nsp CER2 0603 X7R 16V 100N 319801731040
2702 nsp CER2 0603 X7R 16V 100N 319801731040
2703 nsp ELCAP 5MM 35V 47U PM20 319802844790
2704 nsp ELCAP RGA 50V S 1000U PM20 202203100238
2705 nsp CER2 0603 X7R 16V 100N 319801731040
2706 nsp ELCAP RGA 50V S 1000U PM20 202203100238
2711 nsp ELCAP 5MM 35V 10U PM20 319802841090
2712 nsp CER2 0603 X7R 16V 100N 319801731040
2713 nsp CER2 0603 X7R 16V 100N 319801731040
2714 nsp CER2 0603 X7R 16V 100N 319801731040
2720 nsp CER2 0603 X7R 50V 10N 319801731030
2722 nsp CER2 0603 X5R 10V 470N PM10 202055296457
2723 nsp ELCAP 5MM 35V 10U PM20 319802841090
2724 nsp ELCAP 5MM 35V 10U PM20 319802841090
OTHERS PARTS GROUP
1500 nsp CON V 16P F 1.00 SM FFC 0.3 R
242202517202
1501 nsp CON BM V 6P M 2.50 EH B 242202512482
1502 nsp CON BM V 4P M 2.50 EH B 242202512479
1503 nsp CON V 15P F 1.00 SM FFC 0.3 R 242202517018
1504 nsp CON BM V 5P M 2.50 EH B 242202512481
1604 nsp CON BM V 2P M 2.50 EH B 241202000724
1700 nsp CON BM V 3P M 3.96 VH B 242202511143
1702 nsp CON BM V 2P M 2.50 EH B 241202000724
5500 nsp IND FXD 16RHBP S 22U P10M20 242253600822
5501 nsp IND FXD 0603 EMI 100MHZ 60R, BLM18 242254945153
5502 nsp IND FXD 16RHBP S 22U P10M20 242253600822
5504 nsp IND FXD 16RHBP S 10U PM20 242253601533
5505 nsp IND FXD 16RHBP S 22U P10M20 242253600822
5506 nsp IND FXD 16RHBP S 22U P10M20 242253600822
nsp Cooling block 3104 211 30390
nsp Pressure spring 3104 211 30400
nsp Tapt. screw wash St Zn 3x10
nsp Grease (Wacker)
1312 502 09001
nsp Curved washer 3104 211 30460
Ref. No. Part No. Part Name Remarks Q'ty New

Denon DHT-FS5 Specifications

General

Type	Home theatre speakers
Frequency range	80 - 20000 Hz
Dimensions (WxDxH)	750 x 138 x 118 mm
Satellite speaker driver diameter	3.15 \
Audio output channels	5.0 channels
Impedance	6 Ω
RMS rated power	150 W
Signal-to-Noise Ratio (SNR)	100 dB
Microphone in	Yes
Product color	Black

Weight and Dimensions

Weight	5100 g
